Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 1930589 | HOUSING, PISTON | 1 |
| 1930558 | NUT | ||
| 1930559 | BUSHING | ||
| 5222423 | BRKT,BRAKE CALIPER (All except 650) | ||
| 5222234 | BRKT,BRAKE CALIPER (650) | ||
| 1930561 | BOLT-BRIDGE | ||
| 1930569 | BRAKE PAD, INDIVIDUAL | ||
| 1930672 | LINE, BRAKE (Sport GT) | ||
| 5420114 | LINE-BRAKE (All except Sport GT) | ||
| 7080349 | CABLE, BRAKE (650, 500) | ||
| 7080376 | CABLE, BRAKE (Sport, GT) | ||
| 1930588 | PAD, BRAKE,(THICK) | ||
| 1910024 | BRACKET | ||
| 7080316 | PIN, CLEVIS | ||
| 1930652 | CALIPER ASM,BRAKE | ||
| 1 | 7052034 | ELBOW-FEMALE | 1 |
| 5332795 | BUSHING | ||
| 1 | 7542122 | NYLOK NUT | 1 |
| 7041147 | SPRING, BRAKE RETURN | ||
| 1930578 | TAB-JAM NUT LOCK | ||
| 1930577 | NUT-JAM | ||
| 1930590 | BOLT & STOP | ||
| 1 | 1930580 | SHAFT-HELIX | 1 |
| 1930563 | PIN,PAD RETAINING | ||
| 4110046 | SWITCH-STOPLIGHT | ||
| 5211163 | SPACER,(SWED.BRAKE) | ||
| 5010248 | SPACER,RING(SWED.BRAKE) | ||
| 5333033 | STAND-OFF,C/C COVER | ||
| 5020569 | CAP, STUD COVER | ||
| 5210999 | SPACER (650) | ||
| 5410401 | O-RING,CHAINCASE | ||
| 1 | 7515477 | SCREW, CARRIAGE | 1 |
| 5020347 | SHAFT-IDLER | ||
| 1930562 | CLIP-SPRING | ||
| ------- | Driven Clutch | ||
| 7515301 | BOLT | ||
| 1 | 7555701 | WASHER,FLAT | 1 |
| 1 | 7555734 | WASHER,FLAT(10) | 1 |
| 5020291 | INPUT SHAFT SPACER, .984 X 63 | ||
| 4 | 5221172 | FLANGETTE | 4 |
| 3514501 | Discontinued | ||
| 3 | 7558402 | FLAT WASHER | 3 |
| 6 | 7542324 | NYLOK NUT | 6 |
| 1 | 7721204 | KEY-SQUARE | 1 |
| 5020323 | SHAFT, INPUT,BLK. (650, 500) | ||
| 5020546 | SHAFT, INPUT (Sport, GT) | ||
| 7727003 | KEY,(10) | ||
| 7713901 | Discontinued | ||
| 1332091 | DISC BRAKE ASM | ||
| 5223775 | COVER CHAINCASE | ||
| 7512246 | Discontinued | ||
| 5410012 | PLUG,RUBBER-HOLE,.5DIA | ||
| 1 | 7511909 | SCREW | 1 |
| 1 | 7558201 | WASHER, FLAT | 1 |
| 7541918 | NUT-WELL | ||
| 5410277 | Discontinued | ||
| 2 | 7512325 | BOLT | 2 |
| 7577902 | WASHER,SHAKEPROOF,5/16 | ||
| 1332078 | CHAINCASE TIGHTENER | ||
| 1321031 | DESC NOT_AVAILABLE (340) | ||
| 1321034 | DESC NOT_AVAILABLE (650, 500, 500 SP, Classic) | ||
| 1321037 | DESC NOT_AVAILABLE (500 Trail) | ||
| 3224023 | Discontinued (650, 500) | ||
| 3222036 | SPROCKET 35 T,11W | ||
| 2 | 7556509 | BUSHING | 2 |
| 3224026 | CHAIN,62P,SILENT (Sport, GT) | ||
| 5010128 | SPACER, SPROCKET | ||
| 2 | 7718406 | RETAINING RING | 2 |
| 3514307 | BEARING,CHAINCASE | ||
| 7512470 | Discontinued | ||
| 1 | 7542404 | NUT | 1 |
| 5410565 | O RING | ||
| 5020430 | Discontinued | ||
| 7512293 | BOLT, S.S.(10) | ||
| 1011593 | RETAINER, RECOIL (650Only) | ||
| 5 | 7512240 | BOLT | 5 |
| 4 | 7552801 | SPRING LOCK WASHER | 4 |
| 5130752 | DESC NOT_AVAILABLE | ||
| 3 | 7515428 | BOLT,CARRIAGE | 3 |
| 3 | 7542423 | NUT,FLANGE | 3 |
| 3 | 7512331 | BOLT,CARRIAGE | 3 |
| 1590198 | DRIVE SHAFT ASM (All except 650)(Incl. 76 - 78) | ||
| 1590218 | DRIVESHAFT ASM. (650) (Incl. 76-78) | ||
| 5020388 | DRIVE SHAFT | ||
| 5430571 | SPROCKET, 9T | ||
| 5430993 | SPROCKET, HALF,9T (650 only) | ||
| 1 | 3280019 | SPEEDO METAL BUSHING | 1 |
| 1 | 3211042 | SNOWMOBILE DRIVE BELT (All except 340) | 1 |
| 3211052 | BELT, DRIVE (340) | ||
| 3 | 7512394 | CARRIAGE BOLT | 3 |
| 1 | 1930668 | BRAKE ASM.(HALF) | 1 |
| 1930670 | PAD,PARK BRAKE(COMPL.) | ||
| 1930570 | CASTING-CARRIER | ||
| 1930568 | PISTON | ||
| 1930564 | SCREW-BLEEDER | ||
| 1930567 | SEAL-PISTON | ||
| 1321034 | DESC NOT_AVAILABLE (650,500,500 SP,Classic) | ||
| 1011593 | RETAINER, RECOIL (650 Only) | ||
| 1590218 | DRIVESHAFT ASM. (650) (Incl. 76 | ||
| 1590218 | DRIVESHAFT ASM. (650) (Incl. 76 - 78) |
