Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 207503044 | Hex. Screw M10 X 1.5 X 30 TS SE5 | 1 |
| 7 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip T, TS | 7 |
| 2 | 230681034 | Hex. Flange Screw M8 X 110 T, TS | 2 |
| 1 | 250000630 | Torx Truss Screw M6 X 25 T | 1 |
| 1 | 207189060 | Hex. Screw M8 x 90 | 1 |
| 4 | 232180600 | Hex. Jam Nut M8 T, TS | 4 |
| 2 | 233281434 | Hex. Flange Elastic Nut M8 T, TS | 2 |
| 1 | 705006423 | LH RUBBER BUSHING T | 1 |
| 1 | 705006424 | RH RUBBER BUSHING T | 1 |
| 3 | 705006555 | BUSHING T | 3 |
| 2 | 234281704 | Spring Washer M8 T, TS | 2 |
| 4 | 250000099 | Allen Plastite Screw #12 T, TS | 4 |
| 2 | 705006696 | Bushing T | 2 |
| 2 | 207503046 | Hex. Flange Screw M10 X 30, Scotch Grip | 2 |
| 1 | 207561044 | Flange Screw M6 X 10, Scotch Grip TS SE5 | 1 |
| 1 | 230020586 | Hexagonal Screw M12 X 105 TS SE5 | 1 |
| 1 | 232521416 | Elastic Stop Nut M12 TS SE5 | 1 |
| 2 | 234001410 | Flat Washer 10 mm TS SE5 | 2 |
| 2 | 234021430 | Flat Washer TS SE5 | 2 |
| 4 | 250000223 | Torx Screw M6 X 16 TS SE5 | 4 |
| 2 | 250200136 | Plastic Washer 20MM TS SE5 | 2 |
| 1 | 705005333 | RH Front Rubber Pad TS SE5 | 1 |
| 1 | 705005334 | RH FRONT FOOTREST ASS'Y TS SE5 | 1 |
| 1 | 705005723 | Pivot Support TS SE5 | 1 |
| 2 | 705005861 | Pivot Bracket TS SE5 | 2 |
| 1 | 705005367 | Latch Ass'y TS SE5 | 1 |
| 1 | 705006428 | Latch Pin M12 X 30 TS SE5 | 1 |
| 1 | 705006533 | Spring TS SE5 | 1 |
| 1 | 705006557 | Retaining Plate T | 1 |
| 1 | 705006557 | Retaining Plate T, TS | 1 |
| 1 | 705600458 | Bearing | 1 |
| 2 | 706000447 | Bearing TS SE5 | 2 |
| 2 | 706000448 | Seal, Single Lip ID 19.4 OD 26 TS SE5 | 2 |
| 1 | 706000731 | Bushing TS SE5 | 1 |
| 1 | 708000759 | Rubber Stopper TS SE5 | 1 |
| 2 | 250100069 | Panel Nut M8 X 1.25 T, TS | 2 |
| 4 | 503183800 | Washer T, TS | 4 |
| 1 | 518327010 | LH ROCKER PANEL FOAM T, TS | 1 |
| 1 | 518327011 | RH ROCKER PANEL FOAM T, TS | 1 |
| 518327438 | RH LATERAL PANEL FOAM | ||
| 4 | 705002153 | Bushing T, TS | 4 |
| 2 | 705003013 | Adjuster Block T, TS | 2 |
| 4 | 705003018 | Rubber Bushing T, TS | 4 |
| 1 | 705005266 | LH ROCKER PANEL T, TS | 1 |
| 1 | 705005267 | RH Rocker Panel T, TS | 1 |
| 1 | 705007668 | Steel Black RH Side Console ST Steel Black Met | 1 |
| 705007674 | RH SIDE CONSOLE, MAGNESIUM ST Magnesium | ||
| 705007674 | RH SIDE CONSOLE, MAGNESIUM ST-S Magnesium | ||
| 705007682 | YELLOW RH SIDE CONSOLE Yellow Circuit | ||
| 705005337 | LH Sliding Block T | ||
| 705006799 | BLACK LH SLIDING BLOCK TS | ||
| 705006799 | BLACK LH SLIDING BLOCK TS SE5 | ||
| 1 | 705006796 | LH REAR FOOT SUPPORT TS SE5 | 1 |
| 705006798 | LH REAR FOOTREST TS SE5 | ||
| 1 | 705006801 | BLACK RH SLIDING BLOCK TS SE5 | 1 |
| 705006794 | RH FOOTREST SUPPORT, BLACK TS SE5 | ||
| 1 | 705006800 | Black RH Footrest Support TS SE5 | 1 |
| 1 | 705005350 | RH REAR RUBBER PAD T, TS | 1 |
| 1 | 705005351 | LH REAR RUBBER PAD T, TS | 1 |
| 1 | 705005413 | LH DEFLECTOR PANNEL T, TS | 1 |
| 1 | 705007665 | Steel Black LH Side Console ST Steel Black Met | 1 |
| 705007676 | LH SIDE CONSOLE, MAGNESIUM ST-S Magnesium | ||
| 705007676 | LH SIDE CONSOLE, MAGNESIUM ST Magnesium | ||
| 1 | 705006727 | RH LATERAL CONSOLE. JAUNE Yellow Circuit | 1 |
| 4 | 708000759 | Rubber Stopper T, TS | 4 |
| 2 | 250000130 | Torx Screw M5 X 20 T, TS | 2 |
| 2 | 250000079 | Panel Nut M5 X 0.8 T, TS | 2 |
| 4 | 250000079 | Panel Nut M5 X 0.8 | 4 |
| 2 | 250000661 | Socket Screw M5 X 16 F/ T, TS | 2 |
| 2 | 207562044 | Flange Screw M6 X 20, Scotch Grip T | 2 |
| 1 | 705005330 | LH Front Footrest Ass'y TS SE5 | 1 |
| 1 | 705006793 | LH FRONT FOOTREST ASS'Y TS SM5 | 1 |
| 1 | 705006797 | RH FRONT FOOTREST ASS'Y TS SM5 | 1 |
| 1 | 705005329 | LH FRONT RUBBER PAD TS SE5 | 1 |
| 1 | 705006297 | LH FRONT RUBBER PAD | 1 |
| 705006388 | VIBRATION DAMPENER T | ||
| 2 | 705007473 | Lock Plate | 2 |
| 1 | 705006556 | CUSHION T | 1 |
| 1 | 234002600 | Flat Washer 10 mm, Stainless T | 1 |
| 705006554 | CUSHION T | ||
| XXX | Not Available As Spare Parts |
