Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 24120-33E00 | SHAFT, COUNTER (NT:15) MODEL T/V | ||
| 24120-33E10 | SHAFT, COUNTER (NT:16) MODEL W/X | ||
| 24221-17E00 | GEAR, 2ND DRIVE (NT:17) MODEL T/V | ||
| 24221-33E50 | GEAR, 2ND DRIVE (NT:20) MDOEL W/X | ||
| 24231-33E00 | GEAR, 3RD & 4TH (NT:20/21) MODEL T/V | ||
| 24231-33E50 | GEAR, 3RD & 4TH (NT:23/22) MDOEL W/X | ||
| 24251-33E00 | GEAR, 5TH DRIVE (NT:23) MODEL T/V | ||
| 24251-33E50 | GEAR, 5TH DRIVE (NT:22) MODEL W/X | ||
| 24261-33E00 | GEAR, 6TH DRIVE (NT:25) MODEL T/V | ||
| 24261-33E50 | GEAR, 6TH DRIVE (NT:25) MODEL W/X | ||
| 24262-17E10 | BUSH, 6TH DRIVE GEAR | ||
| 1 | 09262-25051 | BEARING, CNTR RH 25X62X17 | 1 |
| 1 | 09263-20082 | BEARING, CNTR LH 20X34X17.5 | 1 |
| 1 | 09285-20006 | SEAL, OIL (20X31.2X2.7) | 1 |
| 1 | 09301-28001 | BUSH, 5TH DRIVE GEAR 28X32X2 | 1 |
| 1 | 09380-27001 | CIRCLIP, 5TH DRIVE | 1 |
| 1 | 09380-27001 | CIRCLIP, 6TH DRIVE | 1 |
| 1 | 09380-27004 | CIRCLIP, 2ND DRIVE | 1 |
| 1 | 09390-62012 | C RING | 1 |
| 1 | 04221-07209 | PIN, CNTR LH | 1 |
| 24131-33E00 | SHAFT, DRIVE | ||
| 24311-33E00 | GEAR, 1ST DRIVEN (NT:43) MODEL T/V | ||
| 24311-33E50 | GEAR, 1ST DRIVEN (NT:42) MODEL W/X | ||
| 24321-33E00 | GEAR, 2ND DRIVEN (NT:35) MODEL T/V | ||
| 24321-33E50 | GEAR, 2ND DRIVEN (NT:39) MDOEL W/X | ||
| 24331-33E00 | GEAR, 3RD DRIVEN (NT:33) MODEL T/V | ||
| 24331-33E50 | GEAR, 3RD DRIVEN (NT:36) MODEL W/X | ||
| 24332-17E10 | BUSH, 3RD DRIVEN GEAR | ||
| 24332-17E10 | BUSH, 4TH DRIVEN GEAR | ||
| 24341-33E00 | GEAR, 4TH DRIVEN (NT:30) MODEL T/V | ||
| 24341-33E50 | GEAR, 4TH DRIVEN (NT:30) MDOEL W/X | ||
| 24351-33E00 | GEAR, 5TH DRIVEN (NT:29) MODEL T | ||
| 24351-33E01 | GEAR, 5TH DRIVEN (NT:29) MODEL V | ||
| 24351-33E50 | GEAR, 5TH DRIVEN (NT:27) MDOEL W/X | ||
| 24361-33E00 | GEAR, 6TH DRIVEN (NT:28) MODEL T/V | ||
| 24361-33E50 | GEAR, 6TH DRIVEN (NT:28) MODEL W/X | ||
| 09167-27002 | WASHER, 3RD & 4TH DRIVEN | ||
| 1 | 09262-28025 | BEARING, DRIVE SHAFT,LH 28X70X18 | 1 |
| 1 | 09263-20040 | BEARING (20X34X20) 20X34X20 | 1 |
| 1 | 09283-36008 | SEAL, DRIVE SHAFT,OIL 36X70X6 | 1 |
| 1 | 09300-22008 | BUSH, 1ST DRIVEN GEAR 22X26X9 | 1 |
| 09300-28003 | BUSH, 2ND DRIVEN GEAR 28X32X9.5 | ||
| 1 | 09380-27001 | CIRCLIP, 2ND DRIVEN GEAR | 1 |
| 1 | 09380-27001 | CIRCLIP, 3RD DRIVEN GEAR | 1 |
| 1 | 09380-27001 | CIRCLIP, 4TH DRIVEN GEAR | 1 |
| 1 | 09390-70001 | C RING (67.6X75X2) | 1 |
| 1 | 04221-07209 | PIN, DRIVE SHAFT,RH | 1 |
| 1 | 08211-20341 | WASHER, 1ST,RH MODEL T | 1 |
| 1 | 09181-20251 | WASHER, 1ST,RH (20X34X1.0) MODEL V/W/X | 1 |
| 1 | 08211-22341 | WASHER, 1ST,LH MODEL T | 1 |
| 1 | 09181-22223 | WASHER, 1ST,LH (22X34X1.0) MODEL V/W/X | 1 |
| 1 | 08211-28381 | WASHER, 2ND GEAR MODEL T | 1 |
| 1 | 09181-28195 | WASHER, 2ND GEAR (28X38X1.0) MODEL V/W/X | 1 |
| 24751-33E00 | RETAINER, DRIVE SHAFT MODEL T/V | ||
| 24751-33E10 | RETAINER, DRIVE SHAFT MODEL W/X | ||
| 3 | 01500-06123 | BOLT, DRIVE SHAFT | 3 |
| 27510-21A00 | SPROCKET, ENGINE (NT:16) MODEL T | ||
| 27510-21A10 | SPROCKET, ENGINE (NT:16) MODEL V | ||
| 1 | 27510-20A10 | SPROCKET, ENGINE (NT:16) MODEL W/X | 1 |
| 27531-33E00 | SPACER, ENGINE SPROCKET | ||
| 27600-21E10-108 | CHAIN ASSY (RK50MF0Z1,108L) MODEL T/V; Includes Item(s) 44 | ||
| 27620-21E10 | JOINT SET, DRIVE CHAIN MODEL T/V | ||
| 1 | 27600-33E00-108 | CHAIN ASSY (RK525R0Z2,108L) MODEL W/X; Includes Item(s) 46 | 1 |
| 27620-33E00 | JOINT SET, DRIVE CHAIN MODEL W/X | ||
| 1 | 09159-20004 | NUT, ENGINE SPROCKET | 1 |
| 1 | 08211-25402 | WASHER, ENGINE SPROCKET MODEL T | 1 |
| 1 | 09181-25268 | WASHER (25X40X1.5) MODEL V | 1 |
| 1 | 09160-25009 | WASHER (25X41X3.0) MODEL W/X | 1 |
| SPECIAL NOTE | REVISED 1 OCT.,'98 |
