Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 1B7-24730-01-00 | Double Seat Assy | 1 |
| 1 | 1B7-24731-00-00 | . Cover, Seat | 1 |
| 1 | 1B7-2475M-00-00 | . Seal | 1 |
| 1 | 1B7-2475H-00-00 | . Bracket, Seat Lever 1 | 1 |
| 4 | 95807-06020-00 | . Bolt, Flange | 4 |
| 1 | 1B7-24752-09-00 | . Plate | 1 |
| 2 | 1B7-28429-00-00 | . Seal 2 | 2 |
| 4 | 1B7-2844E-00-00 | . Seal 3 | 4 |
| 1 | 95707-06500-00 | . Nut, Flange | 1 |
| 4 | 5SL-24723-00-00 | . .Damper, Seat | 4 |
| 1 | 90201-06380-00 | . Washer Plain | 1 |
| 1 | 1B7-24790-00-00 | . Seat Back Assy | 1 |
| 1 | 1B7-24791-00-00 | . . Cover, Seat Back | 1 |
| 1 | 59V-21646-00-00 | . Band | 1 |
| 1 | 1B7-2470E-00-00 | Bottom Plate Comp | 1 |
| 1 | 1B7-24769-00-00 | . Hinge, Seat | 1 |
| 1B7-24726-00-00 | . Hinge, Seat | ||
| 2 | 90109-063F5-00 | . Bolt | 2 |
| 2 | 90206-10M04-00 | . Washer, Wave | 2 |
| 2 | 90109-06084-00 | . Bolt | 2 |
| 4 | 1B7-28428-00-00 | . Seal 1 | 4 |
| 2 | 90109-06084-00 | Bolt | 2 |
| 1 | 4HC-84770-00-00 | Light, Accessory | 1 |
| 1 | 4HC-84347-00-00 | . .Bulb (12V-2W) | 1 |
| 1B7-82583-00-00 | Band | ||
| 1 | 1B7-81860-00-00 | Switch Assy | 1 |
| 1 | 98907-03010-00 | Screw, Bind | 1 |
| 90464-07002-00 | Clamp | ||
| 2 | 90464-12001-00 | .Clamp | 2 |
| 1 | 5GJ-2839M-00-00 | Seal, Box 2 | 1 |
| 1 | 4HC-21398-00-00 | Hanger, Helmet | 1 |
| 1 | 1B7-21731-00-00 | Cover, Side 3 | 1 |
| 6 | 97707-40012-00 | .Screw, Tapping | 6 |
| 4 | 92017-06014-00 | Bolt, Button Head | 4 |
| 2 | 90430-04002-00 | Gasket | 2 |
| 2 | 5PS-24741-00-00 | Pad, Seat | 2 |
| 2 | 95817-08016-00 | Bolt, Flange | 2 |
| 2 | 90201-096J9-00 | Washer, Plate | 2 |
| 1B7-8259F-00-00 | Switch Assy | ||
| 2 | 90159-05028-00 | Screw, With Washer | 2 |
| 1 | 1B7-2471P-00-00 | Plate, Cover | 1 |
| 1 | 1B7-24704-00-00 | Box Assy | 1 |
| 1 | 1B7-24747-00-00 | . Damper, Seat | 1 |
| 1 | 1B7-24858-00-00 | . Seal | 1 |
| 1 | 90338-06018-00 | . Plug | 1 |
| 1 | 1B7-24723-00-00 | Damper, Seat | 1 |
| 3 | 90109-06084-00 | Bolt | 3 |
| 1B7-2475A-00-00 | Seat Box Assy | ||
| 4 | 90109-06084-00 | Bolt | 4 |
| 1 | 1B7-24773-00-00 | Handle, Seat | 1 |
| 1 | 1B7-24845-00-00 | Cover 1 | 1 |
| 1B7-2484L-00-00 | Tray | ||
| 1 | 1B7-24846-00-00 | Cover 2 | 1 |
| 1 | 1B7-2484M-00-00 | Tray, 2 | 1 |
| 2 | 90105-08098-00 | Bolt, Flange | 2 |
| 1 | 1B7-24796-00-00 | Cover | 1 |
| 1 | 1B7-2475X-00-00 | Cover, 2 | 1 |
| 2 | 97707-50014-00 | Screw, Truss Head Tapping | 2 |
| 1B7-2840F-00-00 | Back Rest Assy | ||
| 1B7-2843F-00-00 | . Cover Assy | ||
| 2 | 90387-085E1-00 | Collar | 2 |
| 1B7-2478G-00-00 | Stopper | ||
| 2 | 90468-18121-00 | Clip | 2 |
| 1 | 1B7-24780-00-00 | Seat Lock Assy | 1 |
| 2 | 90111-06051-00 | Bolt,Hex. Socket Button | 2 |
| 2 | 90201-06029-00 | Washer, Plate | 2 |
| 1 | 1B7-2478E-10-00 | Cable, Seat Lock | 1 |
| 1B7-24625-00-00 | Guide, Cap | ||
| 1 | 92017-05010-00 | Bolt, Button Head | 1 |
| 1 | 1B7-2476U-00-00 | Protector, 1 | 1 |
| 1B7-2834E-00-00 | Damper 3 | ||
| 2 | 90119-06205-00 | Bolt, With Washer | 2 |
| 1 | 97707-50016-00 | Screw, Truss Head Tapping | 1 |
| 1 | 90460-15126-00 | Clamp, Hose | 1 |
| 5FB-21668-01-00 | Label, Tire | ||
| 1 | 3JJ-28446-A1-00 | Label, Caution | 1 |
| 1 | 5RU-24877-A0-00 | Label, Caution | 1 |
| 1 | 3TB-24877-A0-00 | Label, Caution | 1 |
| 1 | 5RU-21686-00-00 | Plate, Routing 2 | 1 |
| 1B7-2179N-00-00 | Plate, Epa 2 (California) |
