Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 24121-20C00 | COUNTERSHAFT (NT:12) MODEL K/L/M/N | ||
| 24121-20C10 | COUNTERSHAFT (NT:12) MODEL P/R/S/T | ||
| 24221-27A01 | GEAR, 2ND DRIVE (NT:16) MODEL K/L/M/N | ||
| 24221-27A10 | GEAR, 2ND DRIVE (NT:16) MODEL P/R/S/T | ||
| 1 | 09380-25013 | CIRCLIP | 1 |
| 24231-27A00 | GEAR, 3/4TH DRIVE (NT:17/20) MODEL K/L/M/N | ||
| 24231-27A10 | GEAR, 3/4TH DRIVE (NT:17/20) MODEL P/R/S/T | ||
| 24251-27A01 | GEAR, 5TH DRIVE (NT:22) | ||
| 1 | 09301-25001 | BUSH | 1 |
| 2 | 09380-25003 | RING,SNAP | 2 |
| 24261-17C00 | GEAR, 6TH DRIVE (NT:21) MODEL K/L | ||
| 24261-17C01 | GEAR, 6TH DRIVE (NT:21) MODEL M/N/P/R/S/T | ||
| 1 | 09167-25012 | WASHER,LOCK (25.1X31X1.0) | 1 |
| 1 | 09262-25051 | BEARING, RH (25X62X17) MODEL K/L/M/N/P/R | 1 |
| 09262-25115 | BEARING, RH (25X62X17) MODEL S/T | ||
| 1 | 09390-62006 | C RING (59.6X67.2X2) MODEL K/L/M/N/P/R | 1 |
| 1 | 09390-62012 | C RING MODEL S/T | 1 |
| 1 | 09285-20006 | OIL SEAL | 1 |
| 1 | 24741-27A00 | HOLDER, BEARING | 1 |
| 2 | 02122-06167 | SCREW MODEL K/L/M/N/P/R | 2 |
| 2 | 02122-06163 | SCREW MODEL S/T | 2 |
| 1 | 09263-20049 | BEARING, LH | 1 |
| 1 | 04221-07129 | PIN | 1 |
| 24131-20C00 | DRIVESHAFT | ||
| 24311-19C01 | GEAR, 1ST DRIVEN (NT:37) MODEL K/L/M/N | ||
| 24311-19C10 | GEAR, 1ST DRIVEN (NT:37) MODEL P/R/S/T | ||
| 1 | 09300-22008 | BUSH | 1 |
| 1 | 08211-20341 | WASHER, RH | 1 |
| 1 | 08211-22341 | WASHER, LH | 1 |
| 24321-20C00 | GEAR, 2ND DRIVEN (NT:33) MODEL K/L/M/N | ||
| 24321-20C10 | GEAR, 2ND DRIVEN (NT:33) MODEL P/R/S/T | ||
| 09300-28003 | BUSH | ||
| 1 | 08211-28381 | WASHER | 1 |
| 3 | 08331-11289 | CIRCLIP MODEL K/L/M | 3 |
| 3 | 08331-31286 | CIRCLIP MODEL N/P/R/S/T | 3 |
| 24331-27A00 | GEAR, 3RD DRIVEN (NT:28) MODEL K/L/M/N | ||
| 24331-27A10 | GEAR, 3RD DRIVEN (NT:28) MODEL P/R/S/T | ||
| 24332-27A00 | BUSH | ||
| 1 | 09167-28001 | WASHER, LH | 1 |
| 1 | 09167-28002 | WASHER, RH (T:1.5) | 1 |
| 1 | 09169-28001 | WASHER, RH (T:1.0) | 1 |
| 24341-27A00 | GEAR, 4TH DRIVEN (NT:28) MODEL K/L/M | ||
| 24341-27A01 | GEAR, 4TH DRIVEN (NT:28) MODEL N/P/R/S/T | ||
| 1 | 09167-28001 | WASHER, RH | 1 |
| 24351-27A00 | GEAR, 5TH DRIVEN (NT:27) | ||
| 24361-20C00 | GEAR, 6TH DRIVEN (NT:23) | ||
| 1 | 09263-20040 | BEARING (20X34X20) | 1 |
| 1 | 04221-07209 | PIN (L:20) | 1 |
| 1 | 09262-25105 | BEARING, LH MODEL K/L/M/N/P/R | 1 |
| 09262-25115 | BEARING, LH MODEL S/T | ||
| 1 | 09390-62006 | C RING MODEL K/L/M/N/P/R | 1 |
| 1 | 09283-34005 | OIL SEAL (34X62X6) | 1 |
| 24751-27A01 | PLATE | ||
| 4 | 01107-06107 | BOLT MODEL K/L/M/N/P/R | 4 |
| 4 | 01500-06123 | BOLT MODEL S/T | 4 |
| 1 | 27510-17C00 | SPROCKET, ENGINE (NT:15) | 1 |
| 1 | 08211-25402 | WASHER | 1 |
| 1 | 09180-25091 | SPACER | 1 |
| 1 | 09159-20004 | NUT | 1 |
| 1 | 01147-06168 | BOLT MODEL K/L/M/N | 1 |
| 1 | 01570-06163 | BOLT MODEL P/R/S/T | 1 |
| 1 | 08212-06222 | WASHER | 1 |
| 1 | 27600-20C00-118 | CHAIN, DRIVE (118LE) RK MODEL K/L/M/N/P/R | 1 |
| 1 | 27600-17C20-118 | CHAIN, DRIVE (118LE) RK MODEL S/T | 1 |
