Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 1220A-LBA2-E00 | HEAD COMP CYLN | 1 |
| 2 | 12205-KHE8-301 | BOLT SEALING 12MM | 2 |
| 1 | 12205-LBA2-E00 | WATER COVER HEAD | 1 |
| 1 | 12206-LBA2-E00 | GASKET HEAD COVER | 1 |
| 1 | 12208-LBA2-E00 | STOPPER HEAD WATER | 1 |
| 4 | 12209-GDB4-68A | SEAL VALVE STEM | 4 |
| 4 | 12209-GDB4-68B | SEAL VALVE STEM | 4 |
| 1 | 12303-LBA2-E00 | GASKET PLATE | 1 |
| 1 | 12310-LBA2-E00 | COVER COMP CYLN HEAD | 1 |
| 1 | 12311-KBE2-900 | BODY REED VALVE (2ND) | 1 |
| 1 | 12391-LBA2-E00 | GASKET HEAD COVER | 1 |
| 14102-LBA2-E00 | CAM | ||
| 3 | 14103-GEN5-912 | SPG ROLLER | 3 |
| 1 | 14104-LBA2-E00 | WASHER THRUST | 1 |
| 3 | 14105-GEN5-910 | ROLLER 3*5 | 3 |
| 1 | 1411A-LBA2-E00 | CAM SHAFT INLET COMP | 1 |
| 1412A-LBA2-E00 | CAMSHAFT EXH COMP | ||
| 1 | 14153-LBA2-E00 | SPRING STOPPER | 1 |
| 1 | 14154-LBA2-E00 | STOPPER | 1 |
| 1 | 14321-KED9-900 | SPROCKET CAMSHAFT | 1 |
| 1 | 14321-LBA2-E00 | SPROCKET CAMSHAFT | 1 |
| 2 | 14451-LBA2-E00 | SHAFT ROCKER ARM | 2 |
| 1 | 14546-LBA2-E00 | GUIDE UPPER TENSIONER | 1 |
| 1 | 14552-KGBG-900 | STOPPER BOLT | 1 |
| 2 | 14611-LBA2-E00 | ARM VALVE ROCKER | 2 |
| 1 | 14711-LBA2-E00 | VALVE INLET | 1 |
| 2 | 14721-LBA2-E00 | VALVE EXHAUST | 2 |
| 4 | 14751-LBA2-E00 | SPG VALVE OUTER | 4 |
| 4 | 14761-LDG7-900 | SPG VALVE INNER | 4 |
| 4 | 14771-KED9-900 | RETAINER VALVE SPRING | 4 |
| 4 | 14777-LBA2-E00 | SEAT VALVE SPG | 4 |
| 8 | 14781-MFA6-001 | COTTER VALVE | 8 |
| 1 | 16201-LBA2-E00 | GASKET CARB INSULATOR | 1 |
| 1 | 16212-LBA2-E00 | INSULATOR INLET PIPE | 1 |
| 1 | 16213-LBA2-E00 | JOINT FUEL | 1 |
| 1 | 17100-LBA2-900 | PIPE COMP INLET | 1 |
| 1 | 17113-LBA2-E00 | O RING INLET PIPE | 1 |
| 10 | 17304-LBA2-M30 | TUBE ASSY CANI-INLET PIPE | 10 |
| 1 | 17685-GFY6-940 | JOINT COCK-CARB TUBE | 1 |
| 1 | 18601-KBE2-900 | REED VALVE COMP 52*27*6 | 1 |
| 1 | 18612-KFB5-900 | COVER REED VALVE | 1 |
| 1 | 18613-LDB5-E00 | STAY REED VALVE ASSY | 1 |
| 1 | 18645-LBA2-E00 | GASKET A/I PIPE | 1 |
| 1 | 18646-LBA2-E00 | GASKET A/I PIPE | 1 |
| 1 | 18647-LBA2-E00 | PIPE COMP AIR | 1 |
| 1 | 32101-LBA2-E00 | SUB HARNESS THERMO UNIT | 1 |
| 1 | 37720-KGB5-900 | EARTH TERMINAL THERMO | 1 |
| 1 | 37750-PAC1-005 | THERMO UNIT ASSY | 1 |
| 2 | 90001-LBA2-E00 | BOLT UBS 8*137 | 2 |
| 1 | 90002-LBA2-E00 | BOLT UBS 8*210 | 1 |
| 5 | 90011-KED9-900 | BOLT UBS 8*48 | 5 |
| 4 | 90012-3C33-001 | SCREW TAPPET ADJUSTING | 4 |
| 4 | 90017-KED9-900 | BOLT ASSY HEAD COVER | 4 |
| 2 | 90031-LBA2-E00 | BOLT UBS 10*220 | 2 |
| 2 | 90032-LBA2-E00 | BOLT UBS 10*210 | 2 |
| 2 | 90033-GFY6-900 | BOLT STUD 8*32 | 2 |
| 2 | 90033-GFY6-941 | BOLT STUD 6*16 | 2 |
| 4 | 90083-KED9-900 | BOLT KNOCK 6MM | 4 |
| 1 | 90084-4H28-001 | CAP ACG | 1 |
| 4 | 90206-0A01-001 | NUT TAPPET ADJUSTING | 4 |
| 2 | 90403-KED9-900 | WASHER WAVE 10MM | 2 |
| 4 | 90465-LBA2-E00 | WASHER 10.2 MM | 4 |
| 1 | 90488-7L00-001 | WASHER 8MM | 1 |
| 4 | 90541-KED9-900 | RUBBER MOUNTING | 4 |
| 1 | 90652-LBA2-E00 | C-HOPE 10-59 | 1 |
| 2 | 90680-LBA2-E00 | CONE TYPE PLUG 12*7 | 2 |
| 4 | 90914-KED9-900 | WASHER HEAD COVER BOLT | 4 |
| 1 | 91303-3G77-001 | O-RING 13.8*2.5 | 1 |
| 2 | 91308-KED9-900 | O RING 17.5*1.5 | 2 |
| 2 | 94050-06080 | NUT FLANGE 6MM | 2 |
| 1 | 94510-20000 | CIR CLIP EX/20MM | 1 |
| 2 | 95002-02070 | CLAMP D6.8 TUBE | 2 |
| 1 | 95701-06025-08 | BOLT FLANGE 6*25 | 1 |
| 2 | 95701-06035-08 | BOLT FLANGE 6*35 | 2 |
| 2 | 95701-06040-08 | BOLT FLANGE 6*40 | 2 |
| 1 | 95801-KED9-900 | BOLT UBS 8*71 | 1 |
| 2 | 96001-06012-08 | BOLT FLANGE SH 6*12 | 2 |
| 2 | 96001-06014-08 | BOLT FLANGE SH 6*14 | 2 |
| 2 | 96001-06018-08 | BOLT FLANGE SH 6*18 | 2 |
| 1 | 98059-58916-00 | SPARK PLUG (CR8E) | 1 |
