Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| YF1-58524-25-02 | Over Flow Pipe Assy | ||
| 1 | YF1-58414-25-00 | Over Flow Pipe Assy 2 | 1 |
| YF1-58414-25-20 | . . Pipe, Fuel Over Flow | ||
| 2 | YF1-49714-27-50 | . Pipe Clip | 2 |
| YF1-58415-13-60 | Screw, Air Breather | ||
| YF1-56019-66-50 | Packing | ||
| YF1-G6865-37-10 | Pipe, Injection | ||
| YF1-G6865-37-20 | Pipe, Injection | ||
| YF1-58415-38-50 | Clamp, Pipe 1 | ||
| YF1-58415-38-60 | Clamp, Pipe 2 | ||
| YF0-30245-05-20 | Screw, With Washer | ||
| 2 | YF1-68516-55-12 | Glow Plug | 2 |
| YF1-68516-55-60 | Cord, Glow Plug | ||
| 2 | YF0-27615-00-40 | Nut, Flange | 2 |
| YF1-60015-39-04 | Nozzle Holder Kit | ||
| 1 | YF1-G8269-20-32 | . .Nut | 1 |
| 1 | YF1-60015-30-02 | . .Nozzle Holder Assy | 1 |
| 1 | YF1-58415-32-30 | . . . Washer, Adjusting (0.90Mm UR | 1 |
| YF1-58415-31-70 | . . . . Spring, Nozzle | ||
| 1 | YF1-58415-33-50 | . . . . Piece, Distance | 1 |
| 1 | YF1-58415-31-60 | . . ..Push Rod | 1 |
| 1 | YF1-64755-32-80 | . . . . Nut, Nozzle | 1 |
| 1 | YF1-58419-40-40 | . . ..Washer | 1 |
| 1 | YF1-68515-36-10 | . . ..Nozzle Piece | 1 |
| 1 | YF1-58415-36-22 | . .Packing | 1 |
| 1 | YF1-90775-36-50 | . . Seal, Heat | 1 |
| 2 | YF1-58419-81-00 | Adjusting Washer Assy AP | 2 |
| 1 | YF1-58419-86-80 | . . Washer, Adjusting (1.350Mm) UR | 1 |
| 1 | YF1-58419-86-90 | . . Washer, Adjusting (1.375Mm) UR | 1 |
| 1 | YF1-58419-87-00 | . . Washer, Adjusting (1.400Mm) UR | 1 |
| 1 | YF1-58419-87-10 | . . Washer, Adjusting (1.425Mm) UR | 1 |
| 1 | YF1-58419-87-20 | . . Washer, Adjusting (1.450Mm) UR | 1 |
| 1 | YF1-58419-87-30 | . . Washer, Adjusting (1.475Mm) UR | 1 |
| 1 | YF1-58419-87-40 | . . Washer, Adjusting (1.500Mm) UR | 1 |
| 1 | YF1-58419-87-50 | . . Washer, Adjusting (1.525Mm) UR | 1 |
| 1 | YF1-58419-87-60 | . . Washer, Adjusting (1.550Mm) UR | 1 |
| 1 | YF1-58419-87-70 | . . Washer, Adjusting (1.575Mm) UR | 1 |
| 1 | YF1-58419-87-80 | . . Washer, Adjusting (1.600Mm) UR | 1 |
| 1 | YF1-58419-87-90 | . . Washer, Adjusting (1.625Mm) UR | 1 |
| 1 | YF1-58419-88-00 | . . Washer, Adjusting (1.650Mm) UR | 1 |
| 1 | YF1-58419-88-10 | . . Washer, Adjusting (1.675Mm) UR | 1 |
| 1 | YF1-58419-88-20 | . . Washer, Adjusting (1.700Mm) UR | 1 |
| 1 | YF1-58419-88-30 | . . Washer, Adjusting (1.725Mm) UR | 1 |
| 1 | YF1-58419-88-40 | . . Washer, Adjusting (1.750Mm) UR | 1 |
| 1 | YF1-58419-88-50 | . . Washer, Adjusting (1.775Mm) UR | 1 |
| 1 | YF1-58419-88-60 | . . Washer, Adjusting (1.800Mm) UR | 1 |
| 1 | YF1-58419-88-70 | . . Washer, Adjusting (1.825Mm) UR | 1 |
| 1 | YF1-58419-88-80 | . . Washer, Adjusting (1.850Mm) UR | 1 |
| 1 | YF1-58419-88-90 | . . Washer, Adjusting (1.875Mm) UR | 1 |
| 1 | YF1-58419-89-00 | . . Washer, Adjusting (1900Mm) UR | 1 |
| 1 | YF1-58419-89-10 | . . Washer, Adjusting (1.925Mm) UR | 1 |
| 1 | YF1-58419-86-70 | . . Washer, Adjusting (1.325Mm) UR | 1 |
| 1 | YF1-58419-86-60 | . . Washer, Adjusting (1.300Mm) UR | 1 |
| 1 | YF1-58419-86-50 | . . Washer, Adjusting (1.275Mm) UR | 1 |
| 1 | YF1-58419-86-40 | . . Washer, Adjusting (1.250Mm) UR | 1 |
| 1 | YF1-58419-86-30 | . . Washer, Adjusting (1.225Mm) UR | 1 |
| 1 | YF1-58419-89-20 | . . Washer, Adjusting (1.950Mm) UR | 1 |
| 1 | YF1-58419-86-10 | . . Washer, Adjusting (1.175Mm) UR | 1 |
| 1 | YF1-58419-86-00 | . . Washer, Adjusting (1.150Mm) UR | 1 |
| 1 | YF1-58419-85-90 | . . Washer, Adjusting (1.125Mm) UR | 1 |
| 1 | YF1-58419-85-80 | . . Washer, Adjusting (1.100Mm) UR | 1 |
| 1 | YF1-58419-85-70 | . . Washer, Adjusting (1.075Mm) UR | 1 |
| 1 | YF1-58419-85-60 | . . Washer, Adjusting (1.050Mm) UR | 1 |
| 1 | YF1-58419-85-50 | . . Washer, Adjusting (1.025Mm) UR | 1 |
| 1 | YF1-58419-85-40 | . . Washer, Adjusting (1.000Mm) UR | 1 |
| 1 | YF1-58419-85-30 | . . Washer, Adjusting (0.975Mm) UR | 1 |
| 1 | YF1-58419-85-20 | . . Washer, Adjusting (0.950Mm) UR | 1 |
| 1 | YF1-58419-85-10 | . . Washer, Adjusting (0.925Mm) UR | 1 |
| 1 | YF1-58415-32-30 | . . Washer, Adjusting (0.90Mm) UR | 1 |
| 1 | YF1-58419-86-20 | . . Washer, Adjusting (1.200Mm) UR | 1 |
