Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8GL-21940-03-00 | FRONT FRAME COMP. | 1 |
| 2 | 8GL-2194E-00-00 | BRACKET, ENGINE | 1 |
| 3 | 90185-08054-00 | NUT, SELF-LOCKING | 3 |
| 4 | 95827-08016-00 | BOLT, FLANGE | 12 |
| 5 | 90201-086A3-00 | WASHER, PLATE | 1 |
| 6 | 8JJ-21950-00-00 | REAR FRAME COMP. | 1 |
| 7 | 8JJ-21950-09-00 | REAR FRAME COMP. | 1 |
| 8 | 8HK-21926-00-00 | REINFORCEMENT, FOOTREST 1 | 1 |
| 9 | 8HK-21936-00-00 | REINFORCEMENT, FOOTREST 2 | 1 |
| 10 | 8HL-21943-00-00 | BRACKET, MAIN TRACK 1 | 1 |
| 11 | 8HL-21953-00-00 | BRACKET, MAIN TRACK 2 | 1 |
| 12 | 8FU-21919-00-00 | BRACKET, MAIN TRACK 3 | 2 |
| 13 | 8HL-21944-00-00 | BRACKET, REAR TRACK SUS | 1 |
| 14 | 8HL-21954-00-00 | BRACKET, REAR TRACK SUS | 1 |
| 15 | 95812-10020-00 | BOLT, FLANGE | 4 |
| 16 | 90201-10035-00 | WASHER, PLATE | 2 |
| 17 | 8GL-2194H-00-00 | PROTECTOR, MUFFLER | 1 |
| 18 | 8GL-2197N-00-00 | BRACKET 7 | 1 |
| 19 | 8HL-21923-00-00 | REINEFORCEMENT, FRAME REA | 1 |
| 20 | 8CR-2194N-00-00 | BRACKET, FUEL TANK 1 | 2 |
| 21 | 8HL-21917-01-00 | PANEL, SUB FRAME 6 | |
| 22 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELL QTY:127 | 1 |
| 23 | 8GL-22512-00-00 | BRACKET 8 | 4 |
| 24 | 8GL-21295-00-00 | NUT | 1 |
| 25 | 90267-48010-00 | RIVET, BLIND (4.8X12 YELLOW | 6 |
| 26 | 90267-48023-00 | RIVET, BLIND (4.8X12.1 YELL | 55 |
| 27 | 8HK-21961-00-00 | PATCH 1 | 2 |
| 28 | 8HK-21963-00-00 | PATCH 3 | |
| 29 | 8HK-21964-00-00 | PATCH 4 | |
| 30 | 8HK-21965-00-00 | PATCH 5 | 1 |
| 31 | 8HK-21966-00-00 | PATCH 6 | 1 |
| 32 | 90267-48176-00 | RIVET, BLIND (4.8X17 YELLO | 14 |
| 33 | 90267-48177-00 | RIVET, BLIND (4.8X14 YELLO | 18 |
| 34 | 8GL-21925-00-00 | REINF., HOUSING 1 | 1 |
| 35 | 8GL-21930-00-00 | HOUSING, REINF SUB-ASSY (R.H) | |
| 36 | 93306-20601-00 | BEARING | 1 |
| 37 | 99009-62500-00 | CIRCLIP | 1 |
| 38 | 93102-30012-00 | OIL SEAL | 1 |
| 39 | 8HA-12440-00-00 | HEAT EXCHANGER ASSY | 1 |
| 40 | 8GL-21915-00-00 | PANEL, SUB FRAME 4 | 1 |
| 41 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW | 41 |
| 42 | 92012-08016-00 | BOLT, BUTTON HEAD | 2 |
| 43 | 97012-08016-00 | BOLT | 8 |
| 44 | 90267-48010-00 | RIVET, BLIND (4.8X12 YELLOW) | 5 |
| 45 | 90462-08061-00 | CLAMP | 1 |
| 46 | 90462-08064-00 | CLAMP | 1 |
| 47 | 90201-08512-00 | WASHER, PLATE | 8 |
| 48 | 8GL-21960-00-00 | FOOTREST COMP. 1 | 1 |
| 49 | 8GL-21970-02-00 | FOOTREST COMP. 2 | 1 |
| 50 | 8JH-83386-00-00 | STAY, BUZZER | 1 |
| 51 | 90480-14004-00 | GROMMET | 2 |
| 52 | 90387-07391-00 | COLLAR | 2 |
| 53 | 90201-06057-00 | WASHER, PLATE | 2 |
| 54 | 95822-06025-00 | BOLT, FLANGE | |
| 55 | 90462-06022-00 | CLAMP | 1 |
| 56 | 90267-48023-00 | RIVET, BLIND (4.8X12.1 YELLOW) | 1 |
| 57 | 95827-10030-00 | BOLT, FLANGE | 2 |
| 58 | 8HA-1241A-00-00 | HEAT EXCHANGER ASSY 4 | 1 |
| 59 | 90210-06006-00 | WASHER, SEAL | 1 |
| 60 | 97022-06010-00 | BOLT, HEXAGON | 1 |
| 61 | 8GL-21920-00-00 | HOUSING, REINF SUB-ASSY (L.H) | 1 |
| 62 | 95812-08020-00 | BOLT, FLANGE | 2 |
| 63 | 8GL-21916-00-00 | PANEL, SUB FRAME 5 | 1 |
| 64 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW | 10 |
| 65 | 8GL-2194L-00-00 | STAY, MUFFER | 1 |
| 66 | 8GL-21946-00-00 | BRACKET, SEAT FITTING | 2 |
| 67 | 90176-06016-00 | NUT, CAP | 8 |
| 68 | 8GL-22151-00-00 | SEAL, GUARD | 2 |
| 69 | 8GL-22152-00-00 | SEAL, GUARD | 2 |
| 70 | 8GL-21967-00-00 | PATCH 7 | 2 |
| 71 | 8GL-21988-00-00 | PATCH 8 | 1 |
| 72 | 8GL-27471-00-00 | BAR, FOOTREST 1 | 1 |
| 73 | 8GL-27472-00-00 | BAR, FOOTREST 2 | 1 |
| 74 | 92012-06014-00 | BOLT, BUTTON HEAD | 4 |
| 75 | 95812-06012-00 | BOLT, FLANGE | |
| 76 | 8GL-21151-00-00 | BRACKET, REAR FENDER 1 | 1 |
| 77 | 8GL-21152-00-00 | BRACKET, REAR FENDER 2 | 1 |
| 78 | 180-22117-00-00 | CAP | 2 |
| 79 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 46 |
| 80 | 90267-48016-00 | RIVET, BLIND (4.8X16.4 YELLOW) | 4 |
| 81 | 8GL-21852-00-00 | DAMPER | 1 |
| 82 | 8GL-2197B-00-00 | PROTECTOR, FRAME | 1 |
| 83 | 90267-48023-00 | RIVET, BLIND (4.8X12.1 YELLOW) | 12 |
| 84 | 90520-05012-00 | DAMPER, PLATE | 1 |
