Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 10 | 8010-000004 | BOLT M6×14 M6x14 | 10 |
| 1 | 5HYV-041011-1000 | PANEL, FRONT BUMPER | 1 |
| 21 | 30006-060016870 | BOLT M6x16 M6x16 | 21 |
| 37 | 9060-040310 | PUSH RIVET | 37 |
| 1 | 5HY0-041012 | DECO GRID | 1 |
| 1 | 5HY0-041041-0RE00 | FRONT PANEL, LH, TRUE TIMBER CAMO TRUE TIMBER CAMO | 1 |
| 1 | 5HY0-041041-0EK00 | FRONT PANEL, LH, ATHENS BLUE ATHENS BLUE | 1 |
| 1 | 5HY0-041041-0BA00 | FRONT PANEL, LH, MATT TITANIUM GREY MATTE TITANIUM GREY | 1 |
| 1 | 5HY0-041042-0BA00 | FRONT PANEL MIDDLE, MATT TITANIUM GREY MATTE TITANIUM GREY | 1 |
| 1 | 5HY0-041042-0RE00 | FRONT PANEL, MIDDLE, TRUE TIMBER CAMO TRUE TIMBER CAMO | 1 |
| 1 | 5HY0-041042-0EK00 | FRONT PANEL, MIDDLE, ATHENS BLUE ATHENS BLUE | 1 |
| 1 | 5HY0-041043-0BA00 | FRONT PANEL, RH, MATT TITANIUM GREY MATTE TITANIUM GREY | 1 |
| 1 | 5HY0-041043-0RE00 | FRONT PANEL, RH, TRUE TIMBER CAMO TRUE TIMBER CAMO | 1 |
| 1 | 5HY0-041043-0EK00 | FRONT PANEL, RH, ATHENS BLUE ATHENS BLUE | 1 |
| 21 | 8030-040800-00001 | NUT CLIP M6 M6 | 21 |
| 1 | 5HY0-041052-0EK00 | FRONT DECO PANEL, RH, ATHENS BLUE ATHENS BLUE | 1 |
| 1 | 5HY0-041052-0RE00 | FRONT DECO PLATE, RH, TRUE TIMBER CAMO TRUE TIMBER CAMO | 1 |
| 1 | 5HY0-041052-0BA00 | FRONT DECO PATE, RH, MATT TITANIUM GREY MATTE TITANIUM GREY | 1 |
| 7 | 0180-015003 | RUBBER COLLAR | 7 |
| 1 | 5HY0-041062 | FRONT FENDER FLARE, RH | 1 |
| 17 | 5020-040049 | CLAMP ST4.8 ST4.8 | 17 |
| 1 | 5HY0-041031 | FRONT INNER FIXED PLATE. (TRUCK FREIGHT) | 1 |
| 1 | 5HY0-041061 | FRONT FENDER FLARE, LH | 1 |
| 1 | 5HY0-041021 | PANEL, HEADLIGHT, (TRUCK FREIGHT) | 1 |
| 1 | 5HY0-041051-0RE00 | FRONT DECO PLATE LH, TRUE TIMBER CAMO TRUE TIMBER CAMO | 1 |
| 1 | 5HY0-041051-0EK00 | FRONT DECO PLATE, LH, ATHENS BLUE ATHENS BLUE | 1 |
| 1 | 5HY0-041051-0BA00 | FRONT DECO PLATE, LH, MATT TITANIUM GREY MATTE TITANIUM GREY | 1 |
| 1 | 5HY0-041022 | GUARD, LEFT HEADLIGHT | 1 |
| 1 | 5HY0-041023 | GUARD, RIGHT HEADLIGHT | 1 |
| 1 | 5HY0-190220 | CFMOTO LABEL | 1 |
| 1 | 7030-190001 | CFMOTO LOGO BIG | 1 |
| 1 | 5HYV-043011-1C00 | UPPER BODY, DASHBOARD | 1 |
| 1 | 5HY0-043031 | DASHBOARD, LOWER. (TRUCK FREIGHT) | 1 |
| 1 | 5HYV-043041-1H00 | FRONT FENDER | 1 |
| 1 | 5HY0-043042 | FRONT INNER FENDER, LH | 1 |
| 1 | 5HY0-043043 | FRONT INNER FENDER, RH | 1 |
| 1 | 5HY#-041053-1000 | FRONT PANEL, LH | 1 |
| 1 | 5HY#-041054-1000 | FRONT PANEL, RH | 1 |
| 1 | 5HY0-043021 | AIR OUTLET PORT, LH | 1 |
| 1 | 5HY0-043022 | AIR OUTLET PORT, RH | 1 |
| 1 | 5HY0-043023 | FRONT AIR OUTLET PORT, LH | 1 |
| 1 | 5HY0-043024 | FRONT AIR OUTLET PORT, RH | 1 |
| 1 | 8060-040200 | AIR INLET PORT | 1 |
| 1 | 5HY0-043012 | HOLDER | 1 |
| 1 | 5HY0-043013 | STORAGE BOX COVER | 1 |
| 1 | 5HY0-043014 | STORAGE BOX | 1 |
| 2 | 5HY0-043015 | SPRING | 2 |
| 1 | 5HY0-043016-00001 | STORAGE BOX | 1 |
| 1 | 5HY0-043017 | SWITCH PANEL | 1 |
| 16 | 8080-000001 | CLASP | 16 |
| 7 | 8010-000002 | CLAMP ST4.2 ST4.2 | 7 |
| 20 | 30110-480160010 | TAPPING SCREW ST4.8X16 ST4.8x16 | 20 |
| 5 | 0180-015003 | RUBBER COLLAR | 5 |
| 7 | 8010-000004 | BOLT M6×14 M6x14 | 7 |
| 14 | 8030-040800-00001 | NUT CLIP M6 M6 | 14 |
| 2 | 30204-060810 | NUT M6 M6 | 2 |
| 9 | 9060-040310 | PUSH RIVET | 9 |
| 2 | 5020-040049 | CLAMP ST4.8 ST4.8 | 2 |
| 2 | 30006-060020870 | BOLT M6x20 M6x20 | 2 |
| 1 | 5HY0-043033 | GLOVE BOX | 1 |
| 1 | 5HY0-043081 | COVER, DASHBOARD | 1 |
| 1 | 5HY0-043044 | FRONT INNER FENDER | 1 |
| 6 | 6NQ#-000202-6001 | BOLT | 6 |
