Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 0718-227 | Hood | 1 |
| 0718-272 | Hood w/Decals | ||
| 1611-056 | DECAL, HOOD - SIDE RH | ||
| 1611-057 | DECAL, HOOD - SIDE LH | ||
| 0611-380 | DECAL, "ARCTIC CAT" | ||
| 0617-122 | Foam, Hood - Side Right | ||
| 0717-012 | Foam, Hood - Headlight Pod | ||
| 0623-143 | Clip | ||
| 0117-835 | Foil | ||
| 2 | 8061-706 | Rivet | 2 |
| 0606-830 | Bracket, Headlight | ||
| 0609-151 | HEADLAMP-SLOPED | ||
| 4 | 0123-615 | Nut, Headlight Adjustment | 4 |
| 0109-735 | Bulb | ||
| 0115-285 | Holder, Cap | ||
| 0609-114 | Cap, Bulb | ||
| 0623-051 | SCREW,ADJUSTMENT 1.96 BLK ZINC | ||
| 4 | 0123-614 | Spring, Adjustment | 4 |
| 0606-985 | Bushing, Alignment | ||
| 0606-954 | Protector, Trim | ||
| 0623-332 | Screw, Self-Tapping | ||
| 2 | 1623-984 | Clamp, Routing | 2 |
| 0623-311 | Screw, Self-Tapping | ||
| 0616-381 | NOSEPIECE,HOOD(-259) | ||
| 0611-782 | DECAL, ENGINE CAUTION | ||
| 0302-016 | Pin | ||
| 6 | 0117-868 | Pin, Cotter | 6 |
| 0115-595 | Cable, Seat | ||
| 1 | 0123-510 | Spring, Extension | 1 |
| 2 | 0115-306 | Strap, Latch | 2 |
| 0623-261 | Washer, Cup | ||
| 2 | 8009-614 | Screw, Machine | 2 |
| 2 | 8040-366 | Nut, Lock | 2 |
| 2 | 8050-217 | Washer, Flat | 2 |
| 1611-414 | Decal, Battery/Engine | ||
| 0718-197 | Pod, Side - w/Foam Left (inc. 17) | ||
| 0718-196 | Pod, Side - w/Foam Right (inc. 17) | ||
| 3 | 0115-307 | Cup, Latch | 3 |
| 6 | 8060-428 | Rivet | 6 |
| 6 | 0123-149 | Washer, Flat | 6 |
| 1 | 0717-078 | FOAM,HOOD-CONVOLUTED 27 X 3'X.75 | 1 |
| 0617-130 | FOAM,POD-RH | ||
| 0606-526 | Reflector, Front Amber | ||
| 8060-430 | RIVET,BLIND-DH AA58 BLK | ||
| 0623-230 | Pin | ||
| 0606-704 | BUMPER,POD | ||
| 0611-704 | Decal, Caution | ||
| 0611-886 | DECAL, FUEL | ||
| 0123-709 | Nut w/Washer | ||
| 8 | 0623-257 | Screw, Self-Tapping | 8 |
| 1 | 0706-548 | Foil, Protective | 1 |
| 0623-259 | Clip, Bumper - Pod | ||
| 0606-800 | Guide, Hood Pin - Right | ||
| 0606-801 | Guide, Hood Pin - Left | ||
| 0617-111 | Foam, Hood - Center | ||
| 0606-839 | Windshield, Smoke | ||
| 0611-706 | Decal, "Made in USA" | ||
| 6 | 0616-032 | O-Ring | 6 |
| 4 | 0623-302 | Screw, Self-Tapping | 4 |
| 8 | 8041-246 | Nut, Lock | 8 |
| 0606-955 | Hinge | ||
| 4 | 8007-430 | Screw, Machine | 4 |
| 8007-432 | SCREW,MACH-CRTH 10-24X1.0 G2 Z & BLK | ||
| 0606-959 | DUCT, AIR OUT | ||
| 0616-068 | Screen, Vent - Hood Lower Right | ||
| 1 | 0616-069 | Screen, Vent - Hood Lower Left | 1 |
| 1 | 0616-070 | Screen, Vent - Hood Upper Right | 1 |
| 0616-071 | Screen, Vent - Hood Upper Left | ||
| 0706-848 | Screen, Vent - Hood Rear Right | ||
| 0706-849 | Screen, Vent - Hood Rear Left | ||
| 2 | 0123-010 | Nut, Expansion | 2 |
| 2 | 0124-054 | Cap, Snap - Washer | 2 |
| 2 | 0123-549 | SCREW,MACH-PHTRH 10-32 X 1.00 Z&Y | 2 |
| 0617-135 | Foam, Duct - Hood | ||
| 8050-158 | Washer, Lock |
