Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 11300-20892 | CRANKCASE SET MODEL K/L/M/N | ||
| 11300-20893 | CRANKCASE SET MODEL P/R/S/T; Includes Item(s) 2 - 40 | ||
| 2 | 09206-13004 | PIN | 2 |
| 2 | 09206-11005 | PIN | 2 |
| 1 | 09103-06067 | BOLT (6X105) MODEL K/L/M/N/P | 1 |
| 09103-06163 | BOLT (6X105) MODEL R/S/T | ||
| 1 | 09103-08097 | BOLT (8X105) | 1 |
| 2 | 09103-08182 | BOLT (8X125) | 2 |
| 3 | 09103-08098 | BOLT (8X115) | 3 |
| 1 | 01517-06354 | BOLT MODEL K/L/M/N | 1 |
| 1 | 01517-06358 | BOLT MODEL P | 1 |
| 1 | 01550-06353 | BOLT MODEL R/S/T | 1 |
| 1 | 07110-06405 | BOLT MODEL K/L/M/N | 1 |
| 07130-06408 | BOLT MODEL P | ||
| 1 | 07130-06403 | BOLT MODEL R/S/T | 1 |
| 1 | 07110-06505 | BOLT MODEL K/L/M/N | 1 |
| 1 | 07130-06508 | BOLT MODEL P | 1 |
| 1 | 07130-06503 | BOLT MODEL R/S/T | 1 |
| 1 | 07110-06655 | BOLT MODEL K/L/M/N | 1 |
| 1 | 07130-06658 | BOLT MODEL P | 1 |
| 1 | 07130-06653 | BOLT MODEL R/S/T | 1 |
| 2 | 07110-08655 | BOLT MODEL K/L/M/N | 2 |
| 2 | 07130-08658 | BOLT MODEL P | 2 |
| 2 | 07130-08653 | BOLT MODEL R/S/T | 2 |
| 1 | 01517-08605 | BOLT MODEL K/L/M/N | 1 |
| 1 | 01517-08608 | BOLT MODEL P | 1 |
| 1 | 01550-08603 | BOLT MODEL R/S/T | 1 |
| 3 | 01517-06354 | BOLT MODEL K/L/M/N | 3 |
| 3 | 01517-06358 | BOLT MODEL P | 3 |
| 3 | 01550-06353 | BOLT MODEL R/S/T | 3 |
| 1 | 01517-06404 | BOLT MODEL K/L/M/N | 1 |
| 1 | 01517-06408 | BOLT MODEL P | 1 |
| 1 | 01550-06403 | BOLT MODEL R/S/T | 1 |
| 1 | 01550-06407 | BOLT | 1 |
| 1 | 01517-06505 | BOLT MODEL K/L/M/N | 1 |
| 1 | 01517-06508 | BOLT MODEL P | 1 |
| 1 | 01550-06503 | BOLT MODEL R/S/T | 1 |
| 1 | 01517-06605 | BOLT MODEL K/L/M/N | 1 |
| 1 | 01517-06608 | BOLT MODEL P | 1 |
| 1 | 01550-06603 | BOLT MODEL R/S/T | 1 |
| 2 | 01517-06557 | BOLT MODEL K/L/M/N/P | 2 |
| 2 | 01550-06553 | BOLT MODEL R/S/T | 2 |
| 2 | 01517-06705 | BOLT MODEL K/L/M/N | 2 |
| 2 | 01517-06708 | BOLT MODEL P | 2 |
| 2 | 01550-06703 | BOLT MODEL R/S/T | 2 |
| 1 | 01517-06805 | BOLT MODEL K/L/M/N | 1 |
| 01517-06808 | BOLT MODEL P | ||
| 1 | 01550-06803 | BOLT MODEL R/S/T | 1 |
| 4 | 09103-08105 | BOLT (8X95) | 4 |
| 01421-06408 | STUD BOLT | ||
| 1 | 01421-06608 | STUD BOLT | 1 |
| 2 | 09159-06017 | NUT MODEL K/L/M/N/P | 2 |
| 2 | 08316-10063 | NUT MODEL R/S/T | 2 |
| 2 | 09280-21008 | O RING (D:2.5,ID:21) | 2 |
| 6 | 09280-04004 | O RING (D:1.2,ID:4) | 6 |
| 09493-14002 | JET, OIL GALLERY HEAD | ||
| 2 | 09493-24010 | JET, OIL GALLERY GEAR SHIFT | 2 |
| 09493-80008 | JET, OIL GALLERY PISTON | ||
| 1 | 09168-12002 | GASKET, HOLE PLUG | 1 |
| 1 | 09247-12103 | PLUG, HOLE | 1 |
| 2 | 09168-08021 | GASKET | 2 |
| 1 | 09248-16003 | PLUG, OIL GALLERY | 1 |
| 1 | 09280-17002 | O RING (D:2.4,ID:16.8) | 1 |
| 1 | 09248-14004 | PLUG, OIL GALLERY MODEL K/L | 1 |
| 1 | 09248-14005 | PLUG, OIL GALLERY MODEL M/N/P/R/S/T | 1 |
| 1 | 09168-14002 | .GASKET (13.8X18.8X4.8) | 1 |
| 1 | 16591-06B00 | UNION, OIL FILTER STAND | 1 |
| 1 | 12228-48B00-0E0 | .BEARING, CRANK THRUST SEE ILLUSTRATION ON FIG.8(B-12) | 1 |
| 1 | 12228-48B00-0C0 | .BEARING, CRANK THRUST SEE ILLUSTRATION ON FIG.8(B-12) | 1 |
| 1 | 12228-48B00-0H0 | .BEARING, CRANK THRUST SEE ILLUSTRATION ON FIG.8(B-12) | 1 |
| 16430-27A00 | VALVE ASSY, PISTON OIL CONTRO | ||
| 4 | 09280-05007 | O RING (D:1.2,ID:4.7) | 4 |
| 1 | 09103-10237 | BOLT (10X130) MODEL K/L/M/N/P | 1 |
| 1 | 09103-10122 | BOLT (10X130) MODEL R/S/T | 1 |
| 09103-10151 | BOLT (10X175) | ||
| 4 | 01987-10555 | BOLT MODEL K/L/M/N/P | 4 |
| 4 | 01580-10553 | BOLT MODEL R/S/T | 4 |
| 2 | 09159-10020 | NUT | 2 |
| 2 | 09159-10044 | NUT MODEL K/L/M/N/P | 2 |
| 2 | 09159-10058 | NUT MODEL R/S/T | 2 |
| 2 | 08316-16105 | NUT MODEL K/L/M/N/P | 2 |
| 2 | 08316-10103 | NUT MODEL R/S/T | 2 |
| 2 | 11681-06B00 | BUSH | 2 |
| 1 | 11611-06B01 | SPACER (L:27) MODEL K | 1 |
| 1 | 11610-20C00 | SPACER (L:27) MODEL L/M/N/P/R/S/T | 1 |
| 1 | 37820-33200 | SWITCH, OIL PRESSURE MODEL K/L/M/N | 1 |
| 1 | 37820-33D00 | SWITCH, OIL PRESSURE MODEL P/R/S/T | 1 |
