Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 3 | M28050 | Welded Nut Skandic 500F. Skandic 600. | 3 |
| M40808 | Screw M5 X 30 Skandic 500F. Skandic 600. | ||
| M5443136 | Windshield Support Skandic 500F. Skandic 600. | ||
| M5443578 | Reflecting Sheet Skandic 500F. Skandic 600. | ||
| M5142624 | Intake Cover Skandic 500F. Skandic 600. | ||
| M5343135 | Filter Skandic 500F. Skandic 600. | ||
| 10 | 570023800 | Windshield Latch Skandic 500F. Skandic 600. | 10 |
| 4 | M36084 | Safety Washer Skandic 500F. Skandic 600. | 4 |
| M40358 | Screw M5 X 30 Skandic 500F. Skandic 600. | ||
| 6 | M20008 | Washer 5 Mm Skandic 500F. Skandic 600. | 6 |
| M519394 | Sub Seat Skandic 500F. Skandic 600. | ||
| M5244982 | Foam Seat Skandic 500F. Skandic 600. | ||
| M5245382 | Seat Cover Skandic 500F. Skandic 600. | ||
| M549874 | HINGE Skandic 500F. Skandic 600. | ||
| 1 | M5440581 | HINGE Skandic 500F. Skandic 600. | 1 |
| M549732 | Lock Plate Skandic 500F. Skandic 600. | ||
| M36043 | Rivet Skandic 500F. Skandic 600. | ||
| 1 | M5440059 | SEALING STRIP PROFIL Skandic 500F. Skandic 600. | 1 |
| M5142066 | Welded Seat Base Weld Skandic 500F. Skandic 600. | ||
| M5443661 | Support Skandic 500F. Skandic 600. | ||
| M5344987 | Pivot Pin Skandic 500F. Skandic 600. | ||
| M5443664 | Lock Tongue Skandic 500F. Skandic 600. | ||
| 2 | M5444439 | SPRING Skandic 500F. Skandic 600. | 2 |
| M40146 | Screw Skandic 500F. Skandic 600. | ||
| 3 | 232541414 | Elastic Stop Nut M4 Skandic 500F. Skandic 600. | 3 |
| M28019 | Cap Skandic 500F. Skandic 600. | ||
| 1 | 234081410 | Flat Washer 8 mm Skandic 500F. Skandic 600. | 1 |
| M40144 | Screw M4 X 16 Skandic 500F. Skandic 600. | ||
| M539877 | Backrest Skandic 500F. Skandic 600. | ||
| M539399 | Backrest Foam Skandic 500F. Skandic 600. | ||
| M5340917 | COVER-BACKREST Skandic 500F. Skandic 600. | ||
| M5343120 | Support Skandic 500F. Skandic 600. | ||
| M5343075 | Charniere *Hinge Skandic 500F. Skandic 600. | ||
| 4 | M40193 | SCREW Skandic 500F. Skandic 600. | 4 |
| 15 | M33200 | Nut M6 Skandic 500F. Skandic 600. | 15 |
| 2 | M5443123 | SPRING PLATE Skandic 500F. Skandic 600. | 2 |
| M5442870 | Cable Keeper Skandic 500F. Skandic 600. | ||
| 5 | M36005 | Rivet *Rivet Skandic 500F. Skandic 600. | 5 |
| M5342674 | Retainer Cable Skandic 500F. Skandic 600. | ||
| 2 | M5442675 | Ressort *Spring Skandic 500F. Skandic 600. | 2 |
| M5444445 | PIPE Skandic 500F. Skandic 600. | ||
| 572079200 | Lamp Moulding Skandic 500F. Skandic 600. | ||
| 2 | M40084 | SCREW M6 X 45 Skandic 500F. Skandic 600. | 2 |
| 4 | M20009 | Washer 6.4 Din 9021 Skandic 500F. Skandic 600. | 4 |
| M549096R | RH Cap Skandic 500F. Skandic 600. | ||
| M549096L | LH Cap Skandic 500F. Skandic 600. | ||
| M5242798 | Front Bumper Skandic 500F. Skandic 600. | ||
| M40078 | Vis *Screw Skandic 500F. Skandic 600. | ||
| M5242803 | LH Hood Guide Skandic 500F. Skandic 600. | ||
| M5242804 | RH Hood Guide Skandic 500F. Skandic 600. | ||
