Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1341450 | N/A,USE COMPONENTS | ||
| 3233906 | Discontinued | ||
| 8 | 3233826 | SCREW | 8 |
| 1 | 3233827 | GEARS SECTOR COVER | 1 |
| 1 | 3233829 | DETENT PAWL | 1 |
| 1 | 3233869 | O-RING | 1 |
| 1 | 3233831 | SHIFT SHAFT | 1 |
| 2 | 3233878 | TRIPER LIP SEAL | 2 |
| 1 | 3233832 | SECTOR GEAR, 31 TOOTH CUT TO 11 | 1 |
| 1 | 3233524 | TUBE,VENT | 1 |
| 3234059 | GEARCASE,RH | ||
| 3234066 | SHAFT-CENTER DRIVE | ||
| 1 | 3234065 | BALL BEARNING | 1 |
| 3234064 | SPACER | ||
| 2 | 3233364 | RETAINING RING | 2 |
| 1 | 3234063 | COVER-CENTER DRIVE BEARING | 1 |
| 5 | 3234086 | SCREW-TORX TRUSS HD | 5 |
| 1 | 3234062 | GEAR OUTPUT | 1 |
| 2 | 3233268 | BALL BEARING | 2 |
| 1 | 3234421 | SUBASSEMBLY 59 TOOTH, OUTPUT, F [Incl. 2 of Ref. 18] | 1 |
| 1 | 3234057 | CHAIN | 1 |
| 2 | 3233247 | PIN, DOWEL | 2 |
| 3234056 | GEARCASE, LEFT | ||
| 22 | 3233846 | SCR-TAPPING HEX WASHER HD 5/16 | 22 |
| 1 | 3233794 | HEX PLUG W/ O-RING, HOLLOW | 1 |
| 1 | 3234529 | HEX PLUG W/ O-RING, HOLLOW | 1 |
| 1 | 3233874 | DUAL LIP SEAL | 1 |
| 2 | 3233749 | SCREW | 2 |
| 2 | 3233018 | BEARING | 2 |
| 1 | 3234061 | OIL DEFLECTOR | 1 |
| 1 | 3234060 | SPROCKET, 19 TOOTH | 1 |
| 1 | 3233699 | RING-RETAINING | 1 |
| 1 | 3234360 | DRUM SHIFT | 1 |
| 1 | 3234088 | OIL-BAFFLE | 1 |
| 1 | 3233915 | PLATE-PARK 12 FACE | 1 |
| 2 | 3233851 | WASHER | 2 |
| 3 | 3233718 | NEEDLE BEARING | 3 |
| 1 | 3233176 | WASHER | 1 |
| 1 | 3234067 | RETAINING RING | 1 |
| 3234068 | GEAR, 28T | ||
| 1 | 3233855 | WASHER | 1 |
| 1 | 3234070 | ENGAGEMENT DOG 6 FACE | 1 |
| 2 | 3233850 | RETAINING RING | 2 |
| 1 | 3233854 | SPROCKET-24T,6 FACE ENGAGEMENT | 1 |
| 1 | 3234071 | SHAFT-REVERSE,26T | 1 |
| 1 | 3233852 | LOW GEAR 33 TOOTH | 1 |
| 1 | 3234069 | DOG, L/P | 1 |
| 3234074 | BALL BEARING | ||
| 1 | 3233019 | BEARING | 1 |
| 1 | 3234075 | SUBASM-INPUT SHAFT | 1 |
| 3233036 | Discontinued | ||
| 1 | 3233357 | SPACER | 1 |
| 1 | 3234092 | RING-RETAINING | 1 |
| 1 | 3234076 | O-RING | 1 |
| 1 | 3233788 | TRIPLE LIP SEAL | 1 |
| 1 | 3233106 | SNAP RING | 1 |
| 1 | 3233305 | BALL BEARING | 1 |
| 3234085 | SNORKEL TUBE | ||
| 3234084 | O-RING | ||
| 1 | 3233265 | BALL BEARING | 1 |
| 1 | 3234083 | SNORKEL SHAFT | 1 |
| 3233917 | SUBASM-PARK LOCKOUT | ||
| 1 | 3233839 | SECTOR GEAR, 16 TOOTH | 1 |
| 1 | 3233548 | O-RING | 1 |
| 1 | 3234081 | SPACER | 1 |
| 1 | 3234082 | DETENT STAR | 1 |
| 1 | 3233076 | O-RING | 1 |
| 1 | 3233830 | COMPRESSION SPRING | 1 |
| 1 | 3233961 | NUT-LOCK HEX FLANGE NYLON 5/16 | 1 |
| 1 | 3233834 | RETAINING RING | 1 |
| 1 | 3233835 | ROTARY SWITCH, 6 PIN | 1 |
| 2 | 3234091 | CUP WASHER | 2 |
| 2 | 3234077 | SHIFT FORK | 2 |
| 1 | 3234073 | SHIFT COLLAR | 1 |
| 2 | 3234089 | COMPRESSION SPRING | 2 |
| 2 | 3234078 | COMPRESSION SPRING | 2 |
| 2 | 3234090 | RETAINING RING | 2 |
| 2 | 3233432 | DOWEL PIN | 2 |
| 1 | 3233433 | CHAIN TENSIONER SHOE | 1 |
| 1 | 3233434 | CHAIN TENSIONER CAM | 1 |
| 1 | 3233431 | TORISON SPRING | 1 |
| 1 | 3234079 | SHIFT RAIL, SHAFT | 1 |
