Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 1110A-LBA2-E00 | CRANK CASE COMP R | 1 |
| 1 | 11203-LBA2-E00 | RUBBER BUSH L CASE | 1 |
| 1 | 11221-LBA2-E00 | INSULATOR PLATE | 1 |
| 11341-LBA2-E00-N8A | (N8A) GREY, GLOSS PAINTED ALUMINIUM for NH045MA, COVER LEFT | ||
| 11341-LBA2-E00-N8A | (N8A) GREY, GLOSS PAINTED ALUMINIUM for NH124MA, COVER LEFT | ||
| 11341-LBA2-E00-N8A | (N8A) GREY, GLOSS PAINTED ALUMINIUM for PB107MA, COVER LEFT | ||
| 11341-LBA2-E00-N8A | (N8A) GREY, GLOSS PAINTED ALUMINIUM for YR168PA, COVER LEFT | ||
| 11341-LBA2-E00-N8A | (N8A) GREY, GLOSS PAINTED ALUMINIUM for PB244MA, COVER LEFT | ||
| 11343-LBA2-E00 | RR COVER L COVER | ||
| 1 | 11344-LBA2-E00 | INNER COVER L COVER | 1 |
| 1134B-LBA2-E00 | FRONT COVER COMP L COVER | ||
| 1 | 11395-LBA2-E00 | GASKET L COVER @ A | 1 |
| 1 | 12361-GFY6-901 | HOLE CAP TAPPET ADJUSTING | 1 |
| 2 | 13314-LBA2-E0A | BRG CRANK SHAFT A | 2 |
| 2 | 13314-LBA2-E0B | BRG CRANK SHAFT B | 2 |
| 2 | 13314-LBA2-E0C | BRG CRANK SHAFT C | 2 |
| 2 | 13315-LBA2-E0A | BRG CRANK SHAFT A | 2 |
| 2 | 13315-LBA2-E0B | BRG CRANK SHAFT B | 2 |
| 2 | 13315-LBA2-E0C | BRG CRANK SHAFT C | 2 |
| 1 | 15200-LBA2-E00 | OIL RELIEF VALVE ASSY | 1 |
| 1 | 15421-1G07-001 | SCREEN OIL FILTER | 1 |
| 1 | 15426-GAE1-921 | SPG OIL FILTER SCREEN | 1 |
| 1 | 15520-LBA2-E00 | PIPE COMP OIL | 1 |
| 1 | 15521-LBA2-E00 | COLLAR OIL | 1 |
| 1 | 15522-LBA2-E00 | PIPE OIL R/L CASE | 1 |
| 1 | 15700-LBA2-E00 | OIL WATER HEAT EXCHANGER | 1 |
| 1 | 15710-LBA2-E00 | BOTTOM OIL WATER | 1 |
| 1 | 15712-LBA2-E00 | GASKET OIL WATER HEAT EXCHANGER | 1 |
| 6 | 18291-KKC4-900 | COLLAR | 6 |
| 6 | 18293-KKC4-900 | RUBBER | 6 |
| 1 | 23560-LBA2-E00 | ORIFICE R CASE | 1 |
| 1 | 50504-LBA2-E00 | STAND MAIN STOPPER | 1 |
| 1 | 87140-LBA2-E00 | EMB ENG COVER | 1 |
| 2 | 90004-LBA2-E00 | BOLT B OIL PASS | 2 |
| 2 | 90005-LBA2-E00 | BOLT C OIL PASS | 2 |
| 8 | 90407-LBA2-E00 | SEALING WASHER OIL PIPE | 8 |
| 1 | 90474-3C33-001 | WSHER 8MM | 1 |
| 1 | 9052A-GFY6-950 | BOLT ASSY DRAIN PLUG | 1 |
| 4 | 90701-9E65-001 | PIN DOWEL 10*16 | 4 |
| 1 | 91001-KHV8-004 | BRG BALL 6305 | 1 |
| 1 | 91009-LBA2-E00 | BRG BALL RADIAL 6006LLU/2A | 1 |
| 1 | 91202-LBA2-E00 | OIL SEAL 35*47*7 | 1 |
| 1 | 91261-4E15-004 | OIL SEAL 25*40*8 | 1 |
| 1 | 91302-0A01-021 | O RING 30.8MM | 1 |
| 2 | 91313-KED9-900 | O RING 15.5*1.5 | 2 |
| 2 | 91317-LBA2-E00 | O RING 13.5*1.5 | 2 |
| 2 | 93903-34580 | SCREW TAPPING 4*20 | 2 |
| 3 | 94111-06800 | WASHER SPRING 6MM | 3 |
| 2 | 94301-10160 | DOWEL PIN 10*16 | 2 |
| 4 | 94301-12200 | DOWEL PIN 12*20 | 4 |
| 1 | 94520-12100 | CIR CLIP IN 12 | 1 |
| 1 | 94520-52000 | CIR CLIP IN 52 | 1 |
| 1 | 94520-55000 | CIR CLIP IN 55 | 1 |
| 6 | 95701-06016-02 | BOLT FLANGE SH 6*16 | 6 |
| 6 | 95701-06022-08 | BOLT FLANGE 6*22 | 6 |
| 2 | 95701-06028-08 | BOLT FLANGE 6*28 | 2 |
| 1 | 95701-08012-08 | BOLT FLANGE 8*12 | 1 |
| 3 | 96001-06012-08 | BOLT FLANGE SH 6*8 | 3 |
| 1 | 96001-06060-08 | BOLT FLANGE SH 6*60 | 1 |
| 6 | 96001-06065-08 | BOLT FLANGE 6*65 | 6 |
| 1 | 96001-06075-08 | BOLT FLANGE 6*75 | 1 |
| 3 | 96001-06095-08 | BOLT FLANGE 6*95 | 3 |
| 2 | 96001-06100-08 | BOLT FLANGE SH 6*100 | 2 |
| 1 | 96100-62040-00 | BRG BALL RADIAL 6204/20*47*14 | 1 |
| 1 | 96100-63040-00 | BRG BALL RADIAL 6304 | 1 |
| 2 | 96100-LBA2-E00 | BRG BALL RADIAL 6304 | 2 |
| 2 | 96150-60050-00 | BRG BALLRADIAL 6005ZZ | 2 |
