Список запчастей

№	Артикул	Название	Кол-во
2	503191183	Spring Support	2
2	503190754	Retainer Cushion	2
2	205082544	Socket Head Screw M8 X 25	2
2	233281414	Hex. Flange Elastic Nut M8	2
1	503192211	Rocker	1
1	503193037	Bushing	1
1	503189282	Bushing	1
1	207005044	Hex. Screw M10 X 1.5 X 50	1
1	233601416	Elastic Locking Nut M10 X 1.5	1
1	503193274	Front Arm Ass'y Includes 10 To 11	1
2	408200700	Grease Fitting	2
1	503191390	Lower Shaft	1
2	503189324	Bushing	2
2	503192496	Washer	2
2	250000605	Hex. Screw S.Grip M10 X 55	2
1	503191391	Upper Shaft	1
2	503189564	Washer	2
1	503191396	Axle Pivot	1
1	503191397	Bolt 369mm	1
4	503189157	Washer	4
1	233281414	Hex. Flange Elastic Nut M8	1
	503191709	Rear Arm Ass'y Includes 24 To 37
1	503191398	Rear Arm	1
2	414644300	Black, Dart	2
	XXXX	Not Available As Spare Part - Bushing
1	503191565	LH Cam Adjuster	1
1	503191566	RH Cam Adjuster	1
2	293370013	E-Circlip	2
2	503191555	Swivel Bushing	2
1	503191393	Welded Arm Pivot	1
1	503192330	Lower Shaft	1
2	503191640	Cushion	2
2	503189148	Washer	2
2	205523554	Socket Head Screw M12 X 35	2
4	408200700	Grease Fitting	4
2	503191451	Cushion	2
1	503191405	Upper Shaft	1
2	503190328	Washer	2
2	206260844	Socket Set Screw M6 X 8	2
2	503190803	Wheel 165	2
2	503194366	Retaining Ring	2
2	503192491	Washer	2
2	250000484	Socket Screw M12 X 35	2
1	503192377	Black RH Square Spring	1
1	503192378	Black LH Square Spring	1
2	503191765	Link Rod Model LE	2
	503193026	ROD_LINK Model SE
2	503190114	Spacer Model SE	2
1	503190643	Axle Bar (Long) Model LE	1
1	503190113	Bar Axle (Short) Model SE	1
1	503190643	Axle Bar (Long)	1
1	207089044	Hex. Screw M8 X 90 Model LE	1
1	230083044	Hex. Screw M8 X 130 Model SE	1
1	207089044	Hex. Screw M8 X 90	1
2	503189157	Washer	2
1	503193520	Rear Shock Model LE	1
1	503193000	Rear Shock Ass'y Model SE	1
1	503191939	Male Pneumatic Connector	1
1	503192649	Pneumatic Hose Ass'y	1
2	414936000	Bushing Model LE, SE	2
2	207684044	Hex. Flange Screw M8 X 40	2
	XXXX	Not Available As Spare Part - Center Shock Ass'y Includes 63 To 71
1	503192991	Center Shock Model Europe	1
1	503192266	Center Shock Model North America	1
1	505073625	Adjustment Cam	1
1	503189686	Black, Spring	1
1	503193663	Protector	1
1	503191872	Spring Guide	1
1	503189912	Spring Stopper Model Europe	1
1	706200881	Spring Stopper Model North America	1
2	503189117	Urethane Bushing	2
1	706001349	Compressor Model SE	1
1	706000940	Check Valve Model SE	1
1	706000869	Connector Model SE	1
1	219704415	Hose 4.32Mm 3000Mm Long Model SE	1
2	503193103	Compressor Bracket Model SE	2
1	706000631	Compressor Isolator Model SE	1
	503193484	SUPPORT Model SE
	513033638	Protector Tube Model SE
1	219704425	Tubing 6 Mm 3000Mm Long Model SE	1
1	503193009	Air manifold Ass'y Model SE	1
2	706000872	Elbow 90° Model SE	2
2	515175232	Male Terminal Model SE	2
1	515175654	Male Terminal Housing, 2 Circuits Model SE	1
2	205562044	Socket Head Screw M6 X 20, Scotch Grip Model SE	2
2	234061410	Flat Washer 6 mm Model SE	2
1	503193034	Tube Model SE	1
4	250000722	Torx Screw M6 X 20 Model SE	4
	207063544	Hex. Flange Screw M6 X 35 Model SE
	503193393	CLAMP Model SE
1	235551454	Screw-Torx Button Head M5 X 14 Model SE	1
1	233251434	Flange Elastic Nut M5 Model SE	1
7	293150102	Rivet 3/16" Model SE	7
	503193004	BRACKET Model SE
	503193006	HOSE PROTECTOR Model SE
	503193007	HOSE PROTECTOR Model SE
	503193011	HOSE PROTECTOR PAINTED Model SE
1	515177125	Compressor Module Model SE	1
