Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 13201-05A10 | CARBURETOR ASSY, FRONT LH MODEL F/F2 | ||
| 13201-05A30 | CARBURETOR ASSY, FRONT LH MODEL G | ||
| 13202-05A10 | CARBURETOR ASSY, FRONT RH MODEL F/F2 | ||
| 13202-05A30 | CARBURETOR ASSY, FRONT RH MODEL G | ||
| 13203-05A10 | CARBURETOR ASSY, REAR LH MODEL F/F2 | ||
| 13203-05A30 | CARBURETOR ASSY, REAR LH MODEL G | ||
| 13204-05A10 | CARBURETOR ASSY, REAR RH MODEL F/F2 | ||
| 13204-05A30 | CARBURETOR ASSY, REAR RH MODEL G; Includes Item(s) 5 - 71 | ||
| 13502-05A10 | COVER, DIAPHRAGM | ||
| 4 | 13503-05A10 | SPRING | 4 |
| 4 | 13389-37400 | PLATE | 4 |
| 4 | 13387-44030 | RING | 4 |
| 4 | 13394-31210 | E RING | 4 |
| 4 | 13382-44030 | WASHER | 4 |
| 4 | 13388-44030 | SPRING | 4 |
| 4 | 13500-05A10 | DIAPHRAGM ASSY | 4 |
| 13383-05A10 | NEEDLE, JET (5F68) FL,FR | ||
| 13383-05A20 | NEEDLE, JET (5F69) RL,RR | ||
| 09494-00476 | JET, NEEDLE (Y-9) | ||
| 4 | 13605-05A10 | SCREW | 4 |
| 4 | 13332-44080 | WASHER | 4 |
| 13627-05A10 | BRACKET FR,RL | ||
| 13627-05A20 | BRACKET FL,RR | ||
| 16 | 02112-05106 | SCREW | 16 |
| 4 | 13251-05A10 | O RING | 4 |
| 4 | 13332-05A10 | PACKING | 4 |
| 4 | 13385-05A10 | HOLDER | 4 |
| 4 | 09491-21020 | JET, MAIN (107.5) | 4 |
| 4 | 13332-35400 | GASKET | 4 |
| 13250-05A10 | FLOAT | ||
| 4 | 13254-20010 | .PIN,FLOAT | 4 |
| 4 | 13370-42A10 | VALVE ASSY, NEEDLE | 4 |
| 4 | 13374-44080 | O RING | 4 |
| 4 | 13376-65010 | NET | 4 |
| 09492-27004 | JET, PILOT (27.5) | ||
| 09492-67001 | JET, AIR (67.5) | ||
| 13411-05A10 | PLUNGER | ||
| 13417-05A10 | SPRING | ||
| 4 | 13278-47090 | O RING | 4 |
| 4 | 13418-05A10 | HOLDER | 4 |
| 14 | 13601-04148 | SCREW FL:4,FR:3,RL:3,RR:4 | 14 |
| 13603-05A20 | SCREW FR,RL | ||
| 13692-05A10 | CLIP FL,RR | ||
| 13551-05A10 | VALVE, THROTTLE | ||
| 8 | 13604-44080 | SCREW | 8 |
| 4 | 13601-03078 | SCREW | 4 |
| 4 | 13484-37300 | COVER MODEL F/F2 | 4 |
| 4 | 13484-38A10 | COVER MODEL G | 4 |
| 4 | 13480-05A10 | DIAPHRAGM ASSY | 4 |
| 4 | 13481-05A10 | SPRING | 4 |
| 13482-37300 | PLATE MODEL F/F2 | ||
| 12 | 13602-05A40 | SCREW | 12 |
| 13627-05A30 | BRACKET FR | ||
| 13605-05A20 | SCREW FR,RL,RR | ||
| 13271-05A10 | SPRING RL,RR | ||
| 13550-05A10 | SHAFT ASSY RR | ||
| 3 | 13268-96110 | SPRING FR,RL,RR | 3 |
| 13550-05A20 | SHAFT ASSY RL | ||
| 13573-05A10 | SPRING RR | ||
| 13447-05A10 | PLATE RL,RR | ||
| 13550-05A30 | SHAFT ASSY FR | ||
| 13573-05A20 | SPRING FR | ||
| 13553-05A10 | LEVER ASSY FR | ||
| 13553-05A20 | LEVER FR | ||
| 13563-47070 | PIN FR | ||
| 13553-05A30 | LEVER ASSY FL | ||
| 1 | 08310-22088 | NUT FL | 1 |
| 13606-47070 | WASHER FL,MODEL F/F2 | ||
| 1 | 08321-21088 | LOCK WASHER FL,MODEL G | 1 |
| 13557-05A20 | RING FL | ||
| 13573-05A30 | SPRING FL | ||
| 13550-05A40 | SHAFT ASSY FL | ||
| 13573-05A40 | SPRING RL | ||
| 4 | 13617-44080 | E RING | 4 |
| 4 | 13557-47070 | WASHER | 4 |
| 8 | 13556-05A10 | SEAL | 8 |
| 1 | 13607-05A10 | NUT FR | 1 |
| 4 | 13602-05A10 | SCREW | 4 |
