Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 1110A-LBA2-E00 | CASE ASSY R/L CRANK | 1 |
| 1 | 11203-LBA2-E00 | RUB BUSH L CASE **(0) C.2005.03.01 | 1 |
| 1 | 11221-LBA2-E00 | INSULATOR PLATE **(0) C.2005.03.01 | 1 |
| 1 | 11341-LBA2-E01 | COVER LEFT | 1 |
| 1 | 11343-LDG7-E00-NEP | RR COVER L COVER | 1 |
| 1 | 11344-LBA2-E00 | INNER COVER L COVER | 1 |
| 1 | 11345-LDG7-E00-N8F | EMB ENG COVER | 1 |
| 1 | 1134B-LDG7-E00-HJP | FRONT COVER COMP L COVER | 1 |
| 1 | 11382-LDG7-900 | CLAMPER INJECTOR WIRE | 1 |
| 1 | 11395-LBA2-E00 | GASKET L COVER @ A | 1 |
| 12361-GY6-9010 | 12361-GY6-9010 HOLE CAP | ||
| 2 | 13314-LBA2-E0A | BRG CRANK SHAFT A BROWN(1.976~980) | 2 |
| 2 | 13314-LBA2-E0B | BRG CRANK SHAFT A GREEN(1.972~976) | 2 |
| 2 | 13314-LBA2-E0C | BRG CRANK SHAFT A YELLOW(1.968~972) | 2 |
| 2 | 13315-LBA2-E0A | BRG CRANK SHAFT B BROWN(1.976~980) | 2 |
| 2 | 13315-LBA2-E0B | BRG CRANK SHAFT B GREEN(1.972~976) | 2 |
| 2 | 13315-LBA2-E0C | BRG CRANK SHAFT B YELLOW(1.968~972) | 2 |
| 1 | 15200-LBA2-E00 | OIL RELIEF VALVE ASSY **(3) C.2006.02.10 | 1 |
| 15421-107-0000 | SCREEN OIL FILTER | ||
| 15426-GE1-9200 | SPG OIL FILTER SCREEN | ||
| 1 | 15520-LBA2-E00 | PIPE COMP OIL **(7) C.2006.06.29 | 1 |
| 1 | 15521-LBA2-E00 | COLLAR OIL **(0) C.2005.03.01 | 1 |
| 1 | 15522-LBA2-E00 | PIPE OIL R/L CASE **(0) C.2005.03.01 | 1 |
| 1 | 15700-LBA2-E00 | OIL WATER HEAT EXCHANGER **(1) C.2005.06 | 1 |
| 1 | 15710-LBA2-E00 | BOTTOM OIL WATER **(2) C.2005.06.17 | 1 |
| 1 | 15712-LBA2-E00 | GASKET OIL WATER HEAT EXCHANGER **(0) | 1 |
| 6 | 18291-KKC4-900 | COLLAR | 6 |
| 6 | 18293-KKC4-900 | RUBBER | 6 |
| 1 | 23560-LBA2-E00 | ORIFICE R CASE **(0) C.2005.03.01 | 1 |
| 1 | 50504-LBA2-E00 | STOPPER MAIN STAND **(0) C.2005.03.01 | 1 |
| 2 | 90004-LBA2-E00 | BOLT B OIL PASS **(0) C.2005.06.22 | 2 |
| 2 | 90005-LBA2-E00 | BOLT C OIL PASS **(0) C.2005.03.01 | 2 |
| 8 | 90407-LBA2-E00 | SEALING WASHER OIL PIPE **(0) C.2005.03 | 8 |
| 1 | 90474-3C33-001 | WASHER 8MM | 1 |
| 9052A-GY6-9500 | BOLT ASSY DRAIN PLUG | ||
| 4 | 90701-9E65-001 | PIN DOWEL 10*16 **965-0010 C.2005.03.01 | 4 |
| 1 | 91001-KHV8-004 | BRG BALL 6305 **KV8-0040-H1 C.2005.03.01 | 1 |
| 1 | 91009-LBA2-E00 | BRG BALL RADIAL 6006LLU/2A **(0) C.2005 | 1 |
| 1 | 91202-LBA2-E00 | OIL SEAT 35*47*7 **(0) C.2005.03.01 | 1 |
| 1 | 91261-4E15-004 | OIL SEAL 25*40*8 **415-0040 C.2005.03.01 | 1 |
| 1 | 91302-0A01-021 | O-RING 30.8MM | 1 |
| 1 | 91313-KED9-900 | O RING 15.5*1.5 **(2) C.2005.03.01 | 1 |
| 2 | 91317-LBA2-E00 | O RING 13.5*1.5 **(0) C.2005.03.01 | 2 |
| 3 | 93903-34360 | BOLT FLANGE | 3 |
| 2 | 93903-34460 | SCREW TAPPING 4X16 | 2 |
| 3 | 94111-06800 | WASHER SPRING 6MM | 3 |
| 2 | 94301-10160 | PIN DOWEL 10*16 | 2 |
| 4 | 94301-12200 | DOWEL PIN 12*20 **(0) C.2005.03.01 | 4 |
| 1 | 94520-12100 | CIR CLIP IN 12 | 1 |
| 1 | 94520-52000 | CIRCLIP IN 52 | 1 |
| 1 | 94520-55000 | CIR CLIP IN 55 | 1 |
| 6 | 95701-06016-02 | BOLT FLANGE 6*16 | 6 |
| 6 | 95701-06022-08 | BOLT FLANGE 6*22 | 6 |
| 2 | 95701-06032-08 | BOLT FLANGE 6*32 | 2 |
| 1 | 95701-08012-08 | BOLT FLANGE 8*12 | 1 |
| 3 | 96001-06012-08 | BOLT FLANGE 6*12 | 3 |
| 1 | 96001-06060-08 | BOLT FLANGE SH 6*60 | 1 |
| 6 | 96001-06065-08 | BOLT FLANGE SH 6*65 | 6 |
| 1 | 96001-06075-08 | BOLT FLANGE 6*75 | 1 |
| 3 | 96001-06095-08 | BOLT FLANGE 6*95 | 3 |
| 2 | 96001-06100-08 | BOLT FLANGE SH 6*100 | 2 |
| 1 | 96100-62040-00 | BEARING BALL RADIAL 6204 | 1 |
| 1 | 96100-63040-00 | BRG BALL RADIAL 6304/20*52*15 | 1 |
| 2 | 96100-LBA2-E00 | BRG BALL RADIAL 6304 **(0) C.2005.03.01 | 2 |
| 2 | 96150-60050-00 | BEARING BALL RADIAL 6005 | 2 |
