Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 400409420 | <<493>> Engine Grand Touring 500. | ||
| 400509722 | <<593>> Engine Grand Touring 600. | ||
| 400604019 | <<693>> Engine Grand Touring 700. | ||
| 512058000 | Engine Support | ||
| 8 | 234001410 | Flat Washer 10 mm | 8 |
| 234100602 | WASHER-LOCK SPRING DIN.128A-A2 | ||
| 4 | 232006414 | Hex. Nut M10 X 1.5 | 4 |
| 570127700 | RUBBER MOUNT | ||
| 4 | 233601416 | Elastic Locking Nut M10 X 1.5 | 4 |
| 512050900 | Engine Support | ||
| 4 | 512056700 | Lock Washer | 4 |
| 4 | 207102544 | Hex. Screw M10 X 25 | 4 |
| 512058500 | Support Plate | ||
| 1 | 207182044 | Hex. Screw M8 X 20 | 1 |
| 1 | 234081410 | Flat Washer 8 mm | 1 |
| 1 | 232581414 | Hex. Elastic Stop Nut M8 | 1 |
| 1 | 512058800 | STOPPER SCREW | 1 |
| 512059056 | Stopper | ||
| 512059057 | WASHER | ||
| 1 | 732610019 | RH Hex. Jam Nut M12 | 1 |
| 514052994 | Rubber Mount | ||
| 514052891 | Insulated Washer | ||
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 1 | 570039000 | EXHAUST GROMMET Grand Touring 500. Grand Touring 600. | 1 |
| 514053064 | Exhaust Grommet Grand Touring 700. | ||
| 514053159 | Muffler Ass'y Includes 23 - 28. Grand Touring 500. | ||
| 514053212 | Muffler Ass'y Grand Touring 600. | ||
| 514053161 | Muffler Ass'y Grand Touring 700. | ||
| 514053160 | RH Heat Shield | ||
| 514052733 | LH Heat Shield | ||
| 514052734 | RH Insulating Wool | ||
| 514052844 | LH Insulating Wool | ||
| 10 | 390910000 | Pop Rivet 3/16” | 10 |
| 1 | 514052704 | RUBBER BUMPER | 1 |
| 514053198 | Tuned Pipe Ass'y Includes 30 - 41. Grand Touring 600. | ||
| 514053171 | Tuned Pipe Ass'y Includes 30 - 41. Grand Touring 700. | ||
| 514053162 | Tuned Pipe Ass'y Includes 30 - 43. Grand Touring 500. | ||
| 514053167 | Upper Enveloppe Grand Touring 500. | ||
| 514053192 | Upper Enveloppe Grand Touring 600. Grand Touring 700. | ||
| 1 | 514053193 | REAR UPPER ENVELOPE Grand Touring 600. Grand Touring 700. | 1 |
| 1 | 514053196 | REAR LOWER ENVELOPE Grand Touring 600. Grand Touring 700. | 1 |
| 514053168 | Lower Enveloppe Grand Touring 500. | ||
| 514053194 | Rear Lower Enveloppe Grand Touring 600. Grand Touring 700. | ||
| 514052716 | Insulating Wool Grand Touring 500. | ||
| 514053197 | Insulating Wool Grand Touring 600. Grand Touring 700. | ||
| 514053074 | Norma Gear Clamp | ||
| 1 | 514052924 | Norma Clamp Grand Touring 500. | 1 |
| 514053224 | NORMA GEAR CLAMP Grand Touring 600. Grand Touring 700. | ||
| 514052735 | Norma Gear Clamp | ||
| 1 | 293650090 | Norma Gear Clamp Grand Touring 600. Grand Touring 700. | 1 |
| 514052902 | Norma Gear Clamp Grand Touring 600. Grand Touring 700. | ||
| 514053180 | Rubber Pad Grand Touring 600. Grand Touring 700. | ||
| 514052962 | Norma Gear Clamp Grand Touring 500. | ||
| 1 | 514052859 | Norma Gear Clamp Grand Touring 500. | 1 |
| 570044100 | Rubber Pad | ||
| 2 | 390406500 | Pop Rivet 3/16" | 2 |
| 1 | 413710300 | Loctite 17914, Sealant, 80 ml | 1 |
| 7 | 415107100 | Spring | 7 |
| 514052718 | Reflective Sheet | ||
| 514052719 | Reflective Sheet | ||
| 514053026 | Spring Bracket | ||
| 1 | 207151244 | Hex. Screw M5 X 12 | 1 |
| 1 | 233251414 | Hex. Flange Elastic Nut M5 | 1 |
