Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 300 | 710008815 | Main Wiring Harness | 1 |
| 300a | 710007680 | Connector Guard | 1 |
| 4x4 | 293550070 | Dielectric Grease | |
| 4x4 | 710002000 | Housing | 1 |
| 4x4 | 710003047 | Terminal | 1 |
| 4x4 | 710005491 | Female Terminal | 1 |
| BAT1 | 710002576 | Heat Shrink | |
| BAT1 | 710006004 | Open Barell | |
| BAT2 | 710002577 | Heat Shrink | |
| BAT2 | 710000475 | TERMINAL_FEMALE | 1 |
| BN1 | 710002589 | Heat Shrink | |
| BN1 | 278001392 | Open Barrel Terminal | 1 |
| BP1 | 515177246 | Shrink Tubing, 6 mm | 1 |
| BP1 | 278000992 | Open Barrel | 1 |
| BP2 | 710002577 | Heat Shrink | |
| BP2 | 710000530 | Open Barrel | |
| BP2 | 278002266 | Rubber Boot | |
| CL | 278002858 | Female Housing 20 Circuits | 1 |
| CL | 515178018 | Female Terminal | 1 |
| CL | 515178349 | Female Terminal 22 AWG | 1 |
| D2 | 409012700 | Diode | 1 |
| DC1 | 293550070 | Dielectric Grease | |
| DC1 | 710005373 | Housing | 1 |
| DC1 | 710005952 | Female Terminal | 1 |
| DC3 | 515175658 | Female Housing, 2 Circuits | 1 |
| DC3 | 515175231 | Female Terminal | 1 |
| DC3_CAP | 710000667 | Male Housing, 2 Circuits | 1 |
| DESS. | 710007151 | Female Delphi Connector 5 Cavities | 1 |
| DESS. | 710007243 | Lock | 1 |
| DESS. | 710001163 | Wire Seal | 1 |
| DESS. | 710001164 | Female Terminal | 1 |
| DIFF | 710006076 | Label | 1 |
| DIFF | 293550070 | Dielectric Grease | |
| DIFF | 710002003 | Housing Connector | 1 |
| DIFF | 710005491 | Female Terminal | 1 |
| DIFF | 710003047 | Terminal | 1 |
| DLC | 710002706 | Female Housing 6 Circuits | 1 |
| DLC | 710002705 | Lock | 1 |
| DLC | 710005438 | Female Terminal | 1 |
| DLC | 710005439 | Female Terminal | 1 |
| DLC | 278001276 | FEMALE TERMINAL | |
| DPS | 293550070 | Dielectric Grease | |
| DPS | 710004989 | Female Housing | 1 |
| DPS | 710005098 | Lock | 1 |
| DPS | 710001222 | Lock | 1 |
| DPS | 710002075 | Plug | 1 |
| DPS | 278002186 | Wire Seal | 1 |
| DPS | 710003153 | Seal | 1 |
| DPS | 278002187 | Female Terminal | 1 |
| DPS | 710001765 | Terminal | |
| EVAP | 409209200 | Female Terminal Housing, 2 Circuits | |
| EVAP | 710000402 | Wire Seal | 1 |
| EVAP | 409012100 | Female Terminal | 1 |
| FL-1 | 710004226 | Fuse | |
| FL-2 | 710004227 | Fuse | |
| FP | 278002185 | Male Housing, 4 Circuits | 1 |
| FP | 710001222 | Lock | 1 |
| FP | 710006214 | Lock | 1 |
| FP | 278002186 | Wire Seal | 1 |
| FP | 710003153 | Seal | 1 |
| FP | 278002187 | Female Terminal | 1 |
| FP | 710001765 | Terminal | |
| FRA | 515175658 | Female Housing, 2 Circuits | 1 |
| FRA | 710003896 | Female Terminal | 1 |
| FRONT_HL_M | 409210100 | Clip Bracket Connector (edge) | 1 |
| FRONT_HL_M | 515177201 | Housing | 1 |
| FRONT_HL_M | 710006398 | Lock | 1 |
| FRONT_HL_M | 710001225 | Cap | 1 |
| FRONT_HL_M | 710001332 | Seal Wire | 1 |
| FRONT_HL_M | 710001233 | Seal | 1 |
| FRONT_HL_M | 710001223 | Terminal | 1 |
| FRONT_HL_M | 710001224 | Terminal | 1 |
| FT | 710000992 | Clip | 1 |
| FT | 278000217 | Female Housing, 2 Circuits | 1 |
| FT | 278000218 | Wire Seal | 1 |
| FT | 409004300 | Male Terminal | 1 |
| HIBM | 710006074 | Label | 1 |
| HIBM | 293550070 | Dielectric Grease | |
| HIBM | 710002000 | Housing | 1 |
| HIBM | 710003047 | Terminal | 1 |
| HIBM | 710005491 | Female Terminal | 1 |
| HIC | 710001930 | Female Housing, 12 Circuits | 1 |
| HIC | 710006333 | Lock | 1 |
| HIC | 710001222 | Lock | 1 |
| HIC | 710001225 | Cap | 1 |
| HIC | 710001332 | Seal Wire | 1 |
| HIC | 710001233 | Seal | 1 |
| HIC | 710001229 | Terminal | 1 |
| HIC | 710001228 | Terminal | 1 |
| HIC_FD_F | 710001132 | Housing | 1 |
| HIC_FD_F | 710001133 | Lock | 1 |
| HIC_FD_F | 278001482 | Seal | 1 |
| HIC_FD_F | 710001134 | Female Terminal | 1 |
| HIC5M_L | 710004988 | Clip | |
| HIC5M_L | 278000281 | Female Terminal Housing, 3 Circuits | 1 |
| HIC5M_L | 278001065 | Wire Seal | 1 |