| M5142799 | SUPPORT-FRONT Skandic 500F. Skandic 600. | ||
| M5342234 | Hinge Skandic 500F. Skandic 600. | ||
| M5342345 | Hinge Skandic 500F. Skandic 600. | ||
| M36489 | Rivet Skandic 500F. Skandic 600. | ||
| M5443217 | Hood Guide Skandic 500F. Skandic 600. | ||
| M40247 | Screw M5 X 16 Skandic 500F. Skandic 600. | ||
| 4 | M33062 | NUT M5 Skandic 500F. Skandic 600. | 4 |
| M40332 | SCREW Skandic 500F. Skandic 600. | ||
| M5342509 | SUPP.-BUMPER Skandic 500F. Skandic 600. | ||
| 1 | M5142623 | Protecteur Char*Protector-Hinge Skandic 500F. Skandic 600. | 1 |
| 1 | 414227300 | Clip Skandic 500F. Skandic 600. | 1 |
| M36003 | Rivet Skandic 500F. Skandic 600. | ||
| 2 | 207162544 | Hex. Screw M6 X 25 Skandic 500F. Skandic 600. | 2 |
| 6 | 234161471 | Lock Washer M6, Black Skandic 500F. Skandic 600. | 6 |
| 33 | M36036 | Black, Rivet Skandic 500F. Skandic 600. | 33 |
| 2 | M36009 | Rivet *Rivet Skandic 500F. Skandic 600. | 2 |
| 2 | M5342952 | Hood Latch Skandic 500F. Skandic 600. | 2 |
| M5341435 | Dash Skandic 500F. | ||
| M5346367 | Dash Skandic 600. | ||
| 2 | 205082044 | Socket Head Screw M8 X 20 Skandic 500F. Skandic 600. | 2 |
| M5440665 | Spacer Skandic 500F. Skandic 600. | ||
| M5344621 | Foam Skandic 500F. | ||
| M5146367 | Cushion Skandic 600. | ||
| M5144029 | RH Support Skandic 500F. Skandic 600. | ||
| M5144028 | LH Support Skandic 500F. Skandic 600. | ||
| 20 | M36083 | Rivet *Rivet Skandic 500F. Skandic 600. | 20 |
| 2 | M33066 | NUT M6 Skandic 500F. Skandic 600. | 2 |
| 1 | M546777 | Cable Retenue *Cable-Retainer Skandic 500F. Skandic 600. | 1 |
| XXXX | Not Available As Spare Part - Cabel Keeper Skandic 500F. Skandic 600. | ||
| M40052 | Socket Head Screw M6 X 20 Skandic 500F. Skandic 600. | ||
| M40149 | Screw M6 X 30 Skandic 500F. | ||
| 2 | M40135 | Socket Head Screw M8 X 30 Skandic 500F. Skandic 600. | 2 |
| 1 | M5344443 | SPRING-HOLDER Skandic 500F. Skandic 600. | 1 |
| M5142622 | Air Duct Skandic 500F. | ||
| M5146010 | Hood Skandic 500F. | ||
| M5146008 | Hood Skandic 600. | ||
| M5144412 | Air Duct Skandic 500F. | ||
| 4 | 414644300 | Black, Dart Skandic 500F. | 4 |
| M5245105 | Windshield Skandic 500F. Skandic 600. | ||
| 572036310 | BOX COVER Skandic 500F. Skandic 600. | ||
| 572036400 | COVER-BOX Skandic 500F. Skandic 600. | ||
| M5445400 | Tool Kit Skandic 500F. Skandic 600. | ||
| 414631900 | Acoustic Foam Skandic 500F. Skandic 600. | ||
| M5144049 | Bottom Pan (Black) Skandic 500F. | ||
| M5146366 | Bottom Pan Skandic 600. | ||
| M5242672 | RH Lower Grill Skandic 500F. Skandic 600. | ||
| M5342673 | LH Lower Grill Skandic 500F. Skandic 600. | ||
| 1 | M5242671 | RH UPPER GRILL Skandic 500F. | 1 |
| M5242670 | LH Upper Grill Skandic 500F. Skandic 600. | ||
| M5142669 | Front Grill Skandic 500F. Skandic 600. | ||
| M5343409 | Fan Cover Skandic 600. | ||
| M5343408 | LH Cover Skandic 600. | ||
| M5342990 | RH Cover Skandic 600. |
