Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 24120-34001 | COUNTER SHAFT ASSY K,L,M,A; FROM 24120-34000 TO 24120-34002 SEE NOTE | ||
| 24120-34002 | COUNTER SHAFT ASSY A; TO 24120-34003 | ||
| 24120-34003 | COUNTER SHAFT ASSY B; Includes Item(s) 2 - 8 | ||
| 24121-34000 | COUNTER SHAFT K,L,M,A,B; NT : 13 | ||
| 24221-31000 | GEAR, 2ND DRIVE K,L,M,A; NT : 19 | ||
| 24221-37000 | GEAR, 2ND DRIVE A,B; NT : 18 | ||
| 24231-31000 | GEAR, 3RD DRIVE K,L,M,A; NT : 22 | ||
| 24231-37000 | GEAR, 3RD DRIVE A,B; NT : 21 | ||
| 24240-31000 | GEAR, 4TH DRIVE K,L,M,A; NT : 24 | ||
| 24240-31001 | GEAR, 4TH DRIVE B; NT : 24 | ||
| 24250-31000 | GEAR, 5TH DRIVE K,L,M; NT : 26 TO 24250-31001 | ||
| 24250-31001 | GEAR, 5TH DRIVE A,B; NT : 26 | ||
| 1 | 09167-28001 | WASHER K,L,M,A,B | 1 |
| 1 | 08331-11289 | CIRCLIP K,L,M,A,B; FROM 09380-28002 | 1 |
| 24131-34000 | DRIVE SHAFT K,L,M,A,B | ||
| 24310-31940 | GEAR, 1ST DRIVEN K,L,M,A,B; NT : 37 YELLOW PAINTED | ||
| 24320-31930 | GEAR, 2ND DRIVEN K,L,M,A; NT : 33 BLUE PAINTED | ||
| 24320-37000 | GEAR, 2ND DRIVEN A,B; NT : 32 | ||
| 24330-31000 | GEAR, 3RD DRIVEN K,L,M,A; NT : 30 | ||
| 24330-37000 | GEAR, 3RD DRIVEN A,B; NT : 29 | ||
| 24341-31000 | GEAR, 4TH DRIVEN K,L,M,A,B; NT : 27 | ||
| 24351-31000 | GEAR, 5TH DRIVEN K,L,M; NT : 24 TO 24351-31001 | ||
| 24351-31001 | GEAR, 5TH DRIVEN A,B; NT : 24 | ||
| 09160-20004 | WASHER K,L,M,A,B; 20x30.5x1 | ||
| 09160-28006 | WASHER K,L,M,A,B; 28x38x4 | ||
| 3 | 09167-28001 | WASHER K,L,A,BM | 3 |
| 3 | 09380-28002 | CIRCLIP K,L; TO 08331-11289 | 3 |
| 3 | 08331-11289 | CIRCLIP M,A,B | 3 |
| 09262-30022 | BEARING K,L,M,A,B | ||
| 1 | 08163-62040 | BEARING K,L,M,A,B | 1 |
| 09263-20005 | BEARING K,L,M,A,B | ||
| 09319-26002 | BUSHING K; TO 09319-26001 | ||
| 09319-26001 | BUSHING L,M,A,B | ||
| 08163-62063 | BEARING K,L,M,A,B | ||
| 08163-63050 | BEARING K,L,M,A,B | ||
| 09390-72004 | C RING K,L,M,A,B | ||
| 09390-47003 | C RING K,L,M,A,B | ||
| 2 | 09390-62005 | C RING K,L,M,A,B | 2 |
| 09390-32001 | C RING K,L,M,A,B | ||
| 09283-25050 | OIL SEAL K,L,M,A,B | ||
| 1 | 06211-07122 | DOWEL PIN K,L,M,A,B | 1 |
| 24973-34000 | PLUG, OIL RESERVOIR K,L,M,A,B | ||
| 09285-08003 | OIL, SEAL K,L,M,A,B | ||
| 24870-34000 | PLATE, OIL RESERVOIR K,L,M,A,B | ||
| 2 | 02112-06128 | SCREW K,L,M,A,B | 2 |
| 2 | 02122-06128 | SCREW K,L,M,A,B | 2 |
| 24881-34000 | PLATE, OIL GUIDE K,L; TO 24881-34001 | ||
| 24881-34001 | PLATE, OIL GUIDE M,A,B | ||
| 3 | 02112-05168 | SCREW K,L,M,A,B | 3 |
| 3 | 08321-21058 | LOCK WASHER K,L,M,A,B | 3 |
| 27511-33600 | SPROCKET, ENGINE K,L,M,A,B; NT : 16K,L,M,A,B; NT : 15, OPT | ||
| 27512-33000 | PLATE, ENGINE SPROCKET K,L,M,A,B | ||
| 3 | 01112-06128 | BOLT K,L,M,A,B | 3 |
| 09167-25008 | WASHER K,L,M,A,B | ||
| 27600-34010 | CHAIN ASSY, DRIVE (#50HDS x 10 K; TO 27600-31013K; TO 27600-31013 | ||
| 27600-31013 | CHAIN ASSY, DRIVE (#50HDS x 10 L; TO 27600-31015L; TO 27600-31015 | ||
| 27600-31015 | CHAIN ASSY, DRIVE (#50HDSS x 1 M,A,BM,A,B | ||
| 27600-31700 | CHAIN ASSY, DRIVE K,L; 41, EXTENTION CHAIN OPT | ||
| 27620-31012 | JOINT, CHAIN (DID 50HDS) K,L; OPT |
