Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 114045200 | Hair Pin | 1 |
| 1 | 205052544 | Socket Screw M5 X 25 | 1 |
| 1 | 207588044 | Hex. Cap Screw M8 X 80 | 1 |
| 7 | 232551414 | Elastic Stop Nut M5 | 7 |
| 1 | 234051410 | Flat Washer M5 | 1 |
| 6 | 250000580 | Torx Screw M6 X 30 | 6 |
| 4 | 250000707 | Hex. Button Head Screw M8 X 25 | 4 |
| 4 | 250000742 | Torx Screw M5 X 14 | 4 |
| 2 | 250200009 | Lock Washer 8 mm | 2 |
| 1 | 250200144 | Conical Spring Washer M14 | 1 |
| 2 | 250400063 | Spring Pin M3 X 30 | 2 |
| 6 | 293150103 | Pop Rivet 3/16" | 6 |
| 3 | 293150104 | Pop Rivet 3/16" | 3 |
| 3 | 293300185 | O-Ring Engine 900 ACE | 3 |
| 3 | 293300169 | O Ring Engine 600 ACE | 3 |
| 1 | 293370037 | Circlip | 1 |
| 2 | 293370049 | Circlip | 2 |
| 1 | 293370065 | Circlip | 1 |
| 2 | 390909100 | Avex Rivet | 2 |
| 2 | 390909200 | Avex Rivet | 2 |
| 2 | 417127016 | Pulley Roller | 2 |
| 1 | 417127155 | Washer | 1 |
| 1 | 415129604 | Calibration Ass'y | 1 |
| 2 | 417127318 | Bushing ID 41mm OD 45mm X 19mm L | 2 |
| 1 | 417127344 | Release Spring Engine 600 ACE | 1 |
| 1 | 417127467 | Release Spring Engine 900 ACE | 1 |
| 1 | 417127351 | Fixe Flange Ass'y | 1 |
| 1 | 417127366 | Slider Flange Ass'y | 1 |
| 1 | 417127391 | Cam Ass'y Engine 600 ACE | 1 |
| 1 | 417127474 | Cam Ass'y Engine 900 ACE | 1 |
| 1 | 417222758 | Bushing | 1 |
| 6 | 417223257 | Roller Axle | 6 |
| 1 | 417223650 | Spring Cover Ass'y Engine 900 ACE | 1 |
| 1 | 417223907 | Spring Cover Ass'y Engine 600 ACE | 1 |
| 12 | 417223255 | Thrust Washer Engine 600 ACE | 12 |
| 12 | 417223660 | Stopper Washer Engine 900 ACE | 12 |
| 6 | 417223694 | Ramp Axle | 6 |
| 1 | 417223752 | Seat Spring | 1 |
| 1 | 417223865 | Governor Cup Ass'y | 1 |
| 1 | 417223867 | Fixe Flange Ass'y | 1 |
| 12 | 417223919 | Slider Shoe | 12 |
| 1 | 417223855 | Mobile Flange Ass'y Engine 600 ACE | 1 |
| 1 | 417224044 | Flange Slide Ass'y Engine 900 ACE | 1 |
| 6 | 417223767 | Roller Engine 600 ACE | 6 |
| 6 | 417224081 | Roller Engine 900 ACE | 6 |
| 6 | 417224103 | Ramp 749 Engine 900 ACE | 6 |
| 6 | 417223450 | Ramp 716 Engine 600 ACE | 6 |
| 3 | 417300252 | Spacer | 3 |
| 3 | 417300265 | Spacer | 3 |
| 1 | 417300356 | Side Protector | 1 |
| 1 | 417300374 | Front Belt Guard Bracket | 1 |
| 1 | 417300380 | Reinforcement | 1 |
| 1 | 417300381 | Guide | 1 |
| 1 | 417300382 | Belt Guard | 1 |
| 1 | 417300421 | Reinforcement Plate | 1 |
| 1 | 417300423 | Front Bracket | 1 |
| 1 | 417300430 | Front Support | 1 |
| 1 | 417300432 | Pulley Drive Bolt | 1 |
| 1 | 417300440 | CVT Air Duct Pulley | 1 |
| 1 | 417300445 | Stopper | 1 |
| 1 | 417300448 | BELT GUARD BRACKET | 1 |
| 1 | 417300476 | Stopper | 1 |
| 1 | 417300466 | CVT AIR DUCT | 1 |
| 1 | 516005509 | Safety Belt Guard Decal | 1 |
| 1 | 516005503 | Decal English | 1 |
| 3 | 517225900 | Flat Washer | 3 |
| 1 | 517281905 | Bracket | 1 |
| 1 | 517302322 | Strength Washer | 1 |
| 1 | 207287544 | Hex. Cap Screw M8 X 75 | 1 |
| 1 | 417300127 | Drive Belt Engine 600 ACE | 1 |
| 1 | 417300383 | Drive Belt Engine 900 ACE | 1 |
| 1 | 516007493 | Belt Gard Decal | 1 |
| 1 | 417223747 | Clutch Spring Engine 600 ACE | 1 |
| 1 | 417224085 | Clutch Spring Engine 900 ACE | 1 |
| 2 | 417127294 | Pivot Stud | 2 |
