Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2681314 | CUSHION,SEAT(88TRAIL) (Incl. 75-79) (TRAIL) | ||
| 2681315 | COVER,SEAT('88 TRAIL) (TRAIL) | ||
| 2681318 | COVER,SEAT('88 SPORT) (SPORT) | ||
| 2681352 | COVER,SEAT,(TRAIL'88) (Trail Special Only) | ||
| 5430425 | HOUSING,TAILLIGHT | ||
| 4030019 | BULB, BRAKELIGHT | ||
| 5430423 | Discontinued | ||
| 7511840 | SCREW | ||
| 10 | 7542122 | NYLOK NUT (SPORT) | 10 |
| 2 | 7558221 | WASHER(10) | 2 |
| 2681316 | COVER,TANK('88) (TRAIL) | ||
| 2681319 | COVER,TANK('88SPORT) (SPORT) | ||
| 5430575 | GROMMET-GAS TANK | ||
| 1 | 5810142 | GAS CAP GASKET | 1 |
| 1 | 2511149 | GAS CAP WITH GAUGE | 1 |
| 1 | 7042020 | SPRING, TANK | 1 |
| 5420126 | Discontinued | ||
| 2511150 | TANK,GAS | ||
| 1 | 7052037 | FUEL PICKUP WITH FILTER, 105 MI | 1 |
| 1 | 7052023 | FITTING, OUTLET | 1 |
| 2200190 | N/A,USE COMPONENTS | ||
| 5430669 | VENT-TANK | ||
| 2 | 5810063 | PAD-GAS TANK (TRAIL) | 2 |
| 40 | 7621457 | RIVET | 40 |
| 7080288 | PLUG (Except Trail ES) | ||
| 6 | 7621402 | POP RIVET | 6 |
| 1 | 7621452 | RIVET | 1 |
| 12 | 7621330 | POP RIVET | 12 |
| 4020035 | CLIP,WIRING | ||
| 5211047 | HINGE | ||
| 6 | 7558212 | WASHER,13/64X1/2X18GA,FL-Y (10) | 6 |
| 3 | 7621429 | RIVET (TRAIL) | 3 |
| 5230118 | SUBSTITUTED BY 5240965 | ||
| 1 | 7080216 | CLUTCH GUARD PIN | 1 |
| 7080311 | Discontinued | ||
| 1011662 | TUNNEL, (SPORT) (SPORT) | ||
| 1011663 | TUNNEL, (TRAIL) (TRAIL) | ||
| 1011675 | TUNNEL ASM.,(SKS) (SKS Only) w/1011694 (TRAIL) | ||
| 1011680 | TUNNEL,TRAIL DELUXE (Trail Special Only) | ||
| 4 | 7621323 | POP RIVET(50) (Except Trail Special) | 4 |
| 7080322 | BELT,SEAT (Except Trail Special) | ||
| 5223864 | WIRE-SEAT-BELT (Except Trail Special) | ||
| 5210842 | PLATE-SEAT BELT (Except Trail Special) | ||
| 5224334 | BUMPER,REAR,BLK. (400) | ||
| 5224347 | BUMPER,R.(N-INDY) (Sport,Trail) | ||
| 7072132 | DECAL, TRACK | ||
| 5220478 | PANEL,TUNNEL,BACK | ||
| 1011694 | PANEL,CLOSE-OFF,REAR (Trail SKS Only) | ||
| 1 | 5410394 | SNOW FLAP | 1 |
| 5 | 7621418 | RIVET(50) | 5 |
| 1011666 | BRKT,R.SUSP,LH MTG. | ||
| 1011667 | BRKT,R.SUSP,RH MTG. | ||
| 11 | 7661620 | RIVET (Trail SKS Only) | 11 |
| 2 | 2670070 | REFLECTOR, RED | 2 |
| 2 | 7512103 | BOLT | 2 |
| 6 | 7621222 | RIVET(10) | 6 |
| 5220634 | PLATE,TUNNEL,LH | ||
| 5220635 | PLATE,TUNNEL,RH | ||
| 5810201 | FOAM, FILLER | ||
| 7072078 | DECAL(47.5'')TUNNEL | ||
| 3 | 7512193 | CARRIAGE BOLT | 3 |
| 7621301 | RIVET(10) | ||
| 5332405 | TUBE,DRAIN BATTERY (Trail ES Only) | ||
| 5221932 | BRACKET, GASTANK | ||
| 1011612 | BULKHEAD, (TRAIL) (TRAIL) | ||
| 1011615 | BULKHEAD,(SPORT>) (SPROT) | ||
| 5220406 | BRACKET, HINGE | ||
| 7072153 | DECAL, WARNING | ||
| 7080227 | SNAP-MALE | ||
| 3 | 7670021 | NUT, SPEED | 3 |
| 7072414 | DECAL (Trail SKS Only) | ||
| 2681290 | BUCKLE&STRAP (SPORT) | ||
| 2681291 | BUCKLE&STRAP (TRAIL) | ||
| 4 | 7558301 | FLAT WASHER | 4 |
| 1011601 | SUPPORT, MUFFLER | ||
| 4 | 7511848 | SCREW | 4 |
| 7670031 | PALNUT(10) (Trail ES Only) | ||
| 5430930 | Discontinued | ||
| 5211109 | SPACER,R.BUMPER | ||
| 4 | 7512240 | BOLT | 4 |
| 2200250 | FOOTREST ASM,LH | ||
| 2200254 | FOOTREST ASM,RH | ||
| 5220542 | BRKT. | ||
| 32 | 7661620 | RIVET | 32 |
| 1 | 8450003 | FUEL LINE, 1/4 ID | 1 |
| 5221722 | STRAP,GASTANK,BLK. | ||
| 5220395 | TUNNEL,REINFORCEMENT (SPORT) | ||
| 7661818 | RIVET,SEMI-TUBE,(10) * (SPORT) | ||
| 2681317 | SEAT ASM,('88SPORT) ((Incl. 75-79) (SPORT) | ||
| 2681353 | CUSHION,SEAT(TRAIL'88) 34 |
