Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 94510-20C00 | BRACE, COWLING | ||
| 94510-20C10 | BRACE, COWLING CALIFORNIA ONLY | ||
| 1 | 01517-08205 | BOLT | 1 |
| 2 | 01517-06125 | BOLT | 2 |
| 2 | 02142-06127 | SCREW | 2 |
| 94520-20C00 | PLATE, METER | ||
| 4 | 02142-06125 | SCREW | 4 |
| 94420-20C00 | COVER, METER (BLACK) Includes Item(s) 8 | ||
| 2 | 94635-19C10 | MOLDING | 2 |
| 4 | 03541-05085 | SCREW | 4 |
| 1 | 94527-19C00 | MOLDING, METER | 1 |
| 94426-20C00 | CUSHION, SPEEDOMETER | ||
| 94427-20C00 | CUSHION, FUEL METER | ||
| 94610-20C00 | WINDOW | ||
| 1 | 94631-20C00 | MOLDING (L:670) | 1 |
| 94637-19C00 | CAP | ||
| 4 | 09139-05022 | SCREW | 4 |
| 4 | 09161-05010 | WASHER (5.2X11.0X1.0) | 4 |
| 94460-19C00 | PLATE, CENTER | ||
| 2 | 09136-06081 | SCREW | 2 |
| 2 | 09180-06167 | SPACER | 2 |
| 2 | 09320-10015 | CUSHION (10X20X10) | 2 |
| 1 | 94638-19C00 | CUSHION, SCREEN | 1 |
| 94421-19C01-33J | PANEL, CENTER (BLACK) FOR F74 | ||
| 94421-19C01-28V | PANEL, CENTER (RED) FOR F75 | ||
| 2 | 02142-05127 | SCREW | 2 |
| 94401-21C10-F74 | COVER ASSY, COWLING,RH | ||
| 94401-21C10-F75 | COVER ASSY, COWLING,RH Includes Item(s) 26 - 33 | ||
| 68680-20C10-38K | TAPE SET, RH (BLUE) FOR F74 | ||
| 68680-20C10-0FP | TAPE SET, RH (SILVLER) FOR F75 | ||
| 68685-20C30-0YZ | TAPE, RH FOR F74 | ||
| 68685-20C30-0ZA | TAPE, RH FOR F75 | ||
| 68681-20C20-F77 | EMBLEM, RH (KATANA) FOR F74 | ||
| 68681-20C20-F76 | EMBLEM, RH (KATANA) FOR F75 | ||
| 94433-19C01-33J | COVER, METER SIDE RH (BLACK) FOR F74 | ||
| 94433-19C01-28V | COVER, METER SIDE RH (RED) FOR F75 | ||
| 2 | 03541-04105 | SCREW | 2 |
| 94631-19C10 | MOLDING | ||
| 1 | 94635-19C00 | MOLDING | 1 |
| 94438-19C00 | JOINT | ||
| 94435-19C01-33J | LID, OIL (BLACK) FOR F74 | ||
| 94435-19C01-28V | LID, OIL (RED) FOR F75 | ||
| 1 | 09139-06030 | SCREW | 1 |
| 94402-21C10-F74 | COVER ASSY, COWLING LH | ||
| 94402-21C10-F75 | COVER ASSY, COWLING LH | ||
| 94402-21C20-F74 | COVER ASSY, COWLING LH CALIFORNIA ONLY | ||
| 94402-21C20-F75 | COVER ASSY, COWLING LH CALIFORNIA ONLY; Includes Item(s) 35 - 40 | ||
| 68690-20C10-38K | TAPE SET, LH (BLUE) FOR F74 | ||
| 68690-20C10-0FP | TAPE SET, LH (SILVER) FOR F75 | ||
| 68695-20C40-0YZ | TAPE, LH FOR F74 | ||
| 68695-20C40-0ZA | TAPE, LH FOR F75 | ||
| 68691-20C10-F77 | EMBLEM, LH (KATANA) FOR F74 | ||
| 68691-20C10-F76 | EMBLEM, LH (KATANA) FOR F75 | ||
| 68691-20C20-F77 | EMBLEM, LH (KATANA) CALIFORNIA ONLY,FOR F74 | ||
| 68691-20C20-F76 | EMBLEM, LH (KATANA) CALIFORNIA ONLY,FOR F75 | ||
| 94443-19C01-33J | COVER, METER SIDE LH (BLACK) FOR F74 | ||
| 94443-19C01-28V | COVER, METER SIDE LH (RED) FOR F75 | ||
| 2 | 09139-06029 | SCREW, FRONT | 2 |
| 2 | 09160-06036 | WASHER | 2 |
| 2 | 09139-06030 | SCREW, UPPER | 2 |
| 2 | 09161-06021 | WASHER | 2 |
| 94560-19C00 | BRACKET, UPPER RH | ||
| 94570-19C00 | BRACKET, UPPER LH | ||
| 4 | 09125-06055 | SCREW | 4 |
| 94573-19C00 | NUT | ||
| 4 | 09139-06029 | SCREW | 4 |
| 4 | 09160-06036 | WASHER | 4 |
| 4 | 09180-06011 | SPACER | 4 |
| 4 | 09320-09016 | CUSHION | 4 |
| 94471-19C00-38K | COVER, UNDER RH (BLUE) FOR F74 | ||
| 94471-19C00-0FP | COVER, UNDER RH (SILVER) FOR F75 | ||
| 94481-19C00-38K | COVER, UNDER,LH (BLUE) FOR F74 | ||
| 94481-19C00-0FP | COVER, UNDER,LH (SILVER) FOR F75 | ||
| 2 | 09139-06042 | SCREW, FRONT | 2 |
| 94531-19C00 | BRACKET, UNDER,RH | ||
| 94532-19C00 | BRACKET, UNDER,LH | ||
| 94590-19C00 | NUT | ||
| 2 | 01137-06165 | BOLT | 2 |
| 2 | 09139-05025 | SCREW (5X14) | 2 |
| 2 | 09161-05017 | WASHER | 2 |
| 2 | 94484-32B00 | NUT | 2 |
| 2 | 09139-06029 | SCREW, REAR | 2 |
| 09180-06116 | SPACER | ||
| 2 | 09320-09016 | CUSHION | 2 |
| 2 | 09136-06081 | SCREW, LOWER | 2 |
| 2 | 09180-06011 | SPACER | 2 |
| 2 | 02142-15165 | SCREW, LOWER | 2 |
| 94580-19C00 | BRACKET, LOWER | ||
| 3 | 02142-05164 | SCREW | 3 |
| 3 | 09161-05017 | WASHER | 3 |
| 94475-19C01 | COVER, UNDER,FRONT (BLACK) | ||
| 1 | 68612-48B00 | LABEL, SCREEN | 1 |
| 94573-20C00 | SHEET, BALANCER,RH | ||
| 94583-20C00 | SHEET, BALANCER,LH | ||
| 94576-20C00 | CUSHION, RH | ||
| 94586-20C00 | CUSHION, LH | ||
| 94574-20C00 | SHEET, BALANCER LOWER,RH | ||
| 94584-20C00 | SHEET, BALANCER LOWER,LH | ||
| 94584-20C10 | SHEET, BALANCER LOWER,LH CALIFORNIA ONLY | ||
| 94639-20C00 | CUSHION, UNDER,REAR | ||
| 1 | 68319-40C00 | LABEL, CAUTION | 1 |
| SPECIAL NOTE | COLOR : F74=33J(BLACK), |
