Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2681459 | DESC NOT_AVAILABLE (500 SKS) | ||
| 2681424 | SEAT ASM,(CLASSIC) (Incl. 2-7, 12 73) (500 Classic) | ||
| 2681385 | SEAT ASM,(INDY500) (Incl. 2-7, 12 73) (500 Only) | ||
| 2681386 | COVER,SEAT(INDY500) (500 Only) | ||
| 2681423 | COVER,SEAT(CLASSIC) (500 Classic Only) | ||
| 2681460 | COVER, SEAT (500 SKS) | ||
| 5430425 | HOUSING,TAILLIGHT | ||
| 2 | 4030015 | BULB TAILLIGHT/TACH/SPEEDO (10) | 2 |
| 4030019 | BULB, BRAKELIGHT | ||
| 5430423 | Discontinued | ||
| 7511840 | SCREW | ||
| 5 | 7542122 | NYLOK NUT | 5 |
| 2 | 7558221 | WASHER(10) | 2 |
| 5430575 | GROMMET-GAS TANK | ||
| 2681426 | COVER,TANK,(500) (500 Only) | ||
| 2681425 | COVER,TANK(CLASSIC) (500 Classic Only) | ||
| 2681290 | BUCKLE&STRAP | ||
| 1 | 5810142 | GAS CAP GASKET | 1 |
| 1 | 2511149 | GAS CAP WITH GAUGE | 1 |
| 1 | 7042020 | SPRING, TANK | 1 |
| 5221722 | STRAP,GASTANK,BLK. | ||
| 5420126 | Discontinued | ||
| 2511150 | TANK,GAS | ||
| 1 | 7052037 | FUEL PICKUP WITH FILTER, 105 MI | 1 |
| 1 | 7052023 | FITTING, OUTLET | 1 |
| 2200190 | N/A,USE COMPONENTS | ||
| 5430669 | VENT-TANK | ||
| 4 | 7511863 | SCREW | 4 |
| 34 | 7621457 | RIVET | 34 |
| 7080288 | PLUG (500 Only) | ||
| 6 | 7621402 | POP RIVET | 6 |
| 2200250 | FOOTREST ASM,LH | ||
| 2200254 | FOOTREST ASM,RH | ||
| 2200303 | FOOTREST,LH,(650) (500 Classic Only) | ||
| 2200332 | KIT,RH.FOOTREST(SCAND) (500 Classic) | ||
| 1 | 7621452 | RIVET | 1 |
| 14 | 7621330 | POP RIVET | 14 |
| 4020035 | CLIP,WIRING | ||
| 5210728 | HINGE | ||
| 4 | 7558212 | WASHER,13/64X1/2X18GA,FL-Y (10) | 4 |
| 52 | 7621429 | RIVET | 52 |
| 2 | 5220817 | BELT RETAINER CLIP | 2 |
| 5230118 | SUBSTITUTED BY 5240965 | ||
| 1 | 7080216 | CLUTCH GUARD PIN | 1 |
| 1011664 | SUBSTITUTED BY 1011804 (500 Classic Only) | ||
| 1011746 | TUNNEL, (500) | ||
| 1011777 | DESC NOT_AVAILABLE (500 SKS) | ||
| 10 | 7661620 | RIVET | 10 |
| 3 | 7670021 | NUT, SPEED | 3 |
| 7080227 | SNAP-MALE | ||
| 7072871 | DECAL,ENG/CLUTCH | ||
| 5224347 | BUMPER,R.(N-INDY) | ||
| 5224421 | DESC NOT_AVAILABLE (500 SKS) | ||
| 7072132 | DECAL, TRACK (500 Only) | ||
| 7072874 | DECAL,TRACK,GOLD (500 Classic Only) | ||
| 5220478 | PANEL,TUNNEL,BACK | ||
| 1011694 | PANEL,CLOSE-OFF,REAR (500 SKS Only) | ||
| 1 | 5410394 | SNOW FLAP (500 Only) | 1 |
