Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 70612G02 | BRK PDL ASM W/0 LGTS WITHOUT BRAKE LIGHTSINCLUDES ITEMS 2 - 10 | 1 |
| 2 | 70681G01 | SPRING, TORSION, PARK BRAKE* | 2 |
| 1 | 70682G01 | PIN, PARKING BRAKE* | 1 |
| 2 | 01071G01 | PUSHNUT, WASHER CAP TYPE 5/16 | 2 |
| 1 | 70611G02 | OBS-PEDAL WELDMENT,PARK BRAKE | 1 |
| 1 | 70274G01 | PAD KIT-BRAKE PEDAL INCLUDES ITEMS 8 - 10 | 1 |
| 9 | 15766G1 | RIVET-3/8 X 15/32 | 9 |
| 1 | 70582G01 | BOLT, SHOULDER (SEE TEXT) STAINLESS STEEL | 1 |
| 2 | 70581G01 | BUSHING, ACETAL (SEE TEXT) | 2 |
| 1 | 70676G01 | SPRING, TORSION, BRAKE PEDAL | 1 |
| 1 | 00643G1 | WASHER-3/8 X 1.0 X .063 | 1 |
| 1 | 11098G5 | NUT-LOCK-LIGHT-3/8-16 | 1 |
| 6 | 12416G2 | CLAMP,NYLON,WEDGE LOCK,11.8 IN NOT ILLUSTRATED | 6 |
| 1 | 624714 | SVC-EQUALIZER & BRAKE CABLE-ASSY INCLUDES ITEMS 23 - 26 | 1 |
| 1 | 28082G01 | BRACKET,EQUALIZER | 1 |
| 2 | 28083G01 | BUMPER-BRAKE COMPENSATOR | 2 |
| 1 | 624695 | CABLE,BRAKE-65.06 | 1 |
| 1 | 624696 | CABLE,BRAKE-74.81 | 1 |
| 4 | 01111G01 | RETAINING RING - .8D X .42T STAINLESS STEEL | 4 |
| 3 | 10386G3 | PIN-CLEVIS-5/16 X 15/16 | 3 |
| 5 | 10387G3 | PIN-COTTER-3/32 X 3/4* | 5 |
| 1 | 70601G01 | LINKAGE ROD, BRAKE KICK-OFF | 1 |
| 2 | 17838G1 | BUSHING-NYLINER | 2 |
| 2 | 20835G1 | WASHER-NYLON | 2 |
| 2 | 00559G8 | WASHER-5/16-FL--B-CP | 2 |
| 1 | 70098G01 | PIVOT-KICK OFF CAM | 1 |
| 2 | 10097G6 | BEARING-FLANGED | 2 |
| 1 | 70587G01 | KICK-OFF CAM* | 1 |
| 2 | 71215G01 | SC-SET-SQH-(1/4-20X1/2) W/PL | 2 |
| 1 | 14134G4 | SPACER | 1 |
| 1 | 70113G01 | BUMPER-RUBBER-ADJUSTABLE | 1 |
| 1 | 11027G1 | NUT-LOCK FLANGED (WHIZ)5/16-18 | 1 |
| 1 | 70080G02 | CATCH BRACKET | 1 |
| 2 | 00414G6 | SCREW-1/4-20X3/4-HEX | 2 |
| 2 | 14390G4 | NUT-LOCK-1/4-20 STAINLESS STEEL | 2 |
| 1 | 70690G02 | BRK PEDAL ASSY (W/LIGHTS) WITH BRAKE LIGHTSINCLUDES ITEMS 54 - 80 | 1 |
| 1 | 70274G01 | PAD KIT-BRAKE PEDAL INCLUDES ITEMS 57 - 59 | 1 |
| 9 | 16409G1 | RIVET-OVAL HEAD-3/8 X 15/32 | 9 |
| 1 | 70258G03 | PNT,PLATE-BRAKE PEDAL | 1 |
| 1 | 01071G01 | PUSHNUT, WASHER CAP TYPE 5/16 | 1 |
| 4 | 00737G8 | SCREW-#10-24 X 1.0 | 4 |
