Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8HV-F3711-00-00 | SKI 1 | |
| 2 | 8HG-F3712-20-00 | REINFORCEMENT, HEAD | 2 |
| 3 | 8EX-F3754-00-00 | COLLAR 1 | |
| 4 | 8HG-F3731-00-00 | SMA-8HG11-00-00 | |
| 5 | 8EK-F3751-00-00 | BUSH, SKI 1 | 8 |
| 6 | 8HG-F3755-00-00 | BOLT, REINFORCEMENT HEAD 1 | 2 |
| 7 | 8HG-F3756-10-00 | BOLT, REINFORCEMENT HEAD 2 | |
| 8 | 8HG-F3737-00-00 | WASHER 1 | 8 |
| 9 | 8HG-F3738-00-00 | WASHER 2 | |
| 10 | 8HG-F3778-00-00 | NUT | 12 |
| 11 | 90105-10070-00 | BOLT, FLANGE | 2 |
| 12 | 95607-10200-00 | NUT, U FLANGE | 2 |
| 13 | 90387-1012H-00 | COLLAR | 2 |
| 14 | 91401-20020-00 | PIN, COTTER | 2 |
| 15 | 8HG-23743-00-00 | STOPPER 1 | 2 |
| 16 | 8HG-23501-00-00 | STEERING KNUCKLE ASSY (LEFT) | 1 |
| 17 | 90381-25115-00 | BUSH, SOLID | 1 |
| 18 | 90381-32001-00 | BUSH, SOLID | 1 |
| 19 | 90381-15N50-00 | BUSH, SOLID | 2 |
| 20 | 90381-18N51-00 | BUSH, SOLID | 2 |
| 21 | 93700-06004-00 | NIPPLE, GREASE | 1 |
| 22 | 8HG-23502-00-00 | STEERING KNUCKLE ASSY (RIGHT) | 1 |
| 23 | 90381-25115-00 | BUSH, SOLID | 1 |
| 24 | 90381-32001-00 | BUSH, SOLID | 1 |
| 25 | 90381-15N50-00 | BUSH, SOLID | 2 |
| 26 | 90381-18N51-00 | BUSH, SOLID | 2 |
| 27 | 93700-06004-00 | NIPPLE, GREASE | 1 |
| 28 | 8HG-23803-00-00 | COLUMN, SKI ASSY | 2 |
| 29 | 90384-16N51-00 | BUSH, BIMETAL FORMED | 2 |
| 30 | 8FA-23851-00-00 | ARM, OUTSIDE 1 | 1 |
| 31 | 8FA-23852-00-00 | ARM, OUTSIDE 2 | 1 |
| 32 | 90110-08104-00 | BOLT, HEXAGON SOCKET HEAD | 2 |
| 33 | 95602-08200-00 | NUT, SELF-LOCKING | 2 |
| 34 | 3YK-22472-40-00 | CAP, CASE | 2 |
| 35 | 8HG-23540-00-00 | FRONT UPPER ARM COMP. | 2 |
| 36 | 90381-15N50-00 | BUSH, SOLID | 2 |
| 37 | 93700-06004-00 | NIPPLE, GREASE | 1 |
| 38 | 90105-10230-00 | BOLT, FLANGE | 2 |
| 39 | 95602-10200-00 | NUT, U FLANGE | 2 |
| 40 | 90387-10099-00 | COLLAR | 2 |
| 41 | 90201-10052-00 | WASHER, PLATE | 4 |
| 42 | 90109-10056-00 | BOLT | 2 |
| 43 | 95602-10200-00 | NUT, U FLANGE | 2 |
| 44 | 90201-10052-00 | WASHER, PLATE | 2 |
| 45 | 90209-15N50-00 | WASHER | 4 |
| 46 | 8HG-23570-00-00 | FRONT LOWER ARM COMP. (LEFT) | 1 |
| 47 | 90381-16N51-00 | BUSH, SOLID | 2 |
| 48 | 93700-06004-00 | NIPPLE, GREASE | 1 |
| 49 | 8HG-23580-00-00 | FRONT LOWER ARM COMP. (RIGHT) | 1 |
| 50 | 90381-16N51-00 | BUSH, SOLID | 2 |
| 51 | 93700-06004-00 | NIPPLE, GREASE | 1 |
| 52 | 90105-12078-00 | BOLT, FLANGE | 2 |
| 53 | 95602-12200-00 | NUT, SELF-LOCKING | 2 |
| 54 | 90387-12054-00 | COLLAR | 2 |
| 55 | 90201-120T5-00 | WASHER, PLATE | 4 |
| 56 | 90401-10045-00 | BOLT, UNION | 2 |
| 57 | 93700-06004-00 | NIPPLE, GREASE | 2 |
| 58 | 95602-10200-00 | NUT, U FLANGE | 2 |
| 59 | 90201-10052-00 | WASHER, PLATE | 2 |
| 60 | 90209-15N50-00 | WASHER | 4 |
| 61 | 8HG-2376A-00-00 | ABSORBER ASSY 1 | 2 |
| 62 | 90384-15N51-00 | BUSH, BIMETAL FORMED | 2 |
| 63 | 8FA-2331R-00-00 | DAMPER, BUSH B | 1 |
| 64 | 4AA-22259-70-00 | LABEL, WARNING | 1 |
| 65 | 90105-10232-00 | BOLT, FLANGE | 2 |
| 66 | 90105-10288-00 | BOLT, FLANGE | 2 |
| 67 | 95602-10200-00 | NUT, U FLANGE | 4 |
| 68 | 90387-10N59-00 | COLLAR | 2 |
| 69 | 90201-10052-00 | WASHER, PLATE | 4 |
| 70 | 8FG-2386E-10-00 | BAR, STABILIZER FRONT | 1 |
| 71 | 8FG-2386G-00-00 | BUSH, STABILIZER FRONT | 2 |
| 72 | 8FG-2386L-00-00 | ARM, STABILIZER | 2 |
| 73 | 8ES-2385L-00-00 | JOINT, STABILIZER 1 | 2 |
| 74 | 90101-06046-00 | BOLT | 2 |
| 75 | 95604-06200-00 | NUT, U FLANGE | 2 |
| 76 | 95814-08030-00 | BOLT, FLANGE | 4 |
| 77 | 95604-08200-00 | NUT, U FLANGE | 4 |
