Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 8EN-F3711-00-00 | SKI 1 | ||
| 8DM-F3712-00-00 | REINFORCEMENT, HEAD | ||
| 8EK-F3766-00-00 | SADDLE 1 | ||
| 8EN-F3731-00-00 | RUNNER 1 | ||
| 8 | 8EK-F3751-00-00 | BUSH, SKI 1 | 8 |
| 2 | 9702M-08055-00 | BOLT | 2 |
| 2 | 9702M-08100-00 | BOLT | 2 |
| 4 | 90108-08002-00 | BOLT, SQUARE | 4 |
| 8 | 90201-08784-00 | WASHER, PLATE | 8 |
| 12 | 90201-086P8-00 | WASHER, PLATE | 12 |
| 16 | 9570M-08300-00 | NUT, NYLON | 16 |
| 2 | 90105-10712-00 | BOLT, FLANGE | 2 |
| 2 | 95607-10200-00 | NUT, U FLANGE | 2 |
| 2 | 90387-1012H-00 | COLLAR | 2 |
| 2 | 91401-20020-00 | PIN, COTTER | 2 |
| 2 | 8CR-23743-10-00 | STOPPER 1 | 2 |
| 1 | 8FA-23760-00-00 | SPRING ASSY 1 (K=21N/MM) RX1MSH (8EV1) | 1 |
| 1 | 8FA-23760-10-00 | SPRING ASSY 1 (K=19N/MM) RX1MSH (8EV1) | 1 |
| 1 | 8FA-23760-20-00 | SPRING ASSY 1 (K=17N/MM) RX1MSH (8EV1) | 1 |
| 1 | 8FA-23501-00-00 | STEERING KNUCKLE ASSY (LEFT) | 1 |
| 2 | 90381-25115-00 | BUSH, SOLID | 2 |
| 2 | 90381-15088-00 | BUSH, SOLID | 2 |
| 2 | 90381-18N50-00 | BUSH, SOLID | 2 |
| 1 | 93700-06004-00 | NIPPLE, GREASE | 1 |
| 2 | 8FA-23803-00-00 | COLUMN, SKI ASSY | 2 |
| 2 | 90384-16251-00 | BUSH, BIMETAL FORMED | 2 |
| 1 | 8FA-23851-00-00 | ARM, OUTSIDE 1 | 1 |
| 2 | 91317-08045-00 | BOLT, HEX. SOCKET HEAD | 2 |
| 2 | 95607-08200-00 | NUT, SELF-LOCKING | 2 |
| 2 | 3YK-22472-40-00 | CAP, CASE | 2 |
| 8FA-23540-00-00 | FRONT UPPER ARM COMP. (LEFT) RX10SH (8EU1) | ||
| 2 | 8EP-23540-00-00 | FRONT UPPER ARM COMP. (LEFT) RX1MSH (8EV1) | 2 |
| 2 | 90105-10N51-00 | BOLT, FLANGE | 2 |
| 8FA-23737-00-00 | WASHER 1 | ||
| 2 | 90387-10N58-00 | COLLAR | 2 |
| 2 | 90105-10N53-00 | BOLT, FLANGE | 2 |
| 2 | 90201-106F2-00 | WASHER, PLATE | 2 |
| 90387-10N52-00 | COLLAR | ||
| 4 | 90209-15N50-00 | WASHER | 4 |
| 1 | 8FA-23570-00-00 | FRONT LOWER ARM COMP. (LEFT) RX10SH (8EU1) | 1 |
| 8EP-23570-00-00 | FRONT LOWER ARM COMP. (LEFT) RX1MSH (8EV1) | ||
| 2 | 90381-16N51-00 | BUSH, SOLID | 2 |
| 2 | 90105-12N54-00 | BOLT, FLANGE | 2 |
| 2 | 95607-12200-00 | NUT, SELF-LOCKING | 2 |
| 2 | 90387-12N54-00 | COLLAR | 2 |
| 2 | 90105-10N52-00 | BOLT, FLANGE | 2 |
| 90387-10N53-00 | COLLAR | ||
| 8FA-2376A-00-00 | ABSORBER ASSY 1 RX10SH (8EU1) | ||
| 8EP-2376A-00-00 | ABSORBER ASSY 1 RX1MSH (8EV1) | ||
| 90383-12N50-00 | BUSH, FORMED | ||
| 1 | 8FA-2331R-00-00 | DAMPER, BUSH B | 1 |
| 2 | 90105-10232-00 | BOLT, FLANGE | 2 |
| 2 | 90105-10392-00 | BOLT, FLANGE | 2 |
| 4 | 95607-10200-00 | NUT, U FLANGE | 4 |
| 90387-10N57-00 | COLLAR | ||
| 4 | 90201-106F2-00 | WASHER, PLATE | 4 |
| 1 | 8FA-23502-00-00 | STEERING KNUCKLE ASSY (RIGHT) | 1 |
| 1 | 8FA-23852-00-00 | ARM, OUTSIDE 2 | 1 |
| 1 | 8FA-23580-00-00 | FRONT LOWER ARM COMP. (RIGHT) RX10SH (8EU1) | 1 |
| 1 | 8EP-23580-00-00 | FRONT LOWER ARM COMP. (RIGHT) RX1MSH (8EV1) | 1 |
| 8FA-2386E-00-00 | BAR, STABILIZER FRONT | ||
| 2 | 8FA-2386G-00-00 | BUSH, STABILIZER FRONT | 2 |
| 8FA-2386L-00-00 | ARM, STABILIZER 1 | ||
| 8FA-2385L-00-00 | JOINT, STABILIZER 1 | ||
| 2 | 90101-06765-00 | BOLT | 2 |
| 2 | 95604-06200-00 | NUT, U FLANGE | 2 |
| 4 | 95814-08030-00 | BOLT, FLANGE | 4 |
| 4 | 95604-08200-00 | NUT, U FLANGE | 4 |
