Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 94400-48C00-33J | BODY ASSY, COWLING (BLACK) CLEAR COATING | ||
| 94400-48C01-33J | BODY ASSY, COWLING (BLACK) ->94400-48C00-33J; Includes Item(s) 2 - 3 | ||
| 68180-48B30-3BD | TAPE SET | ||
| 68185-05C10-12R | EMBLEM | ||
| 94510-48B11 | BRACE | ||
| 94510-48B21 | BRACE CALIFORNIA ONLY | ||
| 94611-48B40 | WIND SCREEN | ||
| 09103-10195 | BOLT, BRACE FRONT | ||
| 2 | 07110-08165 | BOLT, BRACE REAR | 2 |
| 2 | 09139-06028 | SCREW, BODY REAR | 2 |
| 2 | 09160-06056 | WASHER (6.5X18X1) | 2 |
| 2 | 09180-06152 | SPACER | 2 |
| 2 | 09320-09016 | CUSHION | 2 |
| 2 | 09139-06030 | SCREW, LOWER | 2 |
| 2 | 02142-06127 | SCREW, SET | 2 |
| 94700-48B10-291 | PANEL ASSY, RH (BLACK) Includes Item(s) 15 - 16 | ||
| 1 | 02142-05084 | SCREW | 1 |
| 1 | 94419-48B10 | MOLDING | 1 |
| 94800-48B10-291 | PANEL ASSY, LH (BLACK) Includes Item(s) 18 - 19 | ||
| 2 | 02142-05124 | SCREW | 2 |
| 2 | 09148-05020 | NUT | 2 |
| 4 | 03241-05125 | SCREW, UPPER | 4 |
| 09403-18406 | CLAMP | ||
| 94426-48B10 | CAP, RH | ||
| 1 | 94427-48B10 | CAP, LH | 1 |
| 94591-48B10 | MOLDING, PANEL RH | ||
| 94592-48B10 | MOLDIMG. PANEL LH | ||
| 1 | 94419-48B00 | MOLDING, FRONT | 1 |
| 94439-48B00 | MOLDING, SIDE Includes Item(s) 31 - 32 | ||
| 94651-48B00 | COVER | ||
| 94479-48B00 | MOLDING (L:325) | ||
| 97600-48C01-33J | COVER ASSY, LOWER RH (BLACK) CLEAR COATING | ||
| 97600-48C02-33J | COVER ASSY, LOWER RH (BLACK) ->97600-48C01-33J | ||
| 97600-48B91-33J | COVER ASSY, LOWER RH (BLACK) CALIFORNIA ONLYCLEAR COATING | ||
| 97600-48B92-33J | COVER ASSY, LOWER RH (BLACK) CALIFORNIA ONLY->97600-48B91-33J; Includes Item(s) 34 - 37 | ||
| 68191-48B20-3BJ | EMBLEM | ||
| 68685-48B30-3BD | TAPE, RH | ||
| 94479-48B10 | MOLDING (L:210) | ||
| 94473-48B10 | MOLDING CALIFORNIA ONLY | ||
| 97700-48C01-33J | COVER ASSY, LOWER LH (BLACK) CLEAR COATING | ||
| 97700-48C02-33J | COVER ASSY, LOWER LH (BLACK) ->97700-48C01-33J | ||
| 97700-48B91-33J | COVER ASSY, LOWER LH (BLACK) CALIFORNIA ONLYCLEAR COATING | ||
| 97700-48B92-33J | COVER ASSY, LOWER LH (BLACK) CALIFORNIA ONLY->97700-48B91-33J; Includes Item(s) 39 - 42 | ||
| 68695-48B30-3BD | TAPE, LH | ||
| 94475-48B00-33J | COVER, LOWER FRONT (BLACK) CLEAR COATING | ||
| 94475-48B01 | COVER, LOWER FRONT (BLACK) | ||
| 2 | 09139-05025 | SCREW (5X14) | 2 |
| 2 | 08316-26055 | NUT | 2 |
| 94490-06B00 | BRACE, LOWER | ||
| 94493-06B00 | BRACE, LOWER REAR | ||
| 1 | 09139-06027 | SCREW, FRONT | 1 |
| 6 | 09139-06039 | SCREW, R & L | 6 |
| 94580-48B11 | BRACE, LOWER RH | ||
| 94590-48B11 | BRACE, LOWER LH | ||
| 2 | 01107-08127 | BOLT | 2 |
| 2 | 08321-21088 | LOCK WASHER | 2 |
| 2 | 09139-06028 | SCREW, UPPER REAR | 2 |
| 4 | 09139-06030 | SCREW | 4 |
| 6 | 09161-07005 | WASHER | 6 |
| 2 | 09139-06028 | SCREW | 2 |
| 2 | 09180-06121 | SPACER | 2 |
| 1 | 68612-48B00 | LABEL, SCREEN | 1 |
