Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 5HY#-223011-1001 | REAR CARGO BOX | 1 |
| 1 | 5HY#-223021-1002 | LH NERF BAR, CARGO BOX | 1 |
| 1 | 5HY#-223022-1000-0BA00 | DECO PLATE, LH CARGO BOX, MATTE TITANIUM GREY | 1 |
| 1 | 5HY#-223022-1000-0BA00 | DECO PLATE, LH CARGO BOX, MATTE TITANIUM GREY MATTE TITANIUM GREY | 1 |
| 1 | 5HY#-223022-1001-0RE00 | LH DECO PLATE, CARGO BOX, TT Camo TRUE TIMBER CAMO | 1 |
| 1 | 5HY#-223022-1000-0EK00 | DECO PLATE. LH CARGO BOX, ATHENS BLUE ATHENS BLUE | 1 |
| 1 | 5HY#-223023-1000 | RH SIDE PLATE, CARGO BOX | 1 |
| 1 | 5HY#-223024-1001-0BA00 | RH DECO PLATE, CARGO BOX | 1 |
| 1 | 5HY#-223024-1001-0BA00 | RH DECO PLATE, CARGO BOX MATTE TITANIUM GREY | 1 |
| 1 | 5HY#-223024-1000-0EK00 | DECO PLATE, RH CARGO BOX, AETHENS BLUE ATHENS BLUE | 1 |
| 1 | 5HY#-223024-1001-0RE00 | RH DECO PLATE, CARGO BOX, TT Camo TRUE TIMBER CAMO | 1 |
| 1 | 5HY#-223031-1001 | REAR PLATE, CARGO BOX | 1 |
| 1 | 5HY#-223032-1000 | REAR INNER PLATE, CARGO BOX | 1 |
| 1 | 5HY0-223033 | LATCH, TAILGATE | 1 |
| 1 | 5HY0-223034 | LATCH PLATE | 1 |
| 4 | 30910-0183220 | LOCK PIN | 4 |
| 2 | 5HY0-223036 | BLOCK | 2 |
| 12 | 7030-220113 | BOLT M8X20 M8x20 | 12 |
| 6 | 8030-040800-00001 | NUT CLIP M6 M6 | 6 |
| 27 | 30110-480160010 | TAPPING SCREW ST4.8X16 ST4.8x16 | 27 |
| 1 | 5HY0-223013 | RIGHT FENDER, CARGO BOX | 1 |
| 1 | 5HY0-223012 | LEFT FENDER, CARG BOX | 1 |
| 6 | 30006-060016870 | BOLT M6x16 M6x16 | 6 |
| 6 | 9060-040310 | PUSH RIVET | 6 |
| 11 | 5020-040049 | CLAMP ST4.8 ST4.8 | 11 |
| 2 | 7030-222253 | DAMPER | 2 |
| 2 | 5HY0-220002 | LATCH BAR, TAILGATE | 2 |
| 2 | 5HY0-220003 | TORSION SPRING | 2 |
| 2 | 5HY0-223035 | SLEEVE, LATCH ROD | 2 |
| 2 | 8010-000004 | BOLT M6×14 M6x14 | 2 |
| 1 | 5HY0-221000-10000 | CARGO BOX, FRAME ASSY | 1 |
| 1 | 30211-123810 | NUT M12x1.5 | 1 |
| 2 | 9030-220011 | PIN SHAFT,ROTATION | 2 |
| 12 | 30006-060020870 | BOLT M6x20 M6x20 | 12 |
| 4 | 30006-080055810 | BOLT M8x55 | 4 |
| 4 | 7030-221123 | COLLAR, ROTATE SHAFT | 4 |
| 2 | 7030-222251 | PIN SHAFT,GAS SPRING | 2 |
| 4 | 9030-220004 | HOOK,BAND | 4 |
| 4 | 7030-221140 | MOUNTING BRACKET,HOOK | 4 |
| 4 | 7030-010508 | BOLT | 4 |
| 1 | 7030-010500-10000 | CABLE, TAILGATE | 1 |
| 2 | 30305-060112 | WASHER 6 | 2 |
| 1 | 5HY0-220007 | TORSION SPRING, RH | 1 |
| 1 | 5HY0-220006 | TORSION SPRING, LH | 1 |
| 1 | 5HY0-222080-30000 | BOX TILT STRUT | 1 |
| 2 | 5HY0-220004 | RUBBER BUMPER | 2 |
| 1 | 5HY0-220001-20000 | BRACKET, REAR LICENCE | 1 |
| 4 | 30006-060016870 | BOLT M6x16 M6x16 | 4 |
| 2 | 30006-080045810 | BOLT M8x45 | 2 |
| 6 | 5HY0-222010 | HOOK, CARGO BOX | 6 |
| 1 | 5HY0-222020 | LEFT BRACKET, TAILGATE | 1 |
| 1 | 5HY0-222030 | RIGHT BRACKET, TAILGATE | 1 |
| 1 | 5HY0-222040 | LEFT PROTECTION PLATE | 1 |
| 1 | 5HY0-222050 | RIGHT PROTECTION PLATE | 1 |
| 1 | 5HY0-222060 | LOCK, TAILGATE, LH | 1 |
| 1 | 5HY0-222070 | LOCK, TAILGATE, RH | 1 |
| 1 | 5HY0-222110 | DUMP BOX SHAFT, LH | 1 |
| 1 | 5HY0-222120 | DUMP BOX SHAFT, RH | 1 |
| 2 | 7030-220104 | SLEEVE, ROTATE | 2 |
| 6 | 30006-080020810 | BOLT M8×20 M8x20 | 6 |
| 8 | 30204-080810 | NUT M8 M8 | 8 |