| 1 | 5410392 | SNOW FLAP (500 Classic Only) | 1 |
| 5 | 7621418 | RIVET(50) | 5 |
| 5222061 | WEARPLATE,TUNNEL | ||
| 7661818 | RIVET,SEMI-TUBE,(10) * | ||
| 5430930 | Discontinued | ||
| 2 | 2670070 | REFLECTOR, RED | 2 |
| 2 | 7512103 | BOLT | 2 |
| 4 | 7558301 | FLAT WASHER | 4 |
| 6 | 7621222 | RIVET(10) | 6 |
| 5220635 | PLATE,TUNNEL,RH | ||
| 5220634 | PLATE,TUNNEL,LH | ||
| 5810201 | FOAM, FILLER | ||
| 7072078 | DECAL(47.5'')TUNNEL | ||
| 3 | 7512193 | CARRIAGE BOLT | 3 |
| 5220406 | BRACKET, HINGE | ||
| 1011582 | SUPT., MUFFLER | ||
| 5221932 | BRACKET, GASTANK | ||
| 1011743 | BULKHEAD,(500) (500 Only) | ||
| 1011763 | DESC NOT_AVAILABLE (500 Classic Only) | ||
| 1011771 | DESC NOT_AVAILABLE (500 Special Only) | ||
| 7072653 | DECAL(36.0'')R.BUMP. (500 Only) | ||
| 7072780 | DECAL,R.BUMPER (500 Classic Only) | ||
| 7072819 | DECAL, SKS, BLUE (500 SKS Only) | ||
| 4 | 7512240 | BOLT | 4 |
| 2 | 7542451 | NYLOK NUT (500 SKS Only) | 2 |
| 7515432 | BOLT,NYLOC,BLACK (500 SKS Only) | ||
| 1011666 | BRKT,R.SUSP,LH MTG. | ||
| 1011667 | BRKT,R.SUSP,RH MTG. | ||
| 5220542 | BRKT. | ||
| 5220973 | BRKT, TOOL BOX | ||
| 1 | 8450003 | FUEL LINE, 1/4 ID | 1 |
| 7670031 | PALNUT(10) (500 Classic Only) | ||
| 5332896 | SPACER (500 Classic Only) | ||
| 7072778 | DECAL,TUNNEL STRIPE (500 Classic Only) | ||
| 7072777 | DECAL,TUNNEL STRIPE | ||
| 1 | 5220942 | PLATE,HITCH MT,BLK. | 1 |
| 5430781 | REFLECTOR | ||
| 5430925 | BOX,TOOL,(2-UP SEAT) (500 SKS) | ||
| 5430761 | DESC NOT_AVAILABLE (500 SP) | ||
| 5223798 | BRACKET-CLUTCH GUARD | ||
| 5222119 | DESC NOT_AVAILABLE | ||
| 5211122 | PLATE, BACKING (500 SKS) | ||
| 2681365 | COVER,SEAT,(2-UP) (500 SKS) | ||
| 2460226 | TAILLIGHT HARNESS | ||
| 1011697 | GRABBAR, RH (500 SKS) | ||
| 7030007 | KNOB ASM,BACKREST (500 SKS) | ||
| 1011696 | GRABBAR, LH (500 SKS) | ||
| ------- | Backrest Asm. (500 SKS) | ||
| 5220941 | BRACKET, HITCH (500 SKS) | ||
| 2200304 | FOOTREST,RH,(650) (500 Classic Only) | ||
| 1011747 | TUNNEL, (500 SKS) (500 SKS Only w/1011694) | ||
| 5224334 | BUMPER,REAR,BLK. | ||
| 5224349 | BUMPER, (SKS) (500 SKS Only) | ||
| 2681493 | SEAT ASM,(500SP) (500 SP) | ||
| 2681494 | KIT,CVR,SEAT&LN.TNK,STD,BLK (500 SP) | ||
| 2681495 | KIT,CVR,SEAT&LN.TNK,STD,BLK (500 SP) | ||
| 5510130 | STRIP-WEAR |
