Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 1018824-589 | CONTROL ARM WELD FRT UPR LEFT 6 [AL][EW][USE W/1912060 BRAKE LINE] | 1 |
| 1 | 1018824-619 | CONTROL ARM WELD UPR FRT LEFT 6 [AA][USE W/1912060 BRAKE LINE] | 1 |
| 1 | 1020946-385 | CONTROL ARM WELD FRT UPR LEFT C [AT]AV][LP][AU] | 1 |
| 1 | 1018824-458 | CONTROL ARM WELD UPR FRT LEFT 6 [AO][USE W/1912060 BRAKE LINE] | 1 |
| 1021732-385 | CONTROL ARM FRT UPR LEFT SIDE C [USE W/1912519 BRAKE LINE][AK][AP][AT][AV][AW][LP][NV][NW] | ||
| 1 | 1021732-589 | CONTROL ARM WELD FRT UPR LEFT 6 [USE W/1912519 BRAKE LINE][AL][EW] | 1 |
| 1 | 1021732-458 | CONTROL ARM WELD FRONT UPPER LE [USE W/1912519 BRAKE LINE][AO][AZ] | 1 |
| 1 | 1021732-619 | WELD-CTRL ARM,UPR,FR,LH,64,VDB [USE W/1912519 BRAKE LINE] | 1 |
| 1021732-385 | CONTROL ARM FRT UPR LEFT SIDE C [AW] | ||
| 1 | 1018825-458 | CONTROL ARM WELD FRT UPR RIGHT [AO][USE W/1912062 BRAKE LINE] | 1 |
| 1 | 1018825-589 | CTRL ARM WELD FRT UPR RIGHT 64 [AL][EW][USE W/1912062 BRAKE LINE] | 1 |
| 1 | 1018825-619 | WELD-CTL ARM,UPR,FR,RH,64,VDBL [AA][USE W/1912062 BRAKE LINE] | 1 |
| 1 | 1020947-385 | CTRL WELD ARM FRT UPR RIGHT 64 [AT][AV][LP][AU] | 1 |
| 1 | 1021733-385 | CENTRAL ARM WELD UPR FRT RIGHT [USE W/1912520 BRAKE LINE][AK][AP][AT][AV][AW][NV][NW] | 1 |
| 1 | 1021733-589 | CTRL ARM WELD FRT UPR RIGHT 64 [USE W/1912520 BRAKE LINE][AL][EW] | 1 |
| 1021733-458 | Discontinued [USE W/1912520 BRAKE LINE][AO][AZ] | ||
| 1 | 1021733-619 | WELD-CTRL ARM,UPR,FR,RH,64,VDB [USE W/1912520 BRAKE LINE][VDKAO][VDKAZ] | 1 |
| 1 | 1021733-385 | CENTRAL ARM WELD UPR FRT RIGHT [AW] | 1 |
| 1 | 1020540-589 | CONTROL ARM WELD FRT LWR LEFT 6 [AL] | 1 |
| 1 | 1020540-619 | CONTROL ARM WELD LWR FRT LEFT 6 [AA] | 1 |
| 1 | 1018826-385 | CONTROL ARM FRT LWR LEFT SIDE C [AT][AW][AV][LP][AU][NV][NW] | 1 |
| 1 | 1018826-589 | CONTROL ARM WELD, FRONT, LOWER, [EW] | 1 |
| 1 | 1018826-458 | CONTROL ARM WELD, FRONT, LOWER, [AO][AZ] | 1 |
| 1 | 1020541-589 | CTRL ARM WELD FRT LWR RIGHT 64 [AL] | 1 |
| 1 | 1020541-619 | WELD-CTLARM,HC,LWR,FR,RH,64,VB [AA] | 1 |
| 1 | 1018827-385 | CONTROL ARM FRT LWR RIGHT SIDE [AT][AW][AV][LP][AU][NV][NW] | 1 |
| 1 | 1018827-589 | CONTROL ARM WELD, FRONT, LOWER, [EW] | 1 |
| 1018827-458 | Discontinued [AO][AZ] | ||
| 2 | 5138276 | PIVOT TUBE, 29.2 MM | 2 |
| 6 | 5138797 | PIVOT SHAFT | 6 |
| 2 | 5438641-070 | CV SHIELD, FRONT, GLOSS BLACK | 2 |
| 12 | 5439874 | STANDARD BUSHING, ORV | 12 |
| 12 | 1543367 | HD BUSHING W/ SEAL ASSEMBLY(4) [OPTIONAL] | 12 |
| 4 | 5450095 | CONTROL BUSHING ARM, IGUS | 4 |
| 6 | 7080510 | ZERK FITTING | 6 |
| 4 | 7512084 | SCREW | 4 |
| 6 | 7519043 | SCREW M10 X 1.25-6G | 6 |
| 2 | 7519285 | HEX FLANGE SCREW 10 MM X 1.25 M | 2 |
| 12 | 7547333 | NYLOC NUT | 12 |
| 8 | 7556153 | WASHER | 8 |
| 4 | 7081992 | BALL-JOINT,HARDENED,HI-MISALGN | 4 |
| 4 | 7519306 | FLANGE SCREW | 4 |
| 4 | 7710716 | RETAINING RING | 4 |
