Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8EP-21940-00-00 | FRONT FRAME COMP. | 1 |
| 1 | 8FA-W2197-00-00 | BULKHEAD | 1 |
| 2 | 90381-15001-00 | BUSH, SOLID | 2 |
| 2 | 90381-16001-00 | BUSH, SOLID | 2 |
| 1 | 8FA-W2198-00-00 | BULKHEAD 2 | 1 |
| 3 | 95827-08060-00 | BOLT, FLANGE | 3 |
| 1 | 95827-08065-00 | BOLT, FLANGE | 1 |
| 4 | 95607-08200-00 | NUT, SELF-LOCKING | 4 |
| 1 | 8FA-2128A-00-00 | BRACKET, REGULATOR | 1 |
| 1 | 8FA-21947-00-00 | BRACKET, STEERING 1 | 1 |
| 4 | 95607-10200-00 | NUT, U FLANGE | 4 |
| 8EP-12440-00-00 | HEAT EXCHANGER ASSY | ||
| 1 | 8FA-12551-00-00 | HOSE 7 | 1 |
| 1 | 90467-28046-00 | CLIP | 1 |
| 1 | 90450-35001-00 | HOSE CLAMP ASSY | 1 |
| 1 | 93306-20650-00 | BEARING | 1 |
| 1 | 99009-62500-00 | CIRCLIP | 1 |
| 1 | 95607-08200-00 | NUT, SELF-LOCKING | 1 |
| 43 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 43 |
| 1 | 8FA-21950-09-00 | REAR FRAME COMP. | 1 |
| 1 | 8FA-1241A-00-00 | HEAT EXCHANGER ASSY 4 | 1 |
| 1 | 90210-06006-00 | WASHER, SEAL | 1 |
| 1 | 95817-06016-00 | BOLT, FLANGE | 1 |
| 2 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 2 |
| 1 | 8FA-W2199-00-00 | REINEFORCEMENT, FRAME REAR 1 | 1 |
| 8EP-W2196-00-00 | PANEL, SUB-FRAME KIT | ||
| 8EP-2111J-00-00 | MEMBER, SIDE 1 | ||
| 8EP-2111K-00-00 | MEMBER, SIDE 2 | ||
| 1 | 8EP-21916-00-00 | PANEL, SUB FRAME 5 | 1 |
| 8EP-2192A-00-00 | PLATE, ANTI-SKID | ||
| 2 | 8EP-21943-00-00 | BRACKET, MAIN TRACK 1 | 2 |
| 1 | 8EP-21944-00-00 | BRACKET, RR. TRACK SUSPENSI | 1 |
| 1 | 8EP-21954-00-00 | BRACKET, RR. TRACK SUSPENSI | 1 |
| 1 | 8EP-21963-00-00 | PATCH 3 | 1 |
| 1 | 8EP-21964-00-00 | PATCH 4 | 1 |
| 1 | 8EP-21965-00-00 | PATCH 5 | 1 |
| 1 | 8EP-21966-00-00 | PATCH 6 | 1 |
| 61 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 61 |
| 8 | 90267-47197-00 | RIVET, BLIND (4.7X19.5 SILVER) | 8 |
| 8FA-W2195-00-00 | FRAME CONNECTION KIT | ||
| 2 | 8CR-21939-01-00 | BRACKET, CHAIN HOUSING | 2 |
| 2 | 8CR-21943-01-00 | BRACKET, MAIN TRACK 1 | 2 |
| 1 | 8FA-2196M-00-00 | BRACKET, 5 | 1 |
| 1 | 8FA-2197M-00-00 | BRACKET, 6 | 1 |
| 8FA-2198G-00-00 | COVER 2 | ||
| 1 | 8FA-21999-00-00 | CLAMP, WIRE HARNESS | 1 |
| 78 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 78 |
| 4 | 90267-48018-00 | RIVET, BLIND (4.8X18.6 BLACK) | 4 |
| 2 | 8FA-21953-00-00 | BRACKET, MAIN TRACK 2 | 2 |
| 1 | 8FA-2194X-00-00 | BRACKET 1 | 1 |
| 1 | 8FA-2195X-00-00 | BRACKET 2 | 1 |
| 8FA-21960-00-00 | FOOTREST COMP. 1 | ||
| 1 | 8FA-21970-00-00 | FOOTREST COMP. 2 | 1 |
| 1 | 8FA-2193E-00-00 | BRACKET, OIL TANK 1 | 1 |
| 2 | 95827-08014-00 | BOLT, FLANGE | 2 |
| 1 | 8EK-21920-01-00 | HOUSING, REINF SUB-ASSY (L.H) | 1 |
| 8FA-2198F-00-00 | COVER 1 | ||
| 1 | 8FA-2198J-00-00 | COVER 3 | 1 |
| 1 | 8FA-2195E-00-00 | PLATE, STRG BRACKET 1 | 1 |
| 1 | 8FA-2195F-00-00 | PLATE, STRG BRACKET 2 | 1 |
| 8EP-2196A-00-00 | FRAME UNDER 1 | ||
| 8EP-2196E-00-00 | FRAME, UNDER 2 | ||
| 1 | 8FA-21972-00-00 | BRACKET, GUARD FITTING | 1 |
| 6 | 8FA-2196F-00-00 | BRACKET 3 | 6 |
| 18 | 90267-48018-00 | RIVET, BLIND (4.8X18.6 BLACK) | 18 |
| 1 | 8FA-77512-00-00 | BUMPER, FRONT 2 | 1 |
| 4 | 95827-06012-00 | BOLT, FLANGE | 4 |
| 1 | 8FA-21949-00-00 | BRACKET, FRONT | 1 |
| 1 | 8FA-21959-00-00 | BRACKET, FRONT BUMPER | 1 |
| 2 | 8FA-77125-00-00 | STAY 1 | 2 |
| 6 | 95827-08016-00 | BOLT, FLANGE | 6 |
| 1 | 8FA-21973-00-00 | HOOK | 1 |
| 3 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 3 |
| 2 | 95827-08020-00 | BOLT, FLANGE | 2 |
| 14 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 14 |
| 8FA-2197E-00-00 | PROTECTOR, FRAME | ||
| 5 | 90109-065F3-00 | BOLT | 5 |
| 5 | 90183-06053-00 | NUT, SPRING | 5 |
| 4 | 8FA-21998-00-00 | SPACER | 4 |
| 1 | 8FA-23892-00-00 | SHIELD, HEAT | 1 |
| 13 | 90267-48059-00 | RIVET, BLIND (4.8X12.3) | 13 |
| 1 | 88X-77762-10-00 | LABEL, WARNING 2 | 1 |
