Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 515176041 | TEMPERATURE SENSOR No DPM, Includes 1 to 7 | ||
| 1 | 515175670 | Female Terminal Housing, 2 Circuits | 1 |
| 4 | 278000632 | Female Terminal | 4 |
| 1 | 515175675 | Female Lock, 2 Circuits | 1 |
| 1 | 515175671 | FEMALE TERMINAL HOUSING, 3 CIRCUITS | 1 |
| 1 | 515175676 | Female Lock, 3 Circuits | 1 |
| 1 | 293000052 | Sealing Cap | 1 |
| 1 | 515176043 | Temperature Sensor 800HO With DPM, Includes 8 to 11 | 1 |
| 1 | 278000739 | Male Connector, 4 Circuits | 1 |
| 1 | 278000632 | Female Terminal | 1 |
| 1 | 515175677 | MALE WEDGE, 4 CIRCUITS | 1 |
| 1 | 219704455 | Was 293800018 Loctite 592, 50 ml | 1 |
| 1 | 410113200 | Relay | 1 |
| 1 | 293730018 | Mount Dart | 1 |
| 1 | 515175721 | Configuration Harness Ass'y Electric Starter, Includes 15 to 28 | 1 |
| 4 | 515175232 | Male Terminal | 4 |
| 3 | 515175273 | MALE TERMINAL | 3 |
| 1 | 515175283 | Housing Support | 1 |
| 1 | 409209900 | Female Housing, 5 Circuits | 1 |
| 4 | 561503100 | FEMALE TERMINAL | 4 |
| 2 | 409011600 | Female Terminal | 2 |
| 1 | 409004000 | Fuse Holder | 1 |
| 1 | 409014200 | CLIP | 1 |
| 1 | 219704425 | Tubing 6 Mm 3000Mm Long | 1 |
| 1 | 219704400 | Was 409901800 Tubing (13 mm) | 1 |
| 1 | 278000344 | Fuse, 5 Amperes | 1 |
| 1 | 515175720 | MALE TERMINAL HOUSING, 11 CIRCUITS | 1 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 515176175 | CONFIGURATION HARNESS Manual Starter, Includes 29 to 36 | 1 |
| 1 | 515175232 | Male Terminal | 1 |
| 1 | 515175273 | MALE TERMINAL | 1 |
| 1 | 561503100 | FEMALE TERMINAL | 1 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 293750001 | Tie Wrap 94 mm 800HO With DPM | 1 |
| 1 | 293750009 | Tie-Rap 173 mm | 1 |
| 1 | 515176020 | HARNESS SUPPORT | 1 |
| 1 | 515176035 | HORN | 1 |
| 1 | 414805101 | PLASTIC NUT | 1 |
| 1 | 296000309 | Silicone Sealant 51388, 300 ml | 1 |
| 1 | 270600000 | AIR TEMPERATURE SENSOR 800HO With DPM | 1 |
| 1 | 515176234 | FEMALE TERMINAL HOUSING, 6 CIRCUITS | 1 |
| 4 | 293000052 | Sealing Cap No DPM | 4 |
| 515175822 | Sensor Harness No DPM, Includes 46 to 50 | ||
| 1 | 278000631 | Male Terminal | 1 |
| 1 | 409207500 | Male Lock, 2 Circuits | 1 |
| 1 | 515175665 | Male Terminal Housing, 2 Circuits | 1 |
| 515176256 | Heater Element 800HO With DPM | ||
| 1 | 515175654 | Male Terminal Housing, 2 Circuits 800HO With DPM | 1 |
| 2 | 515175232 | Male Terminal 800HO With DPM | 2 |
| 1 | 219704424 | Vinyl Tubing, Low Temp 3000Mm Long 800HO With DPM | 1 |
| 409901300 | LOW TEMPERATURE VINYL TUBING No DPM | ||
| 1 | 515175673 | Male Housing, 6 Circuits No DPM | 1 |
| 1 | 515175678 | Male Wedge, 6 Circuits No DPM | 1 |
