Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 502007184 | Black Bottom Pan Front | 1 |
| 1 | 502007002 | Insulator | 1 |
| 4 | 293150103 | Pop Rivet 3/16" | 4 |
| 1 | 502007145 | Grille | 1 |
| 1 | 502007393 | Front Grille With Mesh Model-Extreme | 1 |
| 2 | 250100113 | Panel Nut, M6 X 1.0 | 2 |
| 2 | 250000722 | Torx Screw M6 X 20 | 2 |
| 1 | 502007188 | Black Bottom Pan Ass'y RH Includes 8 To 11, Model-LE | 1 |
| 1 | 502007187 | Black Bottom Pan Ass'y, RH Includes 8 To 11, Model-SE | 1 |
| 1 | 502007520 | Black Bottom Pan Ass'y, RH Includes 8 To 11, Model-Extreme | 1 |
| 1 | 502007006 | Insulator Model-LE & SE | 1 |
| 1 | 502007526 | Insulator Model-Extreme | 1 |
| 502007008 | INSULATOR Model-LE & SE | ||
| 1 | 502007009 | Insulator Model-LE & SE | 1 |
| 1 | 517305977 | Insulator Model-Extreme | 1 |
| 1 | 517305975 | Bottom Pan Air Vent RH Model-Extreme | 1 |
| 4 | 293150104 | Pop Rivet 3/16" Model-Extreme | 4 |
| 4 | 250200025 | Washer M5 Model-Extreme | 4 |
| 1 | 517305976 | RH Bottom Pan Grille Model-Extreme | 1 |
| 4 | 293150104 | Pop Rivet 3/16" | 4 |
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 2 | 234052450 | Flat Washer | 2 |
| 1 | 502007191 | Black Bottom Pan Rear Ass'y RH Includes 21 To 23 | 1 |
| 1 | 502007038 | Aluminium Foil | 1 |
| 44110 | Aluminum foil | ||
| 6 | 293150104 | Pop Rivet 3/16" | 6 |
| 1 | 502007196 | Black Bottom Pan Ass'y LH Includes 25 To 27, Model-LE & Extreme | 1 |
| 1 | 502007198 | Black Bottom Pan Ass'y, LH Includes 25 To 27, Model-SE | 1 |
| 1 | 502007003 | Insulator | 1 |
| 1 | 502007185 | Insulator | 1 |
| 1 | 502007195 | Black Bottom Pan Rear Ass'y LH | 1 |
| 5 | 293150104 | Pop Rivet 3/16" | 5 |
| 502007469 | BUMPER Model-LE | ||
| 1 | 502007470 | Bumper Model-SE & Extreme | 1 |
| 2 | 293730041 | Full Moon Dart 8 mm Model-LE | 2 |
| 2 | 293730047 | Black, Dart 8 mm Model-Extreme | 2 |
| 1 | 502007014 | LH Bumper Support | 1 |
| 1 | 502007015 | RH Bumper Support | 1 |
| 4 | 207664044 | Hex. Flange Screw M6 X 40 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 860200563 | PLATE_SKID B-160 KIT Model-SE | ||
| 4 | 250000757 | Button Head Torx Screw M8 X 25 S.Gr Model-SE | 4 |
| 4 | 234082410 | Flat Washer 8 mm Model-SE | 4 |
| 1 | 860200537 | Extra Bumber Paint Includes 43 To 53, Model-SE | 1 |
| XXXX | Not Available As Spare Part - Extra Bumper Model-SE | ||
| 1 | 502007022 | Lower Fastening Plate Model-SE | 1 |
| 2 | 250000717 | Torx Head Screw M6 X 16 Model-SE | 2 |
| 2 | 20117 | Washer Model-SE | 2 |
| 2 | 205084044 | Socket Head Screw M8 X 1.25 X 40 Model-SE | 2 |
| 2 | 28056 | Cover Model-SE | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 Model-SE | 2 |
| 2 | 207066044 | Hex. Screw M6 X 60 Model-SE | 2 |
| 2 | 234061410 | Flat Washer 6 mm Model-SE | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 Model-SE | 2 |
