Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | YFG-31810-31-50 | Panel Assy, Usa-Edl6500 UR FOR USA | 1 |
| YF1-89670-31-50 | Panel Assy, Control (7Nf5) UR FOR CAN | ||
| 1 | YFG-31810-32-10 | . Plate, Panel UR FOR USA | 1 |
| YF1-89670-32-10 | . Plate, Panel UR FOR CAN | ||
| 1 | YF1-89610-34-20 | . Box, Pilot (Edl6500) | 1 |
| 1 | YF5-21704-18-52 | . Indicator, Glow Plug (7Nf1-5) UR FOR USA | 1 |
| 1 | YF1-59516-59-50 | . Indicator UR FOR CAN | 1 |
| 1 | YF3-63308-74-70 | . Cover, Rubber (Edl6500) FOR USA | 1 |
| 1 | YF1-53776-36-10 | . Starter Switch Assy UR FOR USA | 1 |
| 1 | YF1-89616-36-00 | . Starter Switch Assy UR FOR CAN | 1 |
| YF6-67115-51-40 | . . Key, Start | ||
| 1 | YF1-89616-18-00 | . Terminal Assy, Earth (Edl6500 | 1 |
| 1 | YF1-89616-18-20 | . . Bolt, Earth | 1 |
| 1 | YF1-89616-18-30 | . . Nut (Edl6500) | 1 |
| 1 | YF0-45125-00-60 | . . Washer, Spring | 1 |
| 1 | YF0-40125-00-60 | . . Washer, Plate | 1 |
| 1 | YF1-89616-18-10 | . . Nut (Edl6500) | 1 |
| YF1-89616-05-10 | . Switch, Toggle (Edl6500) | ||
| 1 | YF1-89616-12-10 | . Lamp Assy, Pilot (Edl6500) UR FOR USA | 1 |
| 1 | YF1-89676-12-10 | . Pilot Lamp Assy (7Nf5) UR FOR CAN | 1 |
| 1 | YF1-89610-35-50 | Meter, V (Edl6500) | 1 |
| YF1-89610-32-50 | . Receptacle (Edl6500) UR FOR USA | ||
| YF1-86200-34-32 | . Receptacle, Twin (Gfci 7Nf1) UR FOR USA | ||
| 1 | YF1-89670-32-51 | . Receptacle, Twin (7Nf5) UR FOR CAN | 1 |
| 2 | YF1-89619-64-00 | . Screw, With Washer (Edl6500) | 2 |
| 1 | YF1-89610-34-30 | . Receptacle L5-30R | 1 |
| YF1-89610-33-80 | . Receptacle (Edl6500) UR FOR USA | ||
| 1 | YF1-89670-33-80 | . Receptacle, L6-30R (7Nf5 Can) UR FOR CAN | 1 |
| 1 | YF1-89610-34-00 | . Receptacle L14-30R | 1 |
| 5 | YF1-89619-64-00 | . Screw, With Washer (Edl6500) UR FOR USA | 5 |
| 6 | YF1-89619-64-00 | . Screw, With Washer (Edl6500) UR FOR CAN | 6 |
| 1 | YF1-89619-64-10 | . Screw, With Washer (Edl6500) UR FOR USA | 1 |
| YF0-20545-00-40 | . Nut UR FOR USA | ||
| YF0-20545-00-40 | . Nut UR FOR CAN | ||
| 1 | YF1-89610-38-70 | . Switch, V (Select), Edl6500 UR FOR USA | 1 |
| 1 | YF1-89670-38-71 | . Switch, V (7Nf5) UR FOR CAN | 1 |
| 1 | YF1-89616-05-20 | . Cap, Water Proof (Edl6500) UR FOR CAN | 1 |
| 2 | YF1-89616-05-20 | . Cap, Water Proof (Edl6500) UR FOR USA | 2 |
| YF1-89610-35-10 | . Breaker (26.5A) | ||
| 1 | YF1-89670-32-20 | Cover, Blind (7Nf5) FOR CAN | 1 |
| 1 | YF1-89670-32-40 | Gasket (7Nf5) FOR CAN | 1 |
| 1 | YF1-89670-32-30 | Plate, Blind Cover (7Nf5) FOR CAN | 1 |
| 1 | YF0-17545-06-12 | Bolt, Flange FOR CAN | 1 |
| 1 | YF1-89676-12-10 | Pilot Lamp Assy (7Nf5) FOR CAN | 1 |
| 1 | YF1-89676-12-30 | Bulb (7Nf5) FOR CAN | 1 |
| 1 | YF1-89616-13-50 | Meter Assy, Hour (Edl6500 FOR CAN | 1 |
| 2 | YF1-89670-35-20 | Protector (15A) FOR CAN | 2 |
| 1 | YF1-89670-35-30 | Protector (15A) FOR CAN | 1 |
