Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 11300-MGE-D00 | COVER ASSY., R. | 1 |
| 1 | 11332-MBZ-D00 | CAP (45MM) | 1 |
| 1 | 11360-MGE-D00 | COVER, R. (INNER) | 1 |
| 1 | 11362-MGE-D01 | PLATE, COVER (INNER) | 1 |
| 1 | 11366-MGE-D00 | PIPE, COVER (INNER) | 1 |
| 1 | 11367-MGE-D00 | ORIFICE (1.1MM) | 1 |
| 1 | 11370-MGE-D00 | BASE, OIL PASSAGE PIPE | 1 |
| 1 | 11373-MGE-D00 | PIPE, OIL FILTER | 1 |
| 1 | 11375-MGE-D00 | CAP, R. COVER | 1 |
| 1 | 11376-MGE-D00 | COVER, OIL FILTER | 1 |
| 1 | 11379-MGE-D01 | SEAL, RUBBER | 1 |
| 1 | 11390-MGE-D00 | PIPE, OIL PASSAGE | 1 |
| 1 | 15412-MGE-D01 | ELEMENT, OIL FILTER | 1 |
| 1 | 15413-MC8-000 | RUBBER, FILTER | 1 |
| 1 | 15414-KF0-000 | SPRING, OIL FILTER ELEMENT SETTING | 1 |
| 1 | 15611-KA4-710 | CAP, OIL FILLER | 1 |
| 1 | 22711-MGE-D00 | PIPE A, FEED | 1 |
| 1 | 22712-MGE-D00 | PIPE B, FEED | 1 |
| 1 | 22720-MGE-D00 | GUIDE, FEED PIPE | 1 |
| 3 | 28660-RFH-013 | SENSOR ASSY., OIL PRESSURE | 3 |
| 1 | 32158-MGE-D00 | STAY, CONNECTOR | 1 |
| 1 | 38810-MGE-D01 | SENSOR ASSY., ANGLE (40DEGREE) | 1 |
| 1 | 38815-MGE-D00 | COVER, ANGLE SENSOR | 1 |
| 1 | 38816-MGE-D00 | COLLAR, SENSOR COVER | 1 |
| 2 | 64951-MGE-D00 | MAT A, ENGINE GUARD | 2 |
| 1 | 64952-MGE-D00 | MAT B, ENGINE GUARD | 1 |
| 1 | 64960-MGE-D00ZA | GUARD SET, R. ENGINE COVER *NH437M* (MAT RAY SILVER) Candy tahitian blue PB215C; | 1 |
| 1 | 83551-MGE-D00 | MAT A, R. ENGINE COVER (UPPER) | 1 |
| 2 | 83645-GG0-000 | BAND, NYLON | 2 |
| 1 | 90011-MGE-D00 | BOLT, KNOCK (6MM) | 1 |
| 3 | 90016-GHB-640 | BOLT, FLANGE (6X18) | 3 |
| 3 | 90016-GHB-660 | BOLT, FLANGE (6X22) | 3 |
| 13 | 90016-GHB-680 | BOLT, FLANGE (6X28) | 13 |
| 1 | 90016-GHB-710 | BOLT, FLANGE (6X40) | 1 |
| 1 | 90016-GHB-780 | BOLT, FLANGE (6X75) | 1 |
| 2 | 90089-KAS-900 | BOLT, FLANGE SOCKET (5X14) | 2 |
| 1 | 90109-371-000 | BOLT, SEALING (8MM) | 1 |
| 3 | 90114-MGE-D00 | BOLT, SPECIAL (6X15) | 3 |
| 1 | 90421-KM1-003 | WASHER, SEALING | 1 |
| 3 | 91301-MEH-003 | O-RING (13X1.5) | 3 |
| 1 | 91301-ML7-003 | O-RING (48.1X3.6) (ARAI) | 1 |
| 1 | 91302-KF0-003 | O-RING (54X2.4) (ARAI) | 1 |
| 1 | 91303-428-003 | O-RING (7.7X2.5) | 1 |
| 1 | 91307-KF0-003 | O-RING (18X3) (ARAI) | 1 |
| 1 | 91307-MGE-D01 | O-RING (81X2.2) | 1 |
| 1 | 91308-MGE-D01 | O-RING (46X1.9) | 1 |
| 1 | 91308-PY4-003 | O-RING (10.7X1.9) | 1 |
| 1 | 91310-MGE-D01 | O-RING (16.5X2.5) | 1 |
| 2 | 91311-MGE-D01 | O-RING (9.8X2.4) | 2 |
| 1 | 91315-PC9-004 | O-RING (6X1.5) (N0K) | 1 |
| 1 | 91317-P4V-004 | O-RING (9.8X1.9) (ARAI) | 1 |
| 3 | 91319-ME5-003 | O-RING (5.5X1.4) | 3 |
| 1 | 93903-24280 | SCREW, TAPPING (4X10) | 1 |
| 2 | 94301-06100 | PIN, DOWEL (6X10) | 2 |
| 2 | 94301-08100 | PIN, DOWEL (8X10) | 2 |
| 1 | 94301-08140 | PIN, DOWEL (8X14) | 1 |
| 1 | 94302-05080 | PIN B, DOWEL (5X8) | 1 |
| 1 | 94303-05080 | PIN, DOWEL (5X8) | 1 |
| 1 | 95701-06014-00 | BOLT, FLANGE (6X14) | 1 |
| 10 | 95701-06030-00 | BOLT, FLANGE (6X30) | 10 |
| 1 | 83500-MGE-D50ZA | COVER SET, R. ENGINE (UPPER) *TBLACK* (WL) (BLACK) Candy tahitian blue PB215C; | 1 |
| 1 | 91011-MGE-D01 | BEARING, RADIAL BALL LLU (6810) | 1 |