| HIC5M_L | 278000222 | Male Terminal | 1 |
| JB-1 | 710006610 | Junction Block Cover | 1 |
| JB-1 | 710006609 | Junction Bloc | |
| JB-1 | 232561200 | Brass Elastic Stop Nut M6 | 1 |
| KEYPAD | 710001161 | Housing | 1 |
| KEYPAD | 710001162 | Lock | 1 |
| KEYPAD | 710001163 | Wire Seal | 1 |
| KEYPAD | 710001164 | Female Terminal | 1 |
| PF1 | 278003553 | Fuse Cover | 1 |
| PF1 | 278003448 | Fuse Base Ass'y | 1 |
| PF1 | 710005671 | Housing Support | 1 |
| PF1 | 278000216 | Wire Seal | 1 |
| PF1 | 293300198 | Seal | 1 |
| PF1 | 278000218 | Wire Seal | 1 |
| PF1 | 710000048 | Wire Seal | 1 |
| PF1 | 278001065 | Wire Seal | 1 |
| PF1 | 515177177 | Female Terminal | 1 |
| PF1 | 710000918 | Female Terminal | 1 |
| PF1 | 278002578 | Female Terminal | 1 |
| PF1_STD_LABEL | 710008884 | Fuses Decal | 1 |
| PF1-F11 | 710000746 | Little Fuse, 20 Amperes | 1 |
| PF1-F12 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF1-F14 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF1-F16 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF1-R3 | 515176774 | Relay, 30 AMP | 1 |
| PF1-R4 | 710001778 | Relay | 1 |
| PF1-R8 | 710001778 | Relay | 1 |
| PF1-R9 | 515176774 | Relay, 30 AMP | 1 |
| PF1-SP1 | 710000746 | Little Fuse, 20 Amperes | 1 |
| PF2 | 278003553 | Fuse Cover | 1 |
| PF2 | 710006792 | Fuse Box Decal | 1 |
| PF2 | 278003448 | Fuse Base Ass'y | 1 |
| PF2 | 278000216 | Wire Seal | 1 |
| PF2 | 293300198 | Seal | 1 |
| PF2 | 278000218 | Wire Seal | 1 |
| PF2 | 278001065 | Wire Seal | 1 |
| PF2 | 710000918 | Female Terminal | 1 |
| PF2 | 278002578 | Female Terminal | 1 |
| PF2_SP1 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF2_SP2 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF2_SP3 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF2-F18 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF2-F4 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF2-F5 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF2-F6 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF2-F7 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF2-F8 | 710000744 | Little Fuse, 10 Amperes | 1 |
| PF2-F9 | 710002590 | Fuse, 25 Amps | 1 |
| PF2-R1 | 515176774 | Relay, 30 AMP | 1 |
| PF2-R2 | 710001778 | Relay | 1 |
| PF3 | 293550070 | Dielectric Grease | |
| PF3 | 278001325 | Fuse Holder | 1 |
| PF3 | 710000113 | Female Terminal | 1 |
| PF3-F2 | 710001613 | Fuse | 1 |
| PF4 | 293550070 | Dielectric Grease | |
| PF4 | 278001325 | Fuse Holder | 1 |
| PF4 | 710000113 | Female Terminal | 1 |
| PF4 | 710000357 | Female Terminal | 1 |
| PF4-F21 | 410917200 | Fuse, 30 Amperes | 1 |
| POST- | 710002576 | Heat Shrink | |
| POST- | 710000693 | Terminal | |
| POST_ACC | 515177246 | Shrink Tubing, 6 mm | 1 |
| POST_ACC | 278000992 | Open Barrel | 1 |
| POST_FL | 515177246 | Shrink Tubing, 6 mm | 1 |
| POST_FL | 278000992 | Open Barrel | 1 |
| POST+ | 710002576 | Heat Shrink | |
| POST+ | 710000693 | Terminal | |
| PPS_F | 710001232 | Housing | 1 |
| PPS_F | 710001222 | Lock | 1 |
| PPS_F | 710001233 | Seal | 1 |
| PPS_F | 710001229 | Terminal | 1 |
| SB | 710002177 | Housing | 1 |
| SB | 710002043 | Lock | 1 |
| SB | 278001482 | Seal | 1 |
| SB | 710001134 | Female Terminal | 1 |
| SPLICE_ST | 710001767 | Adhesive Tape | |
| SS | 515177192 | Female Housing, 2 Circuits | 1 |
| SS | 710001152 | Lock | 1 |
| SS | 710001163 | Wire Seal | 1 |
| SS | 710001164 | Female Terminal | 1 |
| STSW | 409209200 | Female Terminal Housing, 2 Circuits | |
| STSW | 710000402 | Wire Seal | 1 |
| STSW | 409012100 | Female Terminal | 1 |
| XCU_A | 515178602 | Cover | 1 |
| XCU_A | 515178618 | Housing 56 Circuits | 1 |
| XCU_A | 515178604 | Plate | 1 |
| XCU_A | 515178599 | Plug | 1 |
| XCU_A | 515178603 | Plate | 1 |
| XCU_A | 515178596 | Terminal | 1 |
| XCU_A | 515178598 | Terminal | 1 |
| XCU_A | 515178666 | Terminal | 1 |
