Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 71262G04 | SEAT BACK SUPPORT ELE | 1 |
| 1 | 00715G2 | SC-TH'D RLG 5/16-18X.80 HWH | 1 |
| 2 | 00438G8 | SCREW-5/16-18X1-CAP-HEX | 2 |
| 2 | 00642G8 | WASHER-5/16 | 2 |
| 2 | 11098G6 | NUT-LOCK-PLASTIC INSERT | 2 |
| 1 | 71263G01 | ACCESS COVER (ELEC) | 1 |
| 3 | 18436G1 | RIVET-DRIVE | 3 |
| 2 | 75900G02 | BRKT SEAT BACK SUPT | 2 |
| 4 | 00427G2 | SCREW-3/8-16X1-1/4 | 4 |
| 2 | 00560G1 | WASHER-3/8-FL-B-CP | 2 |
| 2 | 11098G5 | NUT-LOCK-LIGHT-3/8-16 | 2 |
| 1 | 71274G01 | SEAT BACK ASSY WHITE WORKHORSE 800 | 1 |
| 1 | 71274G02 | SEAT BACK ASSY BLACK WORKHORSE 800 | 1 |
| 1 | 71274G03 | SEAT BACK ASSY TAN WORKHORSE 800 | 1 |
| 1 | 71274G04 | SEAT BACK ASSY GRAY WORKHORSE 800 | 1 |
| 1 | 71274G05 | SEAT BACK ASSY OYSTER WORKHORSE 800 | 1 |
| 1 | 71274G06 | SEAT BACK ASSY SPECIAL WORKHORSE 800 | 1 |
| 1 | 71274G07 | SEAT BACK ASSY BROWN WORKHORSE 800 | 1 |
| 18144G1 | WHITE SEAT BACK COVER | ||
| 1 | 18144G2 | COVER-SEAT BACK-CC/PC/TRK-WHT | 1 |
| 1 | 18144G3 | COVER-SEAT BACK-CC/PC/TRK-BLK | 1 |
| 1 | 18144G4 | COVER-SEAT BACK-CC/PC/TRK-TAN | 1 |
| 1 | 18144G5 | COVER-SEAT BACK-CC/PC/TRK-GRAY | 1 |
| 1 | 18144G6 | COVER-SEAT BACK-CC/PC/TRK-OYST | 1 |
| 1 | 18144G7 | COVER-SEAT BACK-CC/PC/TRK-NSC | 1 |
| 1 | 18144G8 | COVER-SEAT BACK-ST350/SPORT-BROWN | 1 |
| 1 | 74889G01 | COVER SEAT BACK BLACK | 1 |
| 4 | 605056 | SCREW W/PATCHLOCK 1/4 - 20X1 | 4 |
| 4 | 00664G7 | WASHER-LK-SS-.255/.263 | 4 |
| 1 | 71611G01 | SEAT BOTTOM ASSY, WHITE (ELEC) | 1 |
| 1 | 71611G02 | SEAT BTM ASSY-WHITE-TXT-NO HIP RE | 1 |
| 1 | 71611G03 | SEAT BOTTOM ASSY, GRAY (ELEC) | 1 |
| 1 | 71611G04 | SEAT BTM ASSY-GRAY-TXT-NO HIP REST | 1 |
| 1 | 71611G05 | SEAT BOTTOM ASSY,OYSTER | 1 |
| 1 | 71611G06 | SEAT BTM ASSY-OYSTER-TXT-NO HIP R | 1 |
| 1 | 71611G07 | SEAT BOTTOM ASSY, TAN (ELEC) | 1 |
| 1 | 71611G08 | SEAT BTM ASSY-TAN-TXT-NO HIP REST | 1 |
| 71611G09 | SPECIAL | ||
| 71611G10 | SEAT BOTTOM ASSEMBLY-SPECIFY COLOR-MEDALIST-W/O HI | ||
| 1 | 71611G11 | SEAT BOTT ASY, WH (GAS) | 1 |
| 1 | 71611G12 | SVC-SEAT BOTTOM ASSY, GRAY (GAS) | 1 |
| 1 | 71611G13 | SVC-SEAT BOTTOM ASSY, OYSTER (GAS) | 1 |
| 71611G14 | SEAT BOTTOM ASSY, TAN G | ||
| 1 | 71611G15 | SVC-SEAT BOTTOM ASSY, SPEC (GAS) | 1 |
| 1 | 71611G16 | SEAT BOTTOM ASSY,BROWN (GAS) | 1 |
| 1 | 71611G17 | ASSEMBLY, SEAT BOTTOM - BLACK | 1 |
| 1 | 71611G19 | ASSEMBLY, SEAT BOTTOM - Brown | 1 |
| 1 | 71611G21 | SVC-SEAT BTM ASSY BLACK GAS | 1 |
| 1 | 71611G33 | SVC-SEAT BOTTOM ASM, RED ON BLK G | 1 |
| 1 | 71611G35 | SEAT BTTM ASM,RED ON BLK | 1 |
| 1 | 71602G01 | COVER SEAT BTM WHITE | 1 |
| 1 | 71602G02 | COVER SEAT BTM GRAY | 1 |
| 1 | 71602G03 | COVER SEAT BTM OYSTER | 1 |
| 1 | 71602G04 | COVER SEAT BTM TAN | 1 |
| 1 | 71602G05 | COVER SEAT BTM NSC | 1 |
| 1 | 71602G06 | COVER SEAT BTM BLACK | 1 |
| 1 | 71602G07 | COVER SEAT BTM BROWN | 1 |
| 71602G08 | NLA COVER SEAT BTM SLATE BLUE | ||
| 1 | 71012G01 | TRIM-SEAT BOTTOM | 1 |
| 1 | 71702G01 | ARMREST/HIP RESTRAINT-LH | 1 |
| 2 | 71610G01 | HINGE-SEAT | 2 |
| 6 | 00720G08 | SCREW-WD-FP-ZP #12 X 1 | 6 |
| 1 | 71204G01 | SCREW-1/4-20 X 7/8-W/PATCH LK | 1 |
| 1 | 71701G01 | ARMREST/HIP RESTRAINT-RH | 1 |
