Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 13200-33111 | CARBURETOR ASSY L,M,A,B; FROM 13200-33110; Includes Item(s) 1 - 81 | ||
| 13201-33111 | CARBURETOR, RH L,M,A,B; FROM 13201-33110 | ||
| 13202-33111 | CARBURETOR, MIDDLE L,M,A,B; FROM 13202-33110 | ||
| 13203-33111 | CARBURETOR, LH L,M,A,B; FROM 13203-33110 | ||
| 2 | 13424-33110 | RING L,M,A,B | 2 |
| 13617-33110 | CLIP L,M,A,B | ||
| 2 | 13682-09210 | CAP L,M,A,B | 2 |
| 13418-33110 | CAP L,M,A,B | ||
| 2 | 13295-15010 | O RING L,M,A,B | 2 |
| 2 | 13417-18630 | SPRING L,M,A,B | 2 |
| 13411-33110 | VALVE, STARTER L,M,A,B | ||
| 13398-33110 | BRACKET L,M,A,B | ||
| 6 | 13601-03078 | SCREW L,M; TO 02111-03067 | 6 |
| 6 | 02111-03067 | SCREW A,B | 6 |
| 3 | 13394-10010 | CLIP, NEEDLE L,M,A,B | 3 |
| 3 | 13383-33010 | NEEDLE, JET L,M,A,B; 4DH7-2 | 3 |
| 13561-33110 | VALVE, THROTTLE LH & M L,M,A,B; CA:3.0 | ||
| 13551-33110 | VALVE, THROTTLE RH L,M,A,B | ||
| 13269-15011 | SCREW L,M,A,B; FROM 13269-31011 | ||
| 3 | 13295-33010 | .O-RING L,M,A,B | 3 |
| 3 | 13268-01010 | SPRING L,M,A,B | 3 |
| 3 | 13392-18110 | GASKET L,M; TO 13392-58600 | 3 |
| 3 | 13392-58600 | GASKET A,B | 3 |
| 13370-34010 | VALVE, NEEDLE L,M,A,B | ||
| 09494-00075 | JET, NEEDLE L,M,A,B; 0-2 | ||
| 3 | 13382-03110 | WASHER L,M,A,B | 3 |
| 09491-80007 | JET, MAIN L,M,A,B; #80 FROM 09491-80005 | ||
| 3 | 09492-25003 | JET, PILOT L,M,A,B; #25 | 3 |
| 3 | 13252-11010 | FLOAT L,M,A,B | 3 |
| 3 | 13254-01010 | .PIN,FLOAT L,M,A,B | 3 |
| 3 | 13247-05010 | SCREW L,M,A,B; FROM 13247-31010 | 3 |
| 3 | 13249-05010 | GASKET L,M,A,B | 3 |
| 3 | 13251-18010 | GASKET, FLOAT CHAMBER L,M; TO 13251-33110 | 3 |
| 3 | 13251-33110 | GASKET, FLOAT CHAMBER A,B | 3 |
| 12 | 08321-21048 | LOCK WASHER L,M,A,B | 12 |
| 12 | 02111-04168 | SCREW L,M,A,B | 12 |
| 1 | 13664-18654 | PLUG L,M,A,B; FROM 13664-31010 | 1 |
| 1 | 13663-31010 | WASHER L,M,A,B | 1 |
| 13573-33110 | SPRING, THROTTLE L,M,A,B | ||
| 13295-33110 | O RING L,M,A,B | ||
| 13210-33111 | CONTROL ASSY L,M,A,B | ||
| 13552-33110 | SHAFT, THROTTLE VALVE L,M,A,B | ||
| 13582-33600 | NUT L,M,A,B | ||
| 13564-33110 | ARM L,M,A,B | ||
| 13563-33110 | PIN L,M,A,B | ||
| 13611-33600 | BOLT L,M,A,B | ||
| 13582-33110 | NUT L,M,A,B | ||
| 13619-33110 | CLIP L,M,A,B | ||
| 13602-03079 | SCREW L,M; TO 02111-03087 | ||
| 3 | 02111-03087 | SCREW A,B | 3 |
| 13267-33110 | SCREW L,M,A,B | ||
| 13268-33110 | SPRING L,M,A,B | ||
| 13557-33110 | PLATE L,M,A,B | ||
| 13601-04129 | SCREW L,M; TO 02111-04127 | ||
| 1 | 02111-04127 | SCREW A,B | 1 |
| 1 | 09128-06011 | BOLT L,M,A,B; FROM 13612-33110 | 1 |
| 13607-31600 | NUT LM,A,B | ||
| 13605-33110 | SCREW L,M,A,B | ||
| 1 | 13268-31210 | SPRING L,M,A,B | 1 |
| 2 | 08351-21008 | NIPPLE L,M,A,B | 2 |
| 13611-33610 | BOLT L,M,A,B | ||
| 13625-33110 | RUBBER L,M,A,B | ||
| 13602-05079 | SCREW L,M; TO 02112-05088 | ||
| 3 | 02112-05088 | SCREW A,B | 3 |
| 13615-33110 | WASHER L,M,A,B | ||
| 13616-33110 | KEY L,M,A,B | ||
| 13422-33110 | LEVER L,M,A,B | ||
| 2 | 13605-31210 | SCREW L,M,A,B | 2 |
| 13410-34600 | LEVER L,M,A,B | ||
| 13615-33610 | WASHER L,M,A,B | ||
| 13433-33600 | SCREW L,M,A,B | ||
| 13432-33600 | WASHER L,M,A,B | ||
| 13615-33600 | WASHER L,M,A,B | ||
| 13434-33110 | SPRING L,M,A,B | ||
| 1 | 13435-33110 | STEEL BALL L,M,A,B | 1 |
| 13611-33110 | BOLT, FLANGE L,M,A,B | ||
| 13611-33620 | BOLT L,M,A,B | ||
| 13583-33110 | BOOT, THROTTLE ARM L,M,A,B | ||
| 13584-33110 | BOOT, THROTTLE LEVER L,M,A,B | ||
| 13550-33110 | SHAFT, CARBURETOR CONTROL L,M,A,B | ||
| 13683-33640 | HOSE, AIR VENT L,M,A,B; L:280 TO 13684-33111 | ||
| 1 | 13683-33610 | HOSE L,M,A,B; L:95 | 1 |
| 1 | 13683-33110 | HOSE, FUEL L,M,A,B; L:63 | 1 |
| 13683-33600 | HOSE L,M,A,B; L:38.5 | ||
| 4 | 13671-33110 | CLIP L,M,A,B | 4 |
| 13684-33600 | HOSE, AIR VENT L,M,A,B; L:32 | ||
| 13683-33620 | HOSE, STARTER L,M,A,B; L:33.5 | ||
| 1 | 13683-33650 | HOSE L,M,A,B; L:75 | 1 |
| 3 | 09491-77003 | JET, MAIN L,M,A,B; #77.5, OPT FROM 09491-77001 | 3 |
| 09491-82002 | JET, MAIN L,M,A,B; #82.5, OPT | ||
| 09344-03007 | HOSE, OVER FLOW L,M; L:120 TO 09344-03014 | ||
| 1 | 09344-03014 | HOSE, OVER FLOW A,B | 1 |
| 1 | 09344-03019 | HOSE, OVER FLOW L,M,A,B; L:190 FROM 09344-03017 | 1 |
| 09344-03010 | HOSE, OVER FLOW L,M,A; L:250 TO 09344-03019 | ||
| 1 | 09344-03019 | HOSE, OVER FLOW B; L:250 | 1 |
| 09403-00069 | CLAMP, OVER FLOW HOSE L,M,A,B |
