Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705600987 | LH Front Caliper Includes 10 to 10b | 1 |
| 1 | 219800237 | Brake Pad Kit | 1 |
| 1 | 219800238 | Spring/Pin/Clip Kit | 1 |
| 1 | 705600988 | RH Front Caliper Includes 20 to 20b | 1 |
| 4 | 207506556 | Hex Flange Screw M10 X 65 | 4 |
| 1 | 705601672 | RH Front Brake Hose Flexible Includes 40 to 40a | 1 |
| 2 | 293650256 | Clamp | 2 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 4 | 207561634 | Hex. Flange Screw M6 X 16, Scotch Grip | 4 |
| 4 | 250100208 | Panel Nut M6 X 1.0 | 4 |
| 4 | 414920600 | Washer | 4 |
| 2 | 705601201 | Banjo Bolt/ Bleeder | 2 |
| 2 | 705601190 | Bleeder Bolt Cap | 2 |
| 1 | 705601673 | LH Front Brake Hose Flexible Includes 65 to 65a | 1 |
| 2 | 705601631 | Front Brake Disk | 2 |
| 1 | 705601632 | Rear Brake Disk | 1 |
| 5 | 250001054 | Hex. Flange Screw M10 X 25 | 5 |
| 1 | 705600989 | Rear Caliper Includes 90 to 90d | 1 |
| 1 | 219800239 | Brake Pad Kit | 1 |
| 1 | 219800240 | Spring/Pin/Clip Kit | 1 |
| 1 | 219800241 | Rear Cable Support Kit | 1 |
| 1 | 219800242 | Rear Dust Cover | 1 |
| 1 | 705601746 | Rear Brake Caliper Support Package Touring and LTD | 1 |
| 1 | 705601747 | Support Brake Caliper Rear Package STD and S | 1 |
| 2 | 207523056 | Hex. Flange Screw M12 X 30, Scotch Grip | 2 |
| 1 | 705601674 | Flexible Brake Line Rear Package STD and S | 1 |
| 1 | 705601675 | Flexible Brake Line Rear Package Touring and LTD | 1 |
| 1 | 293650256 | Clamp | 1 |
| 1 | 207662054 | Hex. Flange Screw M6 X 20 Package STD and S | 1 |
| 1 | 705601400 | Caliper Trim Cap Package STD and S, Except Australia | 1 |
| 1 | 250000821 | Torx Screw 24 X 0.5 Package STD and S, Except Australia | 1 |
| 1 | 705601406 | Caliper Trim Cap Package STD and S, Except Australia | 1 |
| 1 | 705601201 | Banjo Bolt/ Bleeder | 1 |
| 1 | 705601190 | Bleeder Bolt Cap | 1 |
| 2 | 414920600 | Washer | 2 |
| 3 | 207662054 | Hex. Flange Screw M6 X 20 Package Touring and LTD | 3 |
| 1 | 233261494 | Hex. Elastic Flange Nut M6 Package Touring and LTD | 1 |
| 1 | 706202587 | Cable Guide Package Touring and LTD | 1 |
| 1 | 705600722 | Tandem Cylinder Master | 1 |
| 2 | 207583044 | Hex. Flange Screw M8 X 30, Scotch Grip | 2 |
| 1 | 705600716 | Bellow | 1 |
| 1 | 509000442 | Oeticker Gear Clamp, 25.6-706R | 1 |
| 5 | 705601513 | Rigid Tube Support | 5 |
| 1 | 705601157 | Tandem Rigid Tube | 1 |
| 1 | 705601158 | Tandem Rigid Tube | 1 |
| 2 | 507032551 | Banjo Bolt | 2 |
| 1 | 705601159 | Rear Brake Rigid Tube | 1 |
| 1 | 705601526 | Master Cylinder Reservoir Ass'y Includes 500 to 500g | 1 |
| XXX | Not Available As Spare Parts Not available seperately | ||
| 1 | 219800350 | Diaphragm Cover Ass'y | 1 |
| 2 | 705601073 | Oil Level Sensor | 2 |
| 1 | 705601294 | Spindle Lock | 1 |
| 2 | 211100002 | Push Nut | 2 |
| 2 | 710002033 | Connector Holder | 2 |
| 415129507 | Hose | ||
| 2 | 705601236 | Formed Hose | 2 |
| 4 | 293650047 | Crimp Clamp, 15.3-706R | 4 |
| 1 | 709000571 | Hose Support | 1 |
| 1 | 705600502 | Bleeder Screw | 1 |
| 1 | 707001375 | Parking Brake Cable Package STD and S | 1 |
| 1 | 707001856 | Parking Brake Cable Package Touring and LTD | 1 |
| 1 | 709000633 | Harness Support | 1 |
| 1 | 515175507 | Open Clamp | 1 |
| 1 | 210262050 | Hexagonal Head Screw | 1 |
| 1 | 705600768 | Front Pulley Cable Includes 800 to 800b | 1 |
| 2 | 705600458 | Bearing | 2 |
| 1 | 233201464 | Hex. Flange Elastic M10 x 1.5 | 1 |
| 1 | 293900087 | Bushing | 1 |
| 1 | 207604054 | Hex. Flange Screw M10 X 40 | 1 |
