Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 26651G02 | (UTD) *COIL-PULSAR-4CYC-FROM 1991 INCLUDES ITEM 2 | ||
| 1 | 26707G01 | *BOLT/WASHER-M5 X 8 X 10MM-4CY | 1 |
| 1 | 26652G01 | IGNITION COIL ASY/W/PLUG WIRES INCLUDES ITEMS 6 - 10 | 1 |
| 2 | 13632G1 | *NUT-METRIC-M6 X 1 | 2 |
| 1 | 25887G01 | WIRE ASSY-F1/A2 | 1 |
| 3 | 25682G1 | COVER-TERMINAL-4CYC* | 3 |
| 24775G | BATTERY | ||
| 00962G1 | SQUARE MACHINE SCREW | ||
| 2 | 00993G01 | WASHER-LK-SILICON BZ SILICON BRONZE | 2 |
| 00994G01 | HEX NUT SILICON BRONZE | ||
| 1 | 72101G02 | HOLD DOWN-BATTERY-GAS | 1 |
| 1 | 00438G6 | SCREW-5/16-18X3/4-C-HEX | 1 |
| 1 | 00565G8 | WASHER-LK-SP #5/16 | 1 |
| 1 | 00571G2 | WASHER-FLAT-TYPE A (WIDE-PLATED) STAINLESS STEEL | 1 |
| 1 | 27044G03 | SVC-BATTERY/ENGINE GROUND CABLE | 1 |
| 1 | 25976G19 | 14 GA WIRE ASSY | 1 |
| 2 | 00438G6 | SCREW-5/16-18X3/4-C-HEX | 2 |
| 2 | 11027G1 | NUT-LOCK FLANGED (WHIZ)5/16-18 | 2 |
| 1 | 26676G01 | *BOLT-FLANGED-M6X1.0X23MM-4CYC | 1 |
| 1 | 25972G85 | #6 AWG WIRE ASSEMBLY BLACK 23", F2 - SOL | 1 |
| 1 | 74938G01 | HARNESS CONTROL FOR 2004(MCI ONLY) CONTROL | 1 |
| 1 | 17618G1 | CLAMP - NYLON | 1 |
| 1 | 73049G01 | COVER-FNR | 1 |
| 1 | 16469G1 | WASHER-FENDER-ZP* | 1 |
| 1 | 00114G6 | SCREW-WASHER HEAD 1/4-10X3/4 | 1 |
| 1 | 72909G01 | ELECTRICAL PLATE ASS'Y INCLUDES ITEMS 48 - 73 | 1 |
| 1 | 73057G01 | OBS-BRACKET,ELECTRICAL | 1 |
| 1 | 27739G01 | VOLTAGE REG-4 CYC-FRM 12/93 | 1 |
| 1 | 00415G2 | SCREW-1/4-20 X 1 1/4 | 1 |
| 1 | 11027G2 | NUT-LOCK-1/4-20-FLG | 1 |
| 1 | 72872G01 | IGNITOR ASM 4 CYCLE* MCI ENGINES | 1 |
| 00414G8 | BOLT | ||
| 1 | 00414G5 | SCREW-1/4-20UNC2AX5/8 HX HD | 1 |
| 1 | 27153G01 | SOLENOID-14V-GAS | 1 |
| 3 | 11027G2 | NUT-LOCK-1/4-20-FLG | 3 |
| 1 | 73446G01 | FASTON - TAB 90 | 1 |
| 2 | 00565G5 | WASHER-LK-#10-CP | 2 |
| 2 | 00526G4 | NUT-10-32-HEX-M-CP | 2 |
| 1 | 25978G56 | WIRE 18 GAUGE, BLACK | 1 |
| 1 | 600418G01 | FUSE HOLDER ASM SEALED ATC | 1 |
| 2 | 00565G8 | WASHER-LK-SP #5/16 | 2 |
| 2 | 00544G4 | NUT-5/16-24-HEX-JAM-CP | 2 |
| 1 | 22674G1 | FUSE BLOCK (5-FUSE) | 1 |
| 2 | 01041G01 | RIVET, BULBEX, 5/32 DIA | 2 |
| 3 | 18392G1 | FUSE-15 AMP | 3 |
| 1 | 32860G1 | HORN | 1 |
| 1 | 00559G7 | FLAT WASHER, 1/4" STAINLESS STEEL | 1 |
| 00891G2 | LOCK NUT STAINLESS STEEL | ||
| 1 | 17318G1 | SWITCH/NUT/CAP-HORN-FLOOR MOUNT* | 1 |
| 1 | 17318G2 | HORN SWITCH CAP ONLY | 1 |
| 1 | 27068G01 | BOOT-HORN SWITCH-FLOOR MOUNTED | 1 |
| 1 | 19233G1 | DECAL-HORN | 1 |
| 2 | 71055G01 | RIVET-3/16 X .38 GRIP ALUMINUM | 2 |
