Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 517304530 | Deep Black Hood Black-Black Model | 1 |
| 517304531 | HOOD B-229 White-White Model | ||
| 1 | 517303990 | Hood Foam | 1 |
| 1 | 517303921 | DEEP BLACK CONSOLE 800R PTEK, Black-Black Model | 1 |
| 1 | 517304109 | CONSOLE B-229 800R PTEK, White-White Model | 1 |
| 1 | 517304518 | Console Nut | 1 |
| 2 | 250000128 | Torx Truss Screw M6 X 20 | 2 |
| 2 | 250000048 | Panel Nut M6 X 1.0 | 2 |
| 1 | 250000129 | Torx Screw M6 X 16 | 1 |
| 1 | 250000128 | Torx Truss Screw M6 X 20 | 1 |
| 1 | 517304322 | Black, RH Console Includes 10 to 12, Manual Starter | 1 |
| 3 | 275500241 | Black, Cap | 3 |
| 1 | 413408300 | Loctite, Black Max, 3 ml | 1 |
| 2 | 250000113 | Screw M4 X 16, Type K-40 Manual Starter | 2 |
| 1 | 517303603 | Indicator Support Black-Black Model | 1 |
| 517304415 | INDICATOR SUPPORT White-White Model | ||
| 517304227 | Low Windshield Ass'y Includes 17 to 20, Black-Black Model | ||
| 1 | 517304226 | Low Windshield Ass'y (140) Includes 17 to 20, White-White Model | 1 |
| XXXX | Not Available As Spare Part - Low Windshield | ||
| 1 | 517303757 | Windshield Support | 1 |
| 6 | 732610072 | Push Nut | 6 |
| 3 | 517303756 | Grommet | 3 |
| 1 | 517304029 | Deep Black, RH Panel Black-Black Model | 1 |
| 1 | 517304422 | PANEL_BODY RH B-229 White-White Model | 1 |
| 1 | 517303671 | Deep Black RH Moulding Panel Black-Black Model | 1 |
| 1 | 517304420 | RH MOULDING PANEL, VIPER RED White-White Model | 1 |
| 1 | 517303622 | Grille | 1 |
| 1 | 732610072 | Push Nut | 1 |
| 1 | 241141660 | Hex. Flange Screw K40 X 16 | 1 |
| 1 | 234042600 | Flat Washer 4 mm, Stainless | 1 |
| 1 | 517304280 | RH Center Foam | 1 |
| 1 | 517303982 | RH Panel Rear Foam | 1 |
| 2 | 518325560 | Adhesive Patch | 2 |
| 1 | 517304030 | Deep Black, LH Panel Black-Black Model | 1 |
| 1 | 517304426 | PANEL_BODY LH B-229 White-White Model | 1 |
| 1 | 517303673 | Deep Black, LH Moulding Panel Black-Black Model | 1 |
| 1 | 517304427 | LH MOULDING PANEL, VIPER RED White-White Model | 1 |
| 1 | 517303983 | LH Panel Center Foam | 1 |
| 1 | 517303984 | LH Panel Lower Foam | 1 |
| 1 | 517303985 | LH Panel Upper Foam | 1 |
| 1 | 517303986 | LH Panel Rear Foam | 1 |
| 1 | 517303987 | Foam | 1 |
| 2 | 517304075 | End Piece Latch Black-Black Model | 2 |
| 517304435 | END PIECE LATCH White-White Model | ||
| 2 | 517303981 | Panel Latch | 2 |
| 1 | 517303612 | RH Panel Latch | 1 |
| 1 | 517304221 | Latch Support | 1 |
| 1 | 207652044 | Hex.Flange Screw M5 X 20 | 1 |
| 1 | 233251414 | Hex. Flange Elastic Nut M5 | 1 |
| 1 | 517303808 | LH Panel Latch | 1 |
| 1 | 293150108 | Pop Rivet 3/16” | 1 |
| 2 | 517304105 | Console Decal White-White Model | 2 |
| 1 | 517304103 | RH Decal White-White Model | 1 |
| 1 | 517304104 | LH Decal White-White Model | 1 |
