Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 5BY0-042031 | FLOOR PAN | 1 |
| 21 | 30006-060016870 | BOLT M6x16 M6x16 | 21 |
| 10 | 30309-060870 | WASHER 6X20X1.5 6X20X1.5 | 10 |
| 2 | 30110-480130010 | TAPPING SCREW ST4.8×13 ST4.8x13 | 2 |
| 2 | 5BYV-042032-AD00 | PEDAL PLUG | 2 |
| 1 | 5BY0-043034-10000 | REAR PART, RH FRONT WHEEL FENDER | 1 |
| 1 | 5BY0-043033-10000 | REAR PART, LH FRONT WHEEL FENDER | 1 |
| 32 | 9060-040310 | PUSH RIVET | 32 |
| 1 | 5BY0-041027 | RH DAMPING DECO PLATE | 1 |
| 1 | 5BY0-041026 | LH DAMPING DECO PLATE | 1 |
| 1 | 5BY0-042023 | RH FRONT FENDER | 1 |
| 1 | 5BY0-042022 | LH FRONT FENDER | 1 |
| 2 | 30110-421130010 | SELF TAPPING SCREW ST4.2x13 | 2 |
| 1 | 5BY0-041037 | RH RUBBER SUPPORTER, HEADLIGHT PANEL | 1 |
| 1 | 5BY0-041036 | LH RUBBER SUPPORTER, HEADLIGHT PANEL | 1 |
| 1 | 5BY0-042021 | FIREWALL | 1 |
| 7 | 5BY0-000301 | NUT CLIP M6 | 7 |
| 1 | 5BY0-042024 | RUBBER, FRONT FENDER | 1 |
| 1 | 5BY0-042025 | PLUG, THROTTLE CABLE | 1 |
| 2 | 6100-030004 | RUBBER CAP, LH | 2 |
| 1 | 5BY0-042033 | REAR PART, LH FRONT WHEEL FENDER | 1 |
| 1 | 5BY0-042015 | STORAGE BOX COVER | 1 |
| 1 | 5BY0-042044 | GEARSHIFT COVER | 1 |
| 31 | 30110-421130010 | SELF TAPPING SCREW ST4.2x13 | 31 |
| 1 | 5BY0-042046 | SHADING RUBBER, GEARSHIFT LEVER | 1 |
| 1 | 5BY0-042043-0H300 | MIDDLE PROTECTION COVER | 1 |
| 6 | 8010-000002 | CLAMP ST4.2 ST4.2 | 6 |
| 4 | 8030-040800-00001 | NUT CLIP M6 M6 | 4 |
| 1 | 5BY0-042042 | MIDDLE RH PANEL | 1 |
| 1 | 5BY0-042041 | MIDDLE LH PANEL | 1 |
| 29 | 9060-040310 | PUSH RIVET | 29 |
| 4 | 30006-060016870 | BOLT M6x16 M6x16 | 4 |
| 6 | 30110-420130070 | SELF-TAPPING SCREW ST4.2x13-C-H ST4.2x13-C-H | 6 |
| 1 | 5BY0-042018 | RH ROTATION SHAFT, STORAGE BOX | 1 |
| 1 | 5BY0-042017 | LH ROTATION SHAFT, STORAGE BOX | 1 |
| 1 | 5BY0-042014-0H900 | LOWER BRACKET,SWITCH, GHOST GRAY GHOST GRAY | 1 |
| 2 | 30305-060112 | WASHER 6 | 2 |
| 1 | 5BY0-042011 | DASHBOARD PANEL | 1 |
| 1 | 5BY0-042019 | SEAL STRAP, STORAGE BOX | 1 |
| 1 | 5BY0-042016 | REINFORCEMENT PLATE, STORAGE BOX | 1 |
| 1 | 5BY0-042012 | IGNITION SWITCH CAP (KEY) | 1 |
| 1 | 5BY0-042052 | FRONT PANEL, RH SEAT | 1 |
| 1 | 5BY0-042051 | FRONT PANEL, LH SEAT | 1 |
| 52 | 9060-040310 | PUSH RIVET | 52 |
| 2 | 30309-060870 | WASHER 6X20X1.5 6X20X1.5 | 2 |
| 8 | 30006-060016870 | BOLT M6x16 M6x16 | 8 |
| 1 | 5BY0-041075 | MIDDLE RH PANEL, SEAT | 1 |
| 1 | 5BY0-041074 | MIDDLE LH PANEL, SEAT | 1 |
| 1 | 5BY0-041052 | RH FRONT SIDE PANEL | 1 |
| 1 | 5BY0-041051 | LH FRONT SIDE PANEL | 1 |
| 4 | 8010-000004 | BOLT M6×14 M6x14 | 4 |
| 10 | 8030-040800-00001 | NUT CLIP M6 M6 | 10 |
| 1 | 5BY0-041054 | RH REAR SIDE PANEL | 1 |
| 1 | 5BY0-041053 | LH REAR SIDE PANEL | 1 |
| 2 | 30006-060025810 | BOLT M6x25 | 2 |
| 1 | 5BY0-041073 | RH PANEL, SEAT | 1 |
| 1 | 5BY0-041072 | LH PANEL, SEAT | 1 |
| 4 | 5BY0-041055 | PLUG, FRONT SIDE PANEL | 4 |
