Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Engine 1200 4-TEC | ||
| 1 | 512060591 | Rear Support, PTO | 1 |
| 1 | 207585086 | Hex. Flange Screw M8 X 50, Scotch Grip | 1 |
| 3 | 234281474 | Conical Spring Washer M8 | 3 |
| 1 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 1 |
| 1 | 207583586 | Hex. Flange Screw M8 X 35, Scotch Grip Sub 250000986 | 1 |
| 1 | 512060593 | Front Support, PTO | 1 |
| 2 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 2 |
| 2 | 234281474 | Conical Spring Washer M8 | 2 |
| 1 | 512060594 | Rear Support, MAG | 1 |
| 2 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 2 |
| 1 | 512060596 | Front Support, MAG | 1 |
| 2 | 512060729 | Rubber Mount | 2 |
| 2 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 2 |
| 1 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 1 |
| 1 | 207562534 | Hex. Flange Screw M6 X 25, Scotch Grip | 1 |
| 2 | 207586044 | Hex. Flange Screw M8 X 60, Scotch Grip | 2 |
| 3 | 503183200 | Yellow, Washer | 3 |
| 2 | 250200008 | Flat Washer With Teflon 8 mm | 2 |
| 2 | 250000257 | Cone Screw, M8 X 30 | 2 |
| 1 | 232581414 | Hex. Elastic Stop Nut M8 | 1 |
| 2 | 512060244 | Stopper | 2 |
| 2 | 512060285 | Spacer | 2 |
| 2 | 293650046 | Oetiker Clamp | 2 |
| 1 | 512061113 | Housing Ass'y Includes 28 To 42 | 1 |
| XXXX | Not Available As Spare Part - Housing | ||
| XXXX | Not Available As Spare Part - Sensor | ||
| XXXX | Not Available As Spare Part - Shaft Seal | ||
| XXXX | Not Available As Spare Part - Swivel | ||
| 1 | 512060862 | Cap | 1 |
| 3 | 250000623 | Torx Screw M2.9 x 9.5 | 3 |
| 4 | 250000671 | Torx Screw | 4 |
| XXXX | Not Available As Spare Part - Spring | ||
| XXXX | Not Available As Spare Part - Handle | ||
| XXXX | Not Available As Spare Part - O Ring | ||
| XXXX | Not Available As Spare Part - Screw | ||
| 1 | 250000528 | Torx Screw M5 X 20 | 1 |
| 1 | 515177716 | Protector Tube | 1 |
| 1 | 515177362 | Emergency Stop Switch Includes 43 To 44 | 1 |
| 2 | 515175232 | Male Terminal | 2 |
| 1 | 512060844 | Support | 1 |
| 1 | 294000973 | Friction Tape | 1 |
| 2 | 250000263 | Torx Screw #8-18 | 2 |
| 1 | 512060987 | Front Housing | 1 |
| 2 | 250000632 | Torx Screw M5 X 14 | 2 |
| 4 | 241151640 | Hex. Flange Screw K50 X 2.24 X 16 | 4 |
| 1 | 512061012 | Module Support | 1 |
| 2 | 250000079 | Panel Nut M5 X 0.8 | 2 |
| 2 | 207552044 | Hex. Flange Screw M5 X 20, Scotch Grip | 2 |
| 1 | 516005521 | Caution Decal, Oil Level | 1 |
| 39065 | Aluminium coated fiberglass tube | ||
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
