Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2681452 | SEAT ASM.(650SWED.) (Incl. 2-7, 12, 54) | ||
| 2681451 | COVER,SEAT(SCAND'650') | ||
| 5430425 | HOUSING,TAILLIGHT | ||
| 2 | 4030015 | BULB TAILLIGHT/TACH/SPEEDO (10) | 2 |
| 4030019 | BULB, BRAKELIGHT | ||
| 5430423 | Discontinued | ||
| 7511840 | SCREW | ||
| 5 | 7542122 | NYLOK NUT | 5 |
| 2 | 7558221 | WASHER(10) | 2 |
| 5430575 | GROMMET-GAS TANK | ||
| 2681427 | COVER,TANK(400/650) | ||
| 2681290 | BUCKLE&STRAP | ||
| 1 | 5810142 | GAS CAP GASKET | 1 |
| 1 | 2511149 | GAS CAP WITH GAUGE | 1 |
| 1 | 7042020 | SPRING, TANK | 1 |
| 5221722 | STRAP,GASTANK,BLK. | ||
| 5420126 | Discontinued | ||
| 2511150 | TANK,GAS | ||
| 1 | 7052037 | FUEL PICKUP WITH FILTER, 105 MI | 1 |
| 1 | 7052023 | FITTING, OUTLET | 1 |
| 2200190 | N/A,USE COMPONENTS | ||
| 5430669 | VENT-TANK | ||
| 2 | 5810063 | PAD-GAS TANK | 2 |
| 34 | 7621457 | RIVET | 34 |
| 1 | 7080398 | PLUG HOLE | 1 |
| 6 | 7621403 | BLIND RIVET | 6 |
| 2200303 | FOOTREST,LH,(650) | ||
| 2200332 | KIT,RH.FOOTREST(SCAND) | ||
| 1 | 7621452 | RIVET | 1 |
| 14 | 7621330 | POP RIVET | 14 |
| 4020035 | CLIP,WIRING | ||
| 5210728 | HINGE | ||
| 6 | 7558212 | WASHER,13/64X1/2X18GA,FL-Y (10) | 6 |
| 52 | 7621429 | RIVET | 52 |
| 2 | 5220817 | BELT RETAINER CLIP | 2 |
| 5230118 | SUBSTITUTED BY 5240965 | ||
| 1 | 7080216 | CLUTCH GUARD PIN | 1 |
| 1011778 | DESC NOT_AVAILABLE (650 SKS Only w/1011694) | ||
| 1011665 | TUNNEL ASM,('89-650) (650 SKS) | ||
| 7072558 | DECAL,CLUTCH,POLARIS | ||
| 3 | 7670021 | NUT, SPEED | 3 |
| 7080227 | SNAP-MALE | ||
| 7072153 | DECAL, WARNING | ||
| 5224347 | BUMPER,R.(N-INDY) | ||
| 5224421 | DESC NOT_AVAILABLE (650 SKS Only) | ||
| 7072637 | DECAL,TRACK,SILVER(650) | ||
| 5220478 | PANEL,TUNNEL,BACK | ||
| 1011694 | PANEL,CLOSE-OFF,REAR (650 SKS Only) | ||
| 1 | 5410577 | SNOW FLAP | 1 |
| 5 | 7621418 | RIVET(50) | 5 |
| 5222061 | WEARPLATE,TUNNEL | ||
| 7661812 | RIVET,SEMI-TUBE,(10) * | ||
| 7072818 | DECAL, SKS, RED (650 SKS Only) | ||
| 2 | 2670070 | REFLECTOR, RED | 2 |
| 2 | 7512103 | BOLT | 2 |
| 5430707 | SEAT BUN (except for 650 SKS) (Swedish) | ||
| 6 | 7621222 | RIVET(10) | 6 |
| 5220634 | PLATE,TUNNEL,LH | ||
| 5220635 | PLATE,TUNNEL,RH | ||
| 5810201 | FOAM, FILLER | ||
| 2460226 | TAILLIGHT HARNESS | ||
| 3 | 7512193 | CARRIAGE BOLT | 3 |
| 5220406 | BRACKET, HINGE | ||
| 1011582 | SUPT., MUFFLER | ||
| 5221932 | BRACKET, GASTANK | ||
| 1011614 | BULKHEAD,(600/650) | ||
| 4 | 7558301 | FLAT WASHER | 4 |
| 5430930 | Discontinued | ||
| 4 | 7511863 | SCREW | 4 |
| 4 | 7512240 | BOLT | 4 |
| 7072582 | DECAL,36'',R.BUMP | ||
| 2 | 7542451 | NYLOK NUT (650 SKS Only) | 2 |
| 7515493 | BOLT,NYLOC,BLACK (650 SKS Only) | ||
| 1011667 | BRKT,R.SUSP,RH MTG. | ||
| 1011666 | BRKT,R.SUSP,LH MTG. | ||
| 5220542 | BRKT. | ||
| 5220973 | BRKT, TOOL BOX | ||
| 1 | 8450003 | FUEL LINE, 1/4 ID | 1 |
| 5222119 | DESC NOT_AVAILABLE (Swedish 650 SKS Only) | ||
| 7072776 | DECAL,TUNNEL STRIPE | ||
| 7030007 | KNOB ASM,BACKREST | ||
| 4 | 5431015 | GRIP-HAND W/INSERT (NOR/FIN 650 SKS Only) | 4 |
| 5430925 | BOX,TOOL,(2-UP SEAT) (650 SKS) | ||
| 5223798 | BRACKET-CLUTCH GUARD (Swedish 650 SKS Only) | ||
| 1 | 5220942 | PLATE,HITCH MT,BLK. (FIN 650 Only) | 1 |
| 5220941 | BRACKET, HITCH | ||
| 2691356 | DESC NOT_AVAILABLE (NOR/FIN 650 SKS Only) | ||
| 2681265 | COVER, BACKREST (Swedish 650 SKS Only) | ||
| 1011697 | GRABBAR, RH | ||
| 1011696 | GRABBAR, LH | ||
| 5430781 | REFLECTOR |
