Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | Q810-310000-00002 | FRONT GEAR CASE ASSY | 1 |
| 1 | 0180-312005-0050 | WASHER | 1 |
| 1 | 0180-312006 | O-RING 14X6.8 14x6.8 | 1 |
| 1 | 0181-312007-0050 | COUPLER | 1 |
| 1 | 0180-312002 | OIL SEAL 48X65X9 48x65x9 | 1 |
| 1 | Q810-311003 | RETAINER,BEARING | 1 |
| 1 | 30400-02502 | BEARING,BALL CHINA | 1 |
| 1 | 0180-310006-0003 | ADJUST SHIM 61X53X0.4 ADJUSTING WASHER 61x53x0.4 | 1 |
| 1 | 0180-310006-0002 | ADJUST SHIM 61X53X0.3 ADJUSTING WASHER 61x53x0.3 | 1 |
| 1 | 0180-310006-0001 | ADJUST SHIM 61X53X0.2 ADJUSTING WASHER 61x53x0.2 | 1 |
| 1 | 0180-310006 | ADJUST SHIM 61X53X0.1 ADJUSTING WASHER 61x53x0.1 | 1 |
| 1 | 0180-310006-0005 | ADJUST SHIM 61X53X1.0 ADJUSTING WASHER 61x53x1.0 | 1 |
| 1 | 0180-310006-0004 | ADJUST SHIM 61X53X0.5 ADJUSTING WASHER 61x53x0.5 | 1 |
| 1 | Q810-3100A0 | RING AND PINION SET | 1 |
| 1 | 30499-01502 | NEEDLE BEARING F1512 | 1 |
| 1 | Q810-311001-00002 | FRONT GEAR CASE HOUSING | 1 |
| 2 | 0180-021008-00001 | BOLT M14×1.25×12 M14x1.25x12 | 2 |
| 2 | 0180-011006 | WASHER 14 14 | 2 |
| 1 | 0180-311004-0020 | JOINT , BREATHER HOSE | 1 |
| 2 | 0180-311001 | OIL SEAL 24X38X8 24x38x8 | 2 |
| 1 | 30130-080010820 | SCREW M8×10 M8x10 | 1 |
| 1 | 0180-310002 | PIN SHAFT | 1 |
| 4 | 30102-080020810 | SCREW M8x20 M8x20 | 4 |
| 1 | Q800-314000 | GEAR MOTOR SUMITOMO PLUG | 1 |
| 1 | 0180-310001 | O-RING 81.2×1.9 81.2x1.9 | 1 |
| 1 | 0180-315000 | SHIFT FORK | 1 |
| 1 | 30400-03501 | BEARING,BALL 16007 | 1 |
| 1 | 30800-06200 | RETAINER 62 62 | 1 |
| 1 | 0180-311003-0050 | DRIVE CLUTCH COVER | 1 |
| 1 | 0180-310003-0050 | DRIVE CLUTCH | 1 |
| 1 | 0180-310004-0003 | ADJUST SHIM 83X71X0.4 ADJUSTING WASHER 83x71x0.4 | 1 |
| 1 | 0180-310004 | ADJUST SHIM 83X71X0.1 ADJUSTING WASHER 83x71x0.1 | 1 |
| 1 | 0180-310004-0001 | ADJUST SHIM 83X71X0.2 ADJUSTING WASHER 83x71x0.2 | 1 |
| 1 | 0180-310004-0002 | ADJUST SHIM 83X71X0.3 ADJUSTING WASHER 83x71x0.3 | 1 |
| 1 | 0180-310004-0005 | ADJUST SHIM83X71X1.0 ADJUSTING WASHER 83x71x1.0 | 1 |
| 1 | 0180-310004-0004 | ADJUST SHIM 83X71X0.5 ADJUSTING WASHER 83x71x0.5 | 1 |
| 1 | 30499-06000 | BEARING BALL 61912 | 1 |
| 1 | 30906-0503000 | PIN 5x30 | 1 |
| 1 | 0180-313002-10000 | GEAR SHAFT(CENTER),DIFF | 1 |
| 1 | Q810-313002-10000 | FRONT DIFFERENTIAL CARRIER | 1 |
| 1 | 0180-313001-00001 | DRIVE GEAR,DIFFERENTIAL | 1 |
| 2 | 0181-313011 | WEARING RING | 2 |
| 2 | 0180-313003-00004 | BEVEL GEAR, DIFFERENTIAL SURFACE PEENING TREATMENT, THE INNER HOLE TOLERANCE INCREASING | 2 |
| 1 | 0180-313006-00001 | DRIVEN GEAR,DIFFERENTIAL | 1 |
| 1 | 0180-313009-0010 | SHIM | 1 |
| 1 | 0180-313005-10000 | WASHER | 1 |
| 1 | 0180-313010-0003 | ADJUST SHIM 57X40X0.4 ADJUST GASKET57x40x0.4 | 1 |
| 1 | 0180-313010-0004 | ADJUST SHIM 57X40X0.5 ADJUST GASKET 57x40x0.5 | 1 |
| 1 | 0180-313010-0002 | ADJUST SHIM 57X40X0.3 ADJUST GASKET 57x40x0.3 | 1 |
| 1 | 0180-313010-0005 | ADJUST SHIM 57X40X1.0 ADJUST GASKET57x40x1.0 | 1 |
| 1 | 0180-313010-0001 | ADJUST SHIM 57X40X0.2 ADJUST GASKET57x40x0.2 | 1 |
| 1 | 0180-313010 | ADJUST SHIM 57X40X0.1 ADJUSTING WASHER 57x40x0.1 | 1 |
| 7 | 0180-310100-0010 | BOLT M8X28 M8x28 | 7 |
| 1 | Q810-310001-10002 | GEAR CASE COVER | 1 |
| 1 | 0180-310005 | O-RING 141X2.4 141x2.4 | 1 |
| 1 | 30400-03502 | BEARING BALL 6007 | 1 |
| 6 | 0180-313100-0010 | BOLT M10X1.25X18 M10x1.25x18 | 6 |
| 1 | 0180-312004-0010 | NUT M14X1.5 M14x1.5 | 1 |
| 1 | 30601-108010 | CLAMP A8 A8 | 1 |
| 1 | 9010-310001 | BREATHER HOSE,FRONT DIFFERENTIAL | 1 |
