Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4639-597 | KIT, REVERSE - 19:39/13W | ||
| 1 | 0702-427 | Cover, Dropcase - w/O-Ring - REV (TUBE-DIP) | 1 |
| 0602-444 | Sprocket, 19T (Above 4,000 ft Alt.) | ||
| 1 | 0602-445 | Sprocket - 18T | 1 |
| 0123-641 | Washer, Fiber | ||
| 1 | 0702-415 | DROPCASE, W/STUDS-PTD | 1 |
| 0602-012 | Spacer | ||
| 1602-048 | Shaft, Extension | ||
| 0702-048 | Gear, 55T Reverse Assembly | ||
| 2 | 0602-023 | Washer, Thrust | 2 |
| 0602-022 | Bearing, Thrust | ||
| 1 | 0602-024 | Ring, Retaining | 1 |
| 1 | 0602-028 | Spring, Return | 1 |
| 1 | 0702-372 | Retainer, Shaft | 1 |
| 1 | 8050-272 | Washer | 1 |
| 8002-231 | Screw, Cap-HH 3/8-16 X3.00 G5 Z&Y | ||
| 1 | 1602-041 | CHAIN, 70P - 13 WIDE | 1 |
| 1 | 1602-042 | CHAIN, 72P - 13 WIDE Not Included in Kit | 1 |
| 1 | 0602-094 | Shaft, Reverse | 1 |
| 1 | 0702-366 | Idler, Reverse - Assembly 19T | 1 |
| 1 | 0602-018 | Bearing | 1 |
| 1 | 0602-215 | Spacer, Reverse Idler | 1 |
| 1 | 8050-242 | Washer | 1 |
| 8002-130 | SCREW, CAP-HH 5/16-18 X .75 G5 Z&Y | ||
| 0702-553 | Bracket, chain Backing-WELDT | ||
| 0602-085 | Fork, Shift | ||
| 1 | 0702-350 | Shaft, Shift Fork | 1 |
| 0623-122 | Nut, Lock | ||
| 0602-021 | Seal, O-Ring | ||
| 1 | 0623-542 | Pin, Spring Coiled - Black | 1 |
| 1602-106 | Tube, Oil Level Stick | ||
| 1 | 0602-366 | Pin, Alignment | 1 |
| 1602-107 | Stick, Oil Level | ||
| 2 | 0602-198 | PLATE,FLANGE-BEARING (TRIANGLE) | 2 |
| 0702-260 | Idler, Reverse - Assembly 24T | ||
| 0702-147 | Idler, Reverse - Assembly 20T | ||
| 3 | 8041-426 | Nut, Hex - Thin Lock | 3 |
| 1 | 8050-252 | WASHER,FLAT- 5/16 X .875 X .063 Z&Y | 1 |
| 3 | 0623-317 | Stud | 3 |
| 1 | 0602-437 | Seal, Dropcase | 1 |
| 2 | 0623-117 | Bolt, Ribbed | 2 |
| 1 | 0623-231 | Washer, Spring | 1 |
| 1 | 0123-310 | Nut, Lock | 1 |
| 1 | 1602-151 | Cover, Oil Vent | 1 |
| 6 | 0623-081 | Screw, Self-Tapping | 6 |
| 0702-170 | Sprocket Assembly 39T | ||
| 1 | 0702-629 | SPROCKET, 44T-13W-ASSY | 1 |
| 1 | 0602-144 | Retainer, Spring | 1 |
| 3 | 0602-133 | Pin, Slip | 3 |
| 3 | 0602-138 | Spring, Compression - Reverse | 3 |
| 6 | 0623-182 | Screw, Machine | 6 |
| 0623-906 | Screw, Cap (International) | ||
| 6 | 0123-430 | Nut, Lock | 6 |
| 6 | 0623-392 | Nut, Lock | 6 |
| 1 | 0602-016 | Bearing | 1 |
| 1 | 0602-479 | Plug, Drain - Magnetic | 1 |
| 1 | 1702-180 | Kit, Replacement Bearing-7/8" | 1 |
| 1670-237 | Seal, O-Ring | ||
| 0623-293 | Plug, Drain | ||
| 1 | 1702-179 | Kit, Replacement Bearing-1" | 1 |
| 3 | 8050-247 | Washer | 3 |
| 9 | 8040-426 | Nut, Hex Lock - NYL 5/16-18 Z&Y | 9 |
| 1 | 8011-143 | Bolt, Carriage | 1 |
| 4 | 0123-523 | Bolt, Ribbed | 4 |
| 2 | 8011-139 | Screw, Cap | 2 |
| 9 | 0607-025 | O-Ring, Stud | 9 |
| 8002-134 | SCREW,CAP-HH 5/16-18 X1.25 G5 Z&Y | ||
| 4 | 8053-242 | Washer, External Tooth Lock | 4 |
| 1 | 8042-426 | NUT,5/16-18 HEX-REG-GR5 Z&Y | 1 |
| 1 | 1602-044 | Washer, Thrust | 1 |
| 1 | 1602-045 | Bearing | 1 |
| 8070-153 | Pin, Spring | ||
| 1602-046 | Washer, Tab Lock | ||
| 0605-014 | O-Ring | ||
| 0623-640 | Screw, Self-Tapping | ||
| 1 | 0623-786 | Screw, Self-Tapping | 1 |
| 1 | 0602-093 | SPACER,REV SHAFT-.647X.812X.300 THICK (International) | 1 |
| 2 | 0602-215 | Spacer, Reverse Idler (International) | 2 |