| 2 | 20209G3 | HEADLIGHT (W/O BRACKET) INCLUDES ITEM 94 | 2 |
| 2 | 00906G6 | SCREW-TAPPING,FLAT HD,PH#10 TEXT | 2 |
| 2 | 74337G01 | ASSEMBLY,JUMPER WIRE HEADLIGHT | 2 |
| 2 | 20570G3 | LIGHT ASM - TURN/MARKER-AMBER (LX)* INCLUDES ITEMS 98 - 103 | 2 |
| 1 | 20574G3 | TURN SGNL/TAILLGHT-AMBER-LENS | 1 |
| 1 | 00660G7 | WASHER-SS STAINLESS STEEL | 1 |
| 1 | 20606G1 | WIRE ASS'Y. -JUMPER | 1 |
| 1 | 00567G7 | WASHER-LOCK-1/4-ZP | 1 |
| 1 | 00532G1 | NUT-1/4-20-HEX-CP | 1 |
| 1 | 18995G1 | PUSH-ON TERMINAL MALE | 1 |
| 20574G5 | LENS | ||
| 2 | 00118G5 | SC-TP-PAN-HEAD-PHPS 5/8 #6-18 | 2 |
| 1 | 74056G01 | JUMPER WIRE-RH PASSENGER SIDE | 1 |
| 1 | 74056G02 | JUMPER WIRE-LH DRIVER SIDE | 1 |
| 2 | 32739G2 | TAILLIGHT ASSY. COMPLETE | 2 |
| 75107G01 | TURN SIGNAL KIT INCLUDES ITEMS 113 - 117 | ||
| 1 | 17867G1 | TURN SIGNAL SWITCH (text) WITH MOUNTING HARDWAREINCLUDES ITEM 114 | 1 |
| 1 | 21640G1 | FLASHER-TURN SIGNAL | 1 |
| 1 | 32307G3 | LOOM FLEX-3/8 | 1 |
| 2 | 17618G1 | CLAMP - NYLON | 2 |
| 1 | 20965G3 | COVER-STEERING COLUMN-19.00 | 1 |
| 1 | 72228G01 | HARNESS-ACCESSORY-GAS-MED/TXT ! ACCESSORY | 1 |
| 1 | 33639G03 | IGN SWTCH-W/LTS-IND KEYED (TEXT) WITH LIGHTS, INDIVIDUALLY KEYED | 1 |
| 1 | 00568G6 | WASHER-LK-SH-X-ZP 3/4 | 1 |
| 1 | 17137G1 | NUT-FACE-KEY SWITCH | 1 |
| 1 | 17063G1 | KEY, STANDARD FLEET AND UTILITY | 1 |
| 1 | 73041G01 | WIRING HARNESS,KEY SWITCH KEY SWITCH | 1 |
| 1 | 73030G04 | SVC-PLATE,CONSOLE INSERT-KEY/FG/OL FUEL GAUGE AND OIL LIGHT | 1 |
| 1 | 71131G01 | SVC-DECAL, CONSOLE - OIL LIGHT, FUEL OIL LIGHT AND FUEL GAUGE WITH HEADLIGHTS | 1 |
| 1 | 21553G1 | SVC-GAUGE - FUEL | 1 |
| 1 | 23474G1 | LIGHT-LOW OIL/FUEL | 1 |
| 1 | 74311G01 | SVC-HARNESS,FUEL GAUGE/OIL INDICATOR OIL LIGHT/FUEL GAUGE | 1 |
| 1 | 25978G122 | SVC-WIRE-18 GAUGE | 1 |
| 2 | 33623G02 | RIVET, DRIVE, PLASTIC, BLACK | 2 |
| 74444G01 | ASSY,CON INT-W/POW OUT INCLUDES ITEMS 143 - 146 | ||
| 1 | 71077G03 | PLATE, CONSOLE INSERT/STROBE PWR ! | 1 |
| 1 | 35966G01 | DECAL WH BALL HLDR W/OUTLET HOLES ! CONSOLE INSERT PLATE | 1 |
| 1 | 71078G01 | OUTLET, POWER (12V) 12 VOLT | 1 |
| 2 | 14601G10 | RIVET-ALUMINUM-5/32-BLACK ALUMINUM | 2 |
| 3 | 33623G01 | RIVET, DRIVE, PLASTIC, BLACK | 3 |
| 1 | 71081G01 | OBS-POWER OUTLET, HARNESS POWER OUTLET | 1 |
| 1 | 75114G02 | HOUR METER KIT-GAS INCLUDES ITEMS 152 - 156 | 1 |
| 21573G1 | HOUR METER (METER ONLY) | ||
| 1 | 74019G02 | BRACKET, HOUR METER | 1 |
| 2 | 00379G4 | SC-M-PP-ZP (#10-24 X 1/2) | 2 |
| 2 | 14390G10 | NUT-LK PLAS INS 10-24 UNC-2B | 2 |
| 1 | 75117G01 | HARNESS-HR METER HOUR METER | 1 |
