Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 2707-771 | Complete Chassis Assembly - Green | 1 |
| 1 | 2707-995 | Tunnel Assembly - Green (inc. 2-13) | 1 |
| 1 | 2707-993 | Tunnel, Front - Assembly - Green (inc. 3-4) | 1 |
| 1 | 2707-342 | Bracket, Mounting - Suspension - Right - Green | 1 |
| 1 | 2707-343 | Bracket, Mounting - Suspension - Left - Green | 1 |
| 1 | 8060-686 | Rivet - Zinc Zinc | 1 |
| 14 | 1623-206 | Rivet | 14 |
| 6 | 8422-502 | Nut, Lock | 6 |
| 1 | 2707-124 | Bracket, Mounting - Rear Spar - Right - Green | 1 |
| 1 | 2707-125 | Bracket, Mounting - Rear Spar - Left - Green | 1 |
| 6 | 8476-512 | Screw, Machine | 6 |
| 2 | 1623-257 | Rivet | 2 |
| 1 | 8060-682 | Rivet Zinc | 1 |
| 1 | 2707-984 | Tunnel, Rear - Green | 1 |
| 1 | 8060-482 | Rivet | 1 |
| 1 | 2707-315 | End Cap, Tunnel - Green | 1 |
| 2 | 8476-820 | Screw, Machine | 2 |
| 1 | 2707-822 | Support, Footrest - Right - Green | 1 |
| 1 | 2707-823 | Support, Footrest - Left - Green | 1 |
| 2 | 8427-802 | Nut, Lock | 2 |
| 0744-090 | Kit, Tool | ||
| 4 | 8468-535 | Screw, Machine | 4 |
| 9 | 1623-637 | Clip, U-Nut | 9 |
| 1 | 2707-820 | Footrest - Right - Green | 1 |
| 1 | 2707-821 | Footrest - Left - Green | 1 |
| 4 | 8470-516 | Screw, Machine | 4 |
| 1 | 1607-646 | Protector, Chain Case | 1 |
| 1 | 8061-708 | Rivet | 1 |
| 1 | 1607-645 | Protector, Brake Disc | 1 |
| 1 | 2707-660 | Shield, Brake Disc - Green | 1 |
| 2 | 8408-613 | Screw, Cap | 2 |
| 1 | 8470-520 | Screw, Machine | 1 |
| 1 | 1623-130 | Rivet | 1 |
| 2 | 2707-346 | Roll, Tunnel - Green | 2 |
| 1 | 0630-317 | Protector, Harness - Taillight Extension | 1 |
| 1 | 1623-241 | Rivet | 1 |
| 1 | 2707-336 | Gusset, Running Board - Right - Green | 1 |
| 1 | 2707-337 | Gusset, Running Board - Left - Green | 1 |
| 1 | 2707-338 | Gusset, Tunnel Roll - Right - Green | 1 |
| 1 | 2707-339 | Gusset, Tunnel Roll - Left - Green | 1 |
| 2 | 0621-990 | Decal, Reflector - Red | 2 |
| 2 | 8470-510 | Screw, Machine | 2 |
| 1 | 0730-230 | Bracket, Mounting - Taillight - Green | 1 |
| 1 | 0609-898 | Taillight, LED | 1 |
| 1 | 6606-394 | Snowflap | 1 |
| 1 | 5611-852 | Decal, Warning - Towing (French) | 1 |
| 1 | 5611-853 | Decal, Warning - Towing (English) | 1 |
| 6 | 8061-706 | Rivet | 6 |
| 1 | 2707-590 | Bumper, Rear - Black | 1 |
| 2 | 8476-620 | Screw, Machine | 2 |
| 2 | 8427-602 | Nut, Hex | 2 |
| 1 | 3621-556 | Decal, Tunnel - Rear - Right - Green | 1 |
| 1 | 3621-557 | Decal, Tunnel - Rear - Left - Green | 1 |
| 1 | 3621-550 | Decal, Tunnel - "153" - Right - Green | 1 |
| 1 | 3621-551 | Decal, Tunnel - "153" - Left - Green | 1 |
| 7639-434 | BAG,SHOVEL PACK (inc. 48-52) | ||
| 4 | 2623-204 | RING,CAMLOCK(EA) | 4 |
| 4 | 8468-525 | SCREW,MACH-TSPNH M5X0.8X25 CL8.8 BLK | 4 |
| 4 | 2623-203 | SPOOL,CAMLOCK(EA) | 4 |
| 0423-377 | WASHER,LOCK-EXT M5 | ||
| 8431-503 | NUT,HEX REG NYLOCK M5-.8 Z&BLK | ||
| 1 | 8060-706 | Rivet Black | 1 |
| 2 | 8060-702 | Rivet - Black | 2 |
