Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 95014-10010 | ADJUSTER S, R. CHAIN | 1 |
| 41201-126-920 | SPROCKET, FINAL DRIVEN (35T) | ||
| 1 | 41241-051-000 | DAMPER, RR. WHEEL | 1 |
| 1 | 41245-051-000 | COVER, RR. WHEEL DAMPER | 1 |
| 1 | 42304-098-000 | COLLAR, RR. WHEEL SIDE | 1 |
| 42601-098-010AU | HUB, RR. WHEEL *NH35* (CLOUD SILVER) | ||
| 42601-098-010ZB | HUB, RR. WHEEL *NH35M* (CLOUD SILVER METALLIC) | ||
| 42620-098-000 | COLLAR, RR. AXLE DISTANCE | ||
| 42701-098-853ZA | RIM, R. WHEEL *NH35M* (YUNO) (CLOUD SILVER METALLIC) | ||
| 42701-098-854ZA | RIM, R. WHEEL *NH35M* (KANAI) (CLOUD SILVER METALLIC) | ||
| 42702-098-853ZA | RIM, L. WHEEL *NH35M* (YUNO) (CLOUD SILVER METALLIC) | ||
| 42702-098-854ZA | RIM, L. WHEEL *NH35M* (KANAI) (CLOUD SILVER METALLIC) | ||
| 42711-098-951 | TIRE, RR. (4.00-10) (BS) | ||
| 42711-098-952 | TIRE, RR. (4.00-10) (NITTO) | ||
| 42712-GC8-003 | TUBE, TIRE (3.50-10) (BS) | ||
| 42712-GC8-004 | TUBE, TIRE (3.50/4.00) (DUNLOP) | ||
| 42712-GC8-005 | TUBE, TIRE (3.50-10) (INOUE) | ||
| 42712-GV4-904 | TUBE, TIRE (3.50-10) (KIK) | ||
| 42712-098-000 | TUBE, TIRE (4.00-10) | ||
| 42712-098-003 | TUBE, TIRE (4.00-10) (BS) | ||
| 42712-098-691 | TUBE, WHEEL (3.50-10) (BS) | ||
| 42712-098-006 | TUBE, TIRE (4.00-10) (NITTO) | ||
| 1 | 90305-051-000 | NUT, FR. AXLE | 1 |
| 1 | 90305-169-000 | NUT, AXLE (12MM) | 1 |
| 1 | 90753-051-000 | OIL SEAL (26X37X6) | 1 |
| 1 | 90753-051-003 | OIL SEAL (26X37X6) | 1 |
| 1 | 90753-051-005 | OIL SEAL (26X37X6) | 1 |
| 1 | 92000-06012 | BOLT, HEX. (6X12) | 1 |
| 1 | 92101-06012 | BOLT, HEX. (6X12) | 1 |
| 1 | 92101-06012-0A | BOLT, HEX. (6X12) | 1 |
| 1 | 92000-08025-0A | BOLT, HEX. (8X25) | 1 |
| 1 | 92101-08025-0A | BOLT, HEX. (8X25) | 1 |
| 1 | 90310-KA3-711 | NUT, HEX. (6MM) | 1 |
| 1 | 94000-06000-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06000 | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06000-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06008-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06200-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94030-06000 | NUT, HEX. (6MM) | 1 |
| 1 | 94001-08000-0S | NUT, HEX. (8MM) | 1 |
| 1 | 94101-06000 | WASHER, PLAIN (6MM) | 1 |
| 1 | 94101-06080 | WASHER, PLAIN (6MM) | 1 |
| 1 | 94101-06800 | WASHER, PLAIN (6MM) | 1 |
| 1 | 94111-06000 | WASHER, SPRING (6MM) | 1 |
| 1 | 94111-08000 | WASHER, SPRING (8MM) | 1 |
| 1 | 94201-30250 | PIN, COTTER (3.0X25) | 1 |
| 1 | 94201-30300 | PIN, COTTER (3X30) | 1 |
| 1 | 94201-30400 | PIN, COTTER (3.0X40) | 1 |
| 1 | 94201-30450 | PIN, COTTER (3.0X45) | 1 |
| 1 | 94511-50000 | CIRCLIP (OUTER) (50MM) | 1 |
| 1 | 96100-63010 | BEARING, RADIAL BALL (6301U) | 1 |
| 1 | 96140-63010 | BEARING, RADIAL BALL (6301U) | 1 |
| 1 | 96140-63010-10 | BEARING, RADIAL BALL (6301U) | 1 |
