Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| M5142866 | RH Runner Ass’Y Includes 1 to 4 | ||
| M5142865 | LH RUNNER ASS?Y Includes 1 to 4 | ||
| 1 | M5142864 | Runner | 1 |
| 1 | M5344811 | Rh Support | 1 |
| M5344810 | Lh Support | ||
| 1 | M539673 | Rh Support | 1 |
| 1 | M539672 | Lh Support | 1 |
| M544212 | RIVET | ||
| 2 | 570023100 | RUBBER STOPPER | 2 |
| 1 | 207064044 | Hex. Screw M6 X 40 | 1 |
| M548387 | Washer | ||
| 1 | 232561414 | Elastic Stop Nut M6 | 1 |
| 2 | M5442328 | Rubber Stopper | 2 |
| 1 | 207063044 | Hex. Screw M6 X 30 | 1 |
| M548470 | Plate | ||
| 2 | 605348954 | Runner Protector | 2 |
| 1 | 207162544 | Hex. Screw M6 X 25 | 1 |
| 1 | 234061410 | Flat Washer 6 mm | 1 |
| 8 | M33200 | Nut M6 | 8 |
| 2 | M549582 | Runner Shoe | 2 |
| 1 | 207162044 | Hex. Screw M6 X 20 | 1 |
| M538796 | Welded Front Arm | ||
| 8 | M31046 | Slide Bearing | 8 |
| 2 | M538945 | Rear Cross Shaft | 2 |
| 4 | M548799 | Spring Support | 4 |
| M538802 | Axle | ||
| M548469 | Plate Support | ||
| M548841 | Sleeve | ||
| 1 | M5241177 | Lh Spring | 1 |
| 1 | M5241178 | Rh Spring | 1 |
| M546599 | Cross Shaft | ||
| M5445988 | STOPPER STRAP | ||
| M546065 | Sleeve | ||
| M40122 | Hex. Screw | ||
| 1 | 232581414 | Hex. Elastic Stop Nut M8 | 1 |
| M538801 | Welded Rear Arm | ||
| M538803 | Shaft | ||
| 1 | M5440350 | Rh Lever | 1 |
| 1 | M5440349 | Lh Lever | 1 |
| 6 | M545758 | Sleeve | 6 |
| 1 | 207084544 | Hex. Screw M8 X 45 | 1 |
| 1 | M548946 | Essieu *Axle | 1 |
| M23016 | SHOCK | ||
| M544417 | CUSHION | ||
| 1 | 207005044 | Hex. Screw M10 X 1.5 X 50 | 1 |
| 1 | 233601416 | Elastic Locking Nut M10 X 1.5 | 1 |
| M538806 | Rh Spring | ||
| M538805 | Lh Spring | ||
| M548804 | Spring Support | ||
| 1 | 572030900 | RH ADJUST CAM | 1 |
| 1 | 572030800 | LH ADJUST CAM | 1 |
| 2 | 503189568 | Wheel 165 Ass’Y | 2 |
| 4 | M31001 | Circlip *Circlip | 4 |
| M5445985 | Support Shaft | ||
| M5444098 | Sleeve L=29 | ||
| 10 | M40335 | Screw | 10 |
| 1 | 207005544 | Hex. Screw M10 X 55 | 1 |
| 1 | M40042 | Vis *Screw | 1 |
| 1 | 207181644 | Hex. Screw M8 x 16 | 1 |
| 1 | 503183100 | Washer | 1 |
| M40337 | Hex. Screw | ||
| 4 | M31007 | Circlip | 4 |
| 2 | 503191029 | Wheel 135 | 2 |
| 1 | 503189534 | Cushion | 1 |
| M31091 | SHIM | ||
| M535455 | RUBBER STOPPER | ||
| 605251784 | EXTENSION TUBE RH | ||
| 605251783 | EXTENSION TUBE LH | ||
| M548262 | Protector | ||
| M5346739 | SLEEVE | ||
| M5445986 | Shaft | ||
| M5440377 | BOLT-EYE ADJUSTER | ||
| 1 | M25004 | Spring Plate | 1 |
| 2 | M20011 | Washer | 2 |
| 1 | 232006414 | Hex. Nut M10 X 1.5 | 1 |
| 1 | M542105 | SLEEVE L=176 | 1 |
| 2 | 605452332 | Spacer | 2 |
| M40239 | SCREW | ||
| 1 | 503183300 | Washer | 1 |
| M40050 | Hex. Screw With Nylon Patch | ||
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 2 | M5343191 | PROTECTOR | 2 |
| 1 | M40064 | Hex. Screw | 1 |
| 4 | M40314 | Screw M10 X 30 | 4 |
| 4 | 503190785 | Wheel 135, Yellow Includes 78 to 80 | 4 |
| 1 | 405404500 | Ball Bearing 6205 | 1 |
| 371901700 | CIRCLIP | ||
| 4 | 503190817 | Wheel 165 mm Yellow | 4 |
| M548944 | AXLE | ||
| 2 | M5440645 | Plaque Adj. *Plate-Adj. | 2 |
