Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 708301587 | LH Trim Box Package CHROME | 1 |
| 1 | 708301859 | LH Trim Box Package DARK | 1 |
| 1 | 708301588 | RH Trim Box Package CHROME | 1 |
| 1 | 708301860 | RH Trim Box Package DARK | 1 |
| 2 | 704905469 | Trim Box Double Face Tape | 2 |
| 1 | 708301268 | Steel Black, LH Trunck Cover Models Steel Black | 1 |
| 1 | 708302828 | Liquid Titan, LH Trunk Cover Models Liquid Titan | 1 |
| 1 | 708303520 | Magma Red, LH Trunk Cover Models Magma Red | 1 |
| 1 | 708301269 | Steel Black, RH Trunk Cover Models Steel Black | 1 |
| 1 | 708302829 | Liquid Titan, RH Trunk Cover Models Liquid Titan | 1 |
| 1 | 708303521 | Magma Red, RH Trunk Cover Models Magma Red | 1 |
| 2 | 705002423 | Amber, Lateral Reflector Australia, Europe, Japan, China | 2 |
| 2 | 705003412 | Red, Lateral Reflector Canada/USA | 2 |
| 1 | 708301584 | Rear Fender Except China | 1 |
| 1 | 708301584 | Rear Fender China | 1 |
| 1 | 708301747 | Rear Fender Extention | 1 |
| 2 | 414745900 | Tuflock Phillips Plastic Screw | 2 |
| 2 | 293250385 | Neoprene Seal, 150 MM | 2 |
| 1 | 219704373 | Seal 1000Mm Long | 1 |
| 1 | 708302780 | Striker Support Assembly LH Includes 100o TO 100o3 | 1 |
| 2 | 210251650 | Hex. Forming Screw M5 X 16 | 2 |
| 1 | 219704372 | Was 293250087 Gasket | 1 |
| 3 | 250100208 | Panel Nut M6 X 1.0 | 3 |
| 3 | 250000722 | Torx Screw M6 X 20 | 3 |
| 2 | 708302044 | Female Hinge | 2 |
| 2 | 708302046 | Retaining Plate | 2 |
| 4 | 250000577 | Torx Truss Screw K40 X 12 | 4 |
| 1 | 708301609 | Under Tail | 1 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 2 | 250000446 | Torx Screw M6 X 20, Scotch Grip | 2 |
| 2 | 293150230 | Tuflok Plastic Rivet | 2 |
| 2 | 250100208 | Panel Nut M6 X 1.0 | 2 |
| 5 | 293150230 | Tuflok Plastic Rivet | 5 |
| 1 | 708302781 | Striker Support Assembly RH Includes 100ac TO 100ac3 | 1 |
| 1 | 708302143 | Support | 1 |
| 1 | 719000069 | Rear Fog Light Support China | 1 |
| 1 | 719000067 | Rear Fog Light Guard China | 1 |
| 3 | 205052588 | Socket Head Screw M5 X 25 China | 3 |
| 3 | 232051600 | Hex. Nut M5 China | 3 |
| 2 | 517302785 | Edge Clip China | 2 |
| 1 | 708302404 | LH Cargo | 1 |
| 3 | 234062670 | Stainless Steel Flat Washer | 3 |
| 2 | 708302045 | Male Hinge | 2 |
| 1 | 708301794 | LH Latch Assembly | 1 |
| 2 | 250000722 | Torx Screw M6 X 20 | 2 |
| 1 | 710002033 | Connector Holder | 1 |
| 1 | 708301222 | LH Control | 1 |
| 2 | 250100198 | Panel Nut M6 X 1.0 | 2 |
| 1 | 293250420 | Molded Weather Strip | 1 |
| 1 | 708302401 | LH Cargo Fairing | 1 |
| 4 | 250000720 | Torx Screw K50 X 16 | 4 |
| 1 | 708301805 | Antena Cap | 1 |
| 1 | 708300385 | Retainer Cable | 1 |
| 2 | 250000725 | Screw M4 X 16 | 2 |
| 1 | 708302283 | LH Light Support | 1 |
| 1 | 708302284 | Brace | 1 |
| 1 | 293150230 | Tuflok Plastic Rivet | 1 |
| 1 | 234062670 | Stainless Steel Flat Washer | 1 |
| 1 | 250000720 | Torx Screw K50 X 16 | 1 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 1 | 708302405 | RH Cargo | 1 |
| 1 | 708301795 | RH Latch Assembly | 1 |
| 1 | 708301697 | RH Control | 1 |
| 1 | 708302402 | RH Cargo Fairing | 1 |
| 1 | 708302285 | RH Light Support | 1 |
| 1 | 705009908 | Heat Shield | 1 |
| 1 | 708301656 | LH Heated Passenger Handle | 1 |
| 2 | 708302461 | Bushing | 2 |
| 2 | 250000823 | Socket Head Screw M8 X 30, Scotch Grip | 2 |
| 2 | 234082410 | Flat Washer 8 mm | 2 |
| 2 | 234081670 | Stainless Steel Flat Washer 8 mm | 2 |
| 1 | 414745900 | Tuflock Phillips Plastic Screw | 1 |
| 1 | 708301657 | RH Heated Passenger Handle | 1 |
| 3 | 250100199 | Insert Half Hex Body M6 x 1.0 | 3 |
| 2 | 708303508 | Anchorage Socket | 2 |
| 1 | 708301698 | Cargo Rear Support | 1 |
| 6 | 250100208 | Panel Nut M6 X 1.0 | 6 |
| 6 | 250000881 | Torx Truss M8 X 16 | 6 |
| 5 | 234062670 | Stainless Steel Flat Washer | 5 |
| 1 | 708002532 | Lanyard | 1 |
