Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 5718-106 | Panel, Side - w/Decals - Right - Black (inc. 2-7, 13-15, 17-20, and 31) | ||
| 1 | 3718-180 | Panel, Side - Right w/Foam - Black (inc. 3-7 and 17-20) | 1 |
| 1 | 0617-626 | Foam, Side Panel - Upper Front - Right | 1 |
| 1 | 6606-414 | Foil, Protective | 1 |
| 1 | 0617-628 | Foam, Side Panel - Upper Rear - Right | 1 |
| 1 | 0617-632 | Foam, Side Panel - Lower Front - Right | 1 |
| 1 | 0617-634 | Foam, Side Panel - Lower Rear - Right | 1 |
| 5718-107 | Panel, Side - w/Decals - Left - Black (inc. 9-20) | ||
| 1 | 4718-553 | Panel, Side w/Foam- Left - Black (inc. 10-12 and 16-20) | 1 |
| 1 | 0617-629 | Foam, Side Panel - Upper Rear - Left | 1 |
| 1 | 0617-635 | Foam, Side Panel - Lower Rear - Left | 1 |
| 1 | 0617-681 | Foam, Side Panel - Lower Front - Left | 1 |
| 1 | 3621-272 | Decal, Side Panel - Upper - Right - Black | 1 |
| 1 | 3621-273 | Decal, Side Panel - Upper - Left - Black | 1 |
| 3621-250 | Decal, Side Panel - Lower - Right | ||
| 1 | 3621-251 | Decal, Side Panel - Lower Rear - Left - Black | 1 |
| 3621-254 | Decal, Side Panel - Front - Right | ||
| 1 | 3621-255 | Decal, Side Panel - Front - Left | 1 |
| 1 | 1623-637 | Clip, U-Nut | 1 |
| 2 | 0607-447 | Cable | 2 |
| 2 | 0605-283 | Clip, Hairpin | 2 |
| 2 | 8060-486 | Rivet | 2 |
| 2 | 8050-127 | Washer | 2 |
| 1623-129 | Screw, Self-Tapping | ||
| 2 | 1623-052 | Clip, U-Nut | 2 |
| 1 | 6606-925 | Screen, Intake | 1 |
| 1 | 2602-794 | Duct, Intake - Inner | 1 |
| 4 | 1623-030 | Clip, U-Nut | 4 |
| 1 | 2602-793 | Duct, Intake - Outer - Black | 1 |
| 1 | 0619-206 | Foil, Protective | 1 |
| 1 | 1702-369 | Duct, Belt Cooling (inc. 30) | 1 |
| 1 | 6606-694 | Foil, Protective | 1 |
| 1 | 3621-252 | Decal, Side Panel - Mid - Right | 1 |
| 1 | 3621-257 | Decal, Side Panel - Vent - Left | 1 |
| 1 | 5718-116 | Plate, Skid - Right - Black - w/Decals | 1 |
| 1 | 4718-158 | Plate, Skid - Right w/Foam- Black (inc. 32, 40 and 62) | 1 |
| 1 | 0617-640 | Foam, Skid Plate - Upper Rear - Right | 1 |
| 1 | 0617-638 | Foam, Skid Plate - Center Front - Right | 1 |
| 1 | 0617-636 | Foam, Skid Plate - Upper Front - Right | 1 |
| 1 | 2612-970 | Foil, Protective | 1 |
| 26 | 8061-708 | Rivet | 26 |
| 1 | 2612-754 | Deflector, Heat | 1 |
| 8 | 0123-802 | Washer | 8 |
| 1 | 5718-115 | Plate, Skid - w/Decal - Left - Black (inc. 38, 40, 42-46 and 62 | 1 |
| 1 | 3718-789 | Plate, Skid - Left w/Foam - Black (inc. 38, 40 and 43-46) | 1 |
| 1 | 0617-637 | Foam, Skid Plate - Upper Front - Left | 1 |
| 1 | 0617-639 | Foam, Skid Plate - Center Front - Left | 1 |
| 1 | 0617-641 | Foam, Skid Plate - Upper Rear - Left | 1 |
| 1 | 6606-613 | Panel, Reinforcement | 1 |
| 2 | 2623-005 | Clip, Retaining | 2 |
| 2 | 6606-592 | Pin, Retaining | 2 |
| 1 | 2612-972 | Plate, Exhaust Outlet | 1 |
| 1 | 2612-971 | Seal, Exhaust Outlet | 1 |
| 1 | 1712-963 | Deflector, Exhaust Outlet - Black | 1 |
| 6 | 8061-710 | Rivet | 6 |
| 1 | 6606-940 | Shield, Heat - ECM | 1 |
| 2 | 8408-620 | Screw, Cap | 2 |
| 1 | 0730-266 | ECM (PLEASE INCLUDE VIN WHEN ORDERING) | 1 |
| 2 | 0423-031 | Clip, U-Nut | 2 |
| 2 | 0623-784 | Screw, Self-Tapping | 2 |
| 1 | 6606-342 | Fascia, Front - Right - Black | 1 |
| 1 | 3718-303 | Fascia, Front - Left - Black (inc. 59) | 1 |
| 6606-405 | Foil, Protective | ||
| 1 | 2623-001 | RETAINER,PUSHNUT - 3/16" STUD | 1 |
| 1 | 1623-999 | Screw, Thumb | 1 |
| 1 | 3621-256 | Decal, Side Panel - Vent Lower Right | 1 |