| 2 | 00739G1 | NUT-RUBBER-WELL-#10-24 | 2 |
| 2 | 74535G01 | OBS - STAND OFF,BRAKE PEDAL | 2 |
| 2 | 27137G01 | SPRING CONICAL BRK PEDAL GCB | 2 |
| 2 | 14390G10 | NUT-LK PLAS INS 10-24 UNC-2B | 2 |
| 1 | 10606G8 | SWITCH-LIMIT-10A SPDT | 1 |
| 2 | 00957G1 | SCREW-HEX-CP-#6-32 X 1 1/4 | 2 |
| 2 | 00559G5 | WASHER, FLAT TYPE A | 2 |
| 4 | 00559G3 | WASHER-#6 | 4 |
| 2 | 00565G3 | WASHER-LOCK-#6-SP-ZP | 2 |
| 2 | 00525G5 | NUT-HEX-M-CP-#6-32 | 2 |
| 13514G1 | PAN HEAD PHILLIPS SCREW | ||
| 2 | 14628G1 | TAB-FASTON-5/16 X 5/16 | 2 |
| 1 | 24605G1 | HARNESS-BRAKE PEDA BRAKE LIGHT | 1 |
| 4 | 17618G1 | CLAMP - NYLON | 4 |
| 1 | 70998G01 | OBS-SVC-BRAKE ASSY,MECH,4084,LH DRIVER SIDEINCLUDES ITEMS 84 - 92, 94 - 95 | 1 |
| 1 | 70998G02 | OBS-SVC-BRAKE ASSY,MECH,4084,RH PASSENGER SIDEINCLUDES ITEMS 84 - 91, 93 - 95 | 1 |
| 70794G01 | BRAKE SHOE KIT INCLUDES ITEM 85 | ||
| 2 | 27944G01 | BRAKE-HARDWARE KIT-BENDIX INCLUDES ITEMS 87 - 91 | 2 |
| 1 | 72582G01 | KIT, SER, BRK ADJUSTER,LH DRIVER SIDEINCLUDES ITEMS 94 - 95 | 1 |
| 1 | 72582G02 | KIT, SER, BRK ADJUSTER,RH PASSENGER SIDEINCL. ITEMS 94 - 95 | 1 |
| 8 | 17083G2 | BOLT-HEX-HD 5/16-24 X 10 | 8 |
| 8 | 15126G1 | NUT-LOCK-5/16-24 | 8 |
| 2 | 21809G1 | WASHER-INNER WHEEL RIM-GAS | 2 |
| 2 | 21807G2 | BRAKE DRUM ASSY,GAS,LNG BOLT INCLUDES ITEMS 101 - 102 | 2 |
| 4 | 19862G2 | BOLT, WHEEL | 4 |
| 2 | 606945 | WASHER, BRAKE DRUM | 2 |
| 2 | 606403 | SLOTTED HEX NUT, M22 X 1.5 | 2 |
| 2 | 10387G1 | PIN-COTTER-.125X1.50 | 2 |
| 2 | 74175G01 | CAP, DUST, MOLDED | 2 |
| 1 | 608200 | BRACKET, CABLE, BRAKE, PS PASSENGER SIDE | 1 |
| 1 | 608201 | BRACKET, CABLE, BRAKE, DS DRIVER SIDE | 1 |
| 1 | 612558 | SVC-COMPENSATOR-ASSEMBLY INCLUDES ITEMS 113 - 121 | 1 |
| 00532G4 | NUT-LOCK-5/16-24 | ||
| 1 | 629486 | NUT-SPHER 9/16 HEX 6/16-24 UNF | 1 |
| 2 | 15121G1 | WASHER,FLAT,TYPE-A,3/8 | 2 |
| 1 | 17979G1 | BUSHING-ACCELERATOR ROD | 1 |
| 1 | 23061G2 | TUBE-COMPENSATOR STOP | 1 |
| 1 | 23463G1 | COMPRESSION SPRING, BRAKE LINKAGE | 1 |
| 1 | 27330G01 | OBS-PNT,YOKE,BRAKE | 1 |
| 1 | 11098G9 | NUT-LOCK-5/16-24 | 1 |
| 1 | 612557 | ROD-LINK COMPENSATOR 10.50 | 1 |
